• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
112
3 Capacity tables
3-2 Heating capacity
3-2-9 22HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 275
-19.8 -20.0 35.6 19.9 35.6 20.3 34.5 19.8 33.4 19.1 32.3 18.3 30.1 16.9
-18.8 -19.0 36.9 20.2 36.7 20.4 34.5 19.0 33.4 18.3 32.3 17.6 30.1 16.2
-16.7 -17.0 38.9 20.2 36.7 18.8 34.5 17.5 33.4 16.8 32.3 16.2 30.1 14.9
-14.7 -15.0 38.9 18.6 36.7 17.4 34.5 16.2 33.4 15.6 32.3 15.0 30.1 13.9
-12.6 -13.0 38.9 17.4 36.7 16.2 34.5 15.1 33.4 14.6 32.3 14.0 30.1 13.0
-10.5 -11.0 38.9 16.2 36.7 15.2 34.5 14.2 33.4 13.7 32.3 13.2 30.1 12.2
-9.5-10.038.915.736.714.734.513.733.413.332.312.830.111.9
-8.5 -9.1 38.9 15.3 36.7 14.3 34.5 13.4 33.4 12.9 32.3 12.5 30.1 11.6
-7.0 -7.6 38.9 14.6 36.7 13.7 34.5 12.8 33.4 12.4 32.3 11.9 30.1 11.1
-5.0 -5.6 38.9 13.9 36.7 13.0 34.5 12.2 33.4 11.7 32.3 11.3 30.1 10.5
-3.0 -3.7 38.9 13.2 36.7 12.4 34.5 11.6 33.4 11.2 32.3 10.8 30.1 10.1
0.0 -0.738.912.336.711.534.510.833.410.432.310.130.19.40
3.0 2.2 38.9 11.5 36.7 10.8 34.5 10.1 33.4 9.82 32.3 9.49 30.1 8.85
5.0 4.1 38.9 11.0 36.7 10.4 34.5 9.76 33.4 9.45 32.3 9.14 30.1 8.53
7.0 6.0 38.9 10.6 36.7 10.0 34.5 9.41 33.4 9.11 32.3 8.82 30.1 8.23
9.0 7.9 38.9 10.3 36.7 9.67 34.5 9.09 33.4 8.80 32.3 8.52 30.1 7.96
11.0 9.8 38.99.9136.79.3534.58.7933.48.5232.38.2530.17.71
13.0 11.8 38.9 9.57 36.7 9.03 34.5 8.50 33.4 8.24 32.3 7.98 30.1 7.47
15.0 13.7 38.9 9.27 36.7 8.75 34.5 8.25 33.4 7.99 32.3 7.74 30.1 7.25
NOTE
1 is shown as reference
