Daikin RXYQ22M7W1B [143/182] Capacity tables
![Daikin RXYQ22M7W1B [143/182] Capacity tables](/views2/1707499/page143/bg8f.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
142
3 Capacity tables
3-2 Heating capacity
3-2-19 42HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 525
-19.8 -20.0 67.2 36.5 67.1 37.2 65.8 36.9 63.6 35.5 61.5 34.1 57.3 31.4
-18.8 -19.0 69.7 37.0 69.6 37.7 65.8 35.3 63.6 34.0 61.5 32.7 57.3 30.1
-16.7 -17.0 74.2 37.5 70.0 35.0 65.8 32.5 63.6 31.3 61.5 30.1 57.3 27.8
-14.7 -15.0 74.2 34.7 70.0 32.4 65.8 30.2 63.6 29.1 61.5 28.0 57.3 25.8
-12.6 -13.0 74.2 32.3 70.0 30.2 65.8 28.1 63.6 27.1 61.5 26.1 57.3 24.2
-10.5 -11.0 74.2 30.2 70.0 28.3 65.8 26.4 63.6 25.4 61.5 24.5 57.3 22.7
-9.5-10.074.229.370.027.465.825.663.624.761.523.857.322.0
-8.5 -9.1 74.2 28.5 70.0 26.7 65.8 24.9 63.6 24.0 61.5 23.2 57.3 21.5
-7.0 -7.6 74.2 27.2 70.0 25.5 65.8 23.9 63.6 23.0 61.5 22.2 57.3 20.6
-5.0 -5.6 74.2 25.8 70.0 24.2 65.8 22.6 63.6 21.8 61.5 21.1 57.3 19.6
-3.0 -3.7 74.2 24.5 70.0 23.0 65.8 21.6 63.6 20.8 61.5 20.1 57.3 18.7
0.0 -0.774.222.870.021.465.820.163.619.461.518.857.317.5
3.0 2.2 74.2 21.4 70.0 20.1 65.8 18.9 63.6 18.3 61.5 17.7 57.3 16.5
5.0 4.1 74.2 20.5 70.0 19.3 65.8 18.2 63.6 17.6 61.5 17.0 57.3 15.9
7.0 6.0 74.2 19.8 70.0 18.6 65.8 17.5 63.6 17.0 61.5 16.4 57.3 15.3
9.0 7.9 74.2 19.1 70.0 18.0 65.8 16.9 63.6 16.4 61.5 15.8 57.3 14.8
11.0 9.8 74.218.470.017.465.816.463.615.861.515.357.314.3
13.0 11.8 74.2 17.8 70.0 16.8 65.8 15.8 63.6 15.3 61.5 14.8 57.3 13.9
15.0 13.7 74.2 17.2 70.0 16.3 65.8 15.3 63.6 14.9 61.5 14.4 57.3 13.5
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
