• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
32
3 Capacity tables
3-1 Cooling capacity
3-1-5 14HP
14HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 455 10 35.16.5441.98.0048.69.5252.09.7253.09.5254.39.1255.68.71
12 35.16.6641.98.1548.69.7051.79.6752.49.4753.69.0654.98.92
14 35.16.7841.98.3148.69.8251.09.6251.79.4152.99.3454.29.43
16 35.16.9241.98.4748.69.7750.49.7051.09.7552.39.8453.59.94
18 35.17.0541.98.6448.610.149.710.250.310.251.610.352.810.4
20 35.17.1941.99.2048.410.649.010.749.610.750.910.952.211.0
21 35.17.3941.99.5448.010.948.710.949.311.050.611.151.811.2
23 35.17.9241.910.247.311.448.011.448.611.549.911.651.111.7
25 35.18.4641.910.946.711.947.311.947.912.049.212.150.512.3
27 35.19.0441.911.746.012.446.612.547.212.548.512.649.812.8
29 35.19.6541.912.545.312.945.913.046.613.047.813.249.113.3
31 35.1 10.3 41.9 13.2 44.6 13.4 45.2 13.5 45.9 13.5 47.1 13.7 48.4 13.8
33 35.1 11.0 41.9 13.7 43.9 13.9 44.6 14.0 45.2 14.1 46.5 14.2 47.7 14.4
35 35.1 11.7 41.9 14.2 43.2 14.4 43.9 14.5 44.5 14.6 45.8 14.7 47.0 14.9
37 35.1 12.4 41.3 14.7 42.6 14.9 43.2 15.0 43.8 15.1 45.1 15.3 46.4 15.4
39 35.1 13.2 40.6 15.3 41.9 15.4 42.5 15.5 43.1 15.6 44.4 15.8 45.7 16.0
120 420 10 32.45.9738.67.3044.98.6848.09.3851.19.7753.49.4154.69.03
12 32.46.0838.67.4344.98.8448.09.5651.19.7252.79.3553.98.97
14 32.46.2038.67.5844.99.0148.09.7450.99.6752.09.2953.29.36
16 32.46.3138.67.7244.99.1948.09.8150.29.6951.49.7852.59.86
18 32.46.4438.67.8844.99.5048.010.149.510.250.710.351.910.4
20 32.46.5638.68.1944.910.248.010.648.810.750.010.851.210.9
21 32.46.6338.68.4844.910.647.910.948.510.949.711.050.811.1
23 32.47.0838.69.0944.911.347.211.447.811.449.011.550.111.6
25 32.47.5638.69.7244.911.846.511.947.111.948.312.049.512.2
27 32.48.0838.610.444.912.345.912.446.412.447.612.648.812.7
29 32.48.6138.611.144.612.845.212.945.812.946.913.148.113.2
31 32.49.1838.611.943.913.344.513.445.113.446.213.647.413.7
33 32.49.7838.612.643.213.843.813.944.414.045.614.146.714.2
35 32.4 10.4 38.6 13.5 42.5 14.3 43.1 14.4 43.7 14.5 44.9 14.6 46.0 14.8
37 32.4 11.1 38.6 14.4 41.9 14.8 42.4 14.9 43.0 15.0 44.2 15.1 45.4 15.3
39 32.4 11.8 38.6 15.2 41.2 15.3 41.8 15.4 42.3 15.5 43.5 15.7 44.7 15.8
110 385 10 29.75.4335.46.6141.17.8544.08.4846.99.1252.59.6953.69.35
12 29.75.5235.46.7341.17.9944.08.6446.99.3051.89.6452.99.29
14 29.75.6235.46.8641.18.1544.08.8146.99.4751.29.5852.29.29
16 29.75.7335.46.9941.18.3144.08.9846.99.6650.59.7151.59.79
18 29.75.8435.47.1341.18.4744.09.2346.910.149.810.250.910.3
20 29.75.9535.47.2741.18.9744.09.9146.910.649.110.750.210.8
21 29.76.0135.47.4941.19.2944.010.346.910.948.811.049.811.0
23 29.76.2935.48.0241.19.9644.011.046.911.448.111.549.211.6
25 29.76.7235.48.5841.110.744.011.846.311.947.412.048.512.1
27 29.77.1735.49.1641.111.444.012.345.612.446.712.547.812.6
29 29.77.6435.49.7841.112.244.012.845.012.946.013.047.113.1
31 29.78.1335.410.441.113.043.713.344.313.445.313.546.413.6
33 29.78.6635.411.141.113.743.113.843.613.944.714.045.714.1
35 29.79.2135.411.841.114.242.414.342.914.444.014.545.114.6
37 29.79.7935.412.641.114.741.714.842.214.943.315.044.415.2
39 29.7 10.4 35.4 13.4 40.5 15.2 41.0 15.3 41.5 15.4 42.6 15.5 43.7 15.7
100 350 10.0 27.0 4.89 32.2 5.93 37.4 7.03 40.0 7.60 42.6 8.17 47.8 9.34 52.6 9.66
12.0 27.0 4.98 32.2 6.04 37.4 7.16 40.0 7.74 42.6 8.32 47.8 9.51 51.9 9.61
14.0 27.0 5.07 32.2 6.15 37.4 7.30 40.0 7.89 42.6 8.48 47.8 9.69 51.2 9.56
16.0 27.0 5.16 32.2 6.27 37.4 7.44 40.0 8.04 42.6 8.65 47.8 9.82 50.5 9.72
18.0 27.0 5.26 32.2 6.39 37.4 7.59 40.0 8.20 42.6 8.82 47.8 10.1 49.9 10.2
20.0 27.0 5.36 32.2 6.52 37.4 7.81 40.0 8.61 42.6 9.45 47.8 10.6 49.2 10.7
21.0 27.0 5.41 32.2 6.58 37.4 8.09 40.0 8.92 42.6 9.79 47.8 10.9 48.8 11.0
23.027.05.5532.27.0237.48.6740.09.5642.610.547.211.448.211.5
25.0 27.0 5.92 32.2 7.50 37.4 9.27 40.0 10.23 42.6 11.2 46.5 11.9 47.5 12.0
27.0 27.0 6.31 32.2 8.01 37.4 9.91 40.0 10.94 42.6 12.0 45.8 12.4 46.8 12.5
29.0 27.0 6.72 32.2 8.54 37.4 10.6 40.0 11.69 42.6 12.8 45.1 12.9 46.1 13.0
31.0 27.0 7.15 32.2 9.10 37.4 11.3 40.0 12.48 42.6 13.3 44.5 13.4 45.4 13.5
33.0 27.0 7.61 32.2 9.69 37.4 12.0 40.0 13.32 42.6 13.8 43.8 13.9 44.7 14.0
35.0 27.0 8.08 32.2 10.3 37.4 12.8 40.0 14.24 42.1 14.3 43.1 14.4 44.1 14.5
37.0 27.0 8.59 32.2 11.0 37.4 13.7 40.0 14.70 41.4 14.8 42.4 14.9 43.4 15.0
39.0 27.0 9.12 32.2 11.7 37.4 14.6 40.0 15.20 40.7 15.3 41.7 15.4 42.7 15.6
