Daikin RXYQ22M7W1B [150/182] Capacity tables
![Daikin RXYQ22M7W1B [150/182] Capacity tables](/views2/1707499/page150/bg96.png)
18
3
• Systems • Outdoor Units
149
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-22 48HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
130 1,560
-19.8 -20.0 79.6 16.4 79.2 18.6 78.9 20.8 78.7 21.9 78.5 23.0 78.2 25.2
-18.8 -19.0 82.4 17.8 82.0 19.9 81.7 22.1 81.5 23.1 81.3 24.2 81.0 26.3
-16.7 -17.0 87.9 20.3 87.6 22.3 87.2 24.3 87.1 25.3 86.9 26.3 86.6 28.3
-14.7 -15.0 93.5 22.6 93.1 24.4 92.8 26.3 92.6 27.2 92.5 28.2 92.1 30.1
-12.6 -13.0 99.1 24.5 98.7 26.3 98.4 28.1 98.2 28.9 98.0 29.8 97.7 31.6
-10.5 -11.0 105 26.3 104 28.0 104 29.6 104 30.4 104 31.3 103 32.9
-9.5 -10.0 107 27.1 107 28.7 107 30.3 107 31.1 106 31.9 106 33.5
-8.5 -9.1 110 27.8 110 29.4 109 30.9 109 31.7 109 32.5 109 34.1
-7.0 -7.6 114 28.9 114 30.4 113 31.9 113 32.6 113 33.4 113 34.9
-5.0 -5.6 120 30.2 119 31.6 119 33.0 119 33.8 119 34.5 118 35.9
-3.0 -3.7 125 31.3 125 32.7 124 34.0 124 34.7 124 35.4 124 36.8
0.0 -0.7 133 32.9 133 34.2 133 35.5 132 36.1 132 36.8 132 38.0
3.0 2.2 141 34.3 141 35.5 141 36.7 140 37.3 140 37.9 140 39.1
5.0 4.1 147 35.1 146 36.2 146 37.4 146 38.0 146 38.6 145 39.7
7.0 6.0 152 35.8 152 36.9 151 38.1 151 38.6 151 39.2 151 40.3
9.0 7.9 157 36.5 157 37.6 157 38.7 156 39.2 156 39.8 156 40.8
11.0 9.8 162 37.2 162 38.2 162 39.3 162 39.8 161 40.3 161 41.3
13.0 11.8 168 37.8 168 38.8 167 39.8 167 40.3 167 40.8 167 41.8
15.0 13.7 173 38.4 173 39.4 173 40.3 172 40.8 172 41.3 170 41.5
120 1,440
-19.8 -20.0 79.1 19.4 78.8 21.4 78.5 23.5 78.3 24.5 78.2 25.5 77.8 27.6
-18.8 -19.0 81.9 20.7 81.6 22.7 81.3 24.6 81.1 25.6 80.9 26.6 80.6 28.6
-16.7 -17.0 87.5 23.0 87.1 24.9 86.8 26.7 86.7 27.6 86.5 28.6 86.2 30.4
-14.7 -15.0 93.0 25.1 92.7 26.8 92.4 28.6 92.2 29.4 92.1 30.3 91.8 32.0
-12.6 -13.0 98.6 26.9 98.3 28.5 98.0 30.2 97.8 31.0 97.6 31.8 97.3 33.4
-10.5 -11.0 104 28.5 104 30.1 104 31.6 103 32.4 103 33.1 103 34.7
-9.5 -10.0 107 29.3 107 30.8 106 32.3 106 33.0 106 33.7 106 35.2
-8.5 -9.1 109 29.9 109 31.4 109 32.8 109 33.5 108 34.3 108 35.7
-7.0 -7.6 114 30.9 113 32.3 113 33.7 113 34.4 113 35.1 112 36.5
-5.0 -5.6 119 32.1 119 33.4 119 34.8 118 35.4 118 36.1 118 37.4
-3.0 -3.7 124 33.2 124 34.4 124 35.7 124 36.3 124 37.0 123 38.2
0.0 -0.7 133 34.6 132 35.8 132 37.0 132 37.6 132 38.2 132 39.4
3.0 2.2 141 35.9 141 37.0 140 38.1 140 38.7 140 39.2 140 40.4
5.0 4.1 146 36.6 146 37.7 146 38.8 145 39.3 145 39.9 145 40.9
7.0 6.0 151 37.3 151 38.4 151 39.4 151 39.9 151 40.4 150 41.5
9.0 7.9 157 38.0 156 39.0 156 40.0 156 40.5 156 41.0 155 42.0
11.0 9.8 162 38.6 162 39.5 161 40.5 161 41.0 161 41.5 157 40.9
13.0 11.8 168 39.2 167 40.1 167 41.0 167 41.5 167 42.0 157 39.2
15.0 13.7 173 39.7 173 40.6 172 41.5 172 42.0 168 41.1 157 37.8
110 1,320
-19.8 -20.0 78.7 22.4 78.4 24.2 78.1 26.1 77.9 27.1 77.8 28.0 77.5 29.9
-18.8 -19.0 81.4 23.6 81.1 25.4 80.9 27.2 80.7 28.1 80.6 29.0 80.3 30.8
-16.7 -17.0 87.0 25.7 86.7 27.4 86.4 29.1 86.3 30.0 86.1 30.8 85.8 32.5
-14.7 -15.0 92.6 27.6 92.3 29.2 92.0 30.8 91.8 31.6 91.7 32.4 91.4 33.9
-12.6 -13.0 98.1 29.3 97.8 30.8 97.5 32.3 97.4 33.0 97.3 33.8 97.0 35.2
-10.5 -11.0 104 30.8 103 32.2 103 33.6 103 34.3 103 35.0 103 36.4
-9.5 -10.0 106 31.5 106 32.8 106 34.2 106 34.9 106 35.5 105 36.9
-8.5 -9.1 109 32.0 109 33.4 108 34.7 108 35.4 108 36.0 108 37.4
-7.0 -7.6 113 32.9 113 34.2 113 35.5 112 36.1 112 36.8 112 38.1
-5.0 -5.6 119 34.1 118 35.3 118 36.5 118 37.1 118 37.7 118 38.9
-3.0 -3.7 124 35.0 124 36.2 123 37.3 123 37.9 123 38.5 123 39.7
0.0 -0.7 132 36.4 132 37.5 132 38.5 132 39.1 131 39.6 131 40.7
3.0 2.2 140 37.5 140 38.5 140 39.6 140 40.1 140 40.6 139 41.6
5.0 4.1 146 38.2 145 39.2 145 40.2 145 40.7 145 41.2 144 41.8
7.0 6.0 151 38.8 151 39.8 150 40.7 150 41.2 150 41.7 144 40.0
9.0 7.9 156 39.4 156 40.4 156 41.3 156 41.7 154 41.8 144 38.4
11.0 9.8 162 40.0 161 40.9 161 41.8 160 41.7 154 40.1 144 36.9
13.0 11.8 167 40.5 167 41.4 165 41.6 160 40.1 154 38.5 144 35.4
15.0 13.7 172 41.0 172 41.8 165 40.1 160 38.6 154 37.1 144 34.2
100 1,200
-19.8 -20.0 78.2 25.4 77.9 27.1 77.7 28.8 77.5 29.6 77.4 30.5 77.1 32.2
-18.8 -19.0 81.0 26.5 80.7 28.1 80.4 29.7 80.3 30.6 80.2 31.4 79.9 33.0
-16.7 -17.0 86.5 28.4 86.3 30.0 86.0 31.5 85.9 32.3 85.7 33.0 85.5 34.6
-14.7 -15.0 92.1 30.2 91.8 31.6 91.6 33.0 91.4 33.7 91.3 34.5 91.0 35.9
-12.6 -13.0 97.7 31.7 97.4 33.0 97.1 34.4 97.0 35.0 96.9 35.7 96.6 37.1
-10.5 -11.0 103 33.0 103 34.3 103 35.6 103 36.2 102 36.8 102 38.1
-9.5 -10.0 106 33.6 106 34.9 105 36.1 105 36.7 105 37.4 105 38.6
-8.5 -9.1 109 34.2 108 35.4 108 36.6 108 37.2 108 37.8 107 39.0
-7.0 -7.6 113 35.0 112 36.2 112 37.3 112 37.9 112 38.5 112 39.6
-5.0 -5.6 118 36.0 118 37.1 118 38.2 118 38.8 117 39.3 117 40.4
-3.0 -3.7 124 36.9 123 37.9 123 39.0 123 39.5 123 40.0 122 41.1
0.0 -0.7 132 38.1 132 39.1 131 40.1 131 40.6 131 41.1 131 42.0
3.0 2.2 140 39.2 140 40.1 139 41.0 139 41.5 139 41.9 131 39.1
5.0 4.1 145 39.8 145 40.7 145 41.6 145 42.0 140 40.6 131 37.4
7.0 6.0 151 40.4 150 41.2
150 42.1 145 40.5 140 38.9 131 35.8
9.0 7.9 156 40.9 156 41.7 150 40.4 145 38.8 140 37.3 131 34.4
11.0 9.8 161 41.4 160 41.7 150 38.8 145 37.3 140 35.9 131 33.1
13.0 11.8 167 41.9 160 40.0 150 37.2 145 35.8 140 34.5 131 31.8
15.0 13.7 169 41.3 160 38.6 150 35.9 145 34.5 140 33.2 131 30.7
