• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
118
3 Capacity tables
3-2 Heating capacity
3-2-11 26HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 325
-19.8 -20.0 42.0 23.0 41.9 23.5 40.8 23.0 39.4 22.2 38.1 21.3 35.5 19.6
-18.8 -19.0 43.5 23.3 43.4 23.7 40.8 22.0 39.4 21.2 38.1 20.4 35.5 18.8
-16.7 -17.0 46.0 23.4 43.4 21.8 40.8 20.3 39.4 19.6 38.1 18.8 35.5 17.4
-14.7 -15.0 46.0 21.7 43.4 20.2 40.8 18.8 39.4 18.1 38.1 17.5 35.5 16.1
-12.6 -13.0 46.0 20.2 43.4 18.8 40.8 17.6 39.4 16.9 38.1 16.3 35.5 15.1
-10.5 -11.0 46.0 18.9 43.4 17.7 40.8 16.5 39.4 15.9 38.1 15.3 35.5 14.2
-9.5-10.046.018.343.417.140.816.039.415.438.114.935.513.8
-8.5 -9.1 46.0 17.8 43.4 16.7 40.8 15.6 39.4 15.0 38.1 14.5 35.5 13.4
-7.0 -7.6 46.0 17.0 43.4 15.9 40.8 14.9 39.4 14.4 38.1 13.9 35.5 12.9
-5.0 -5.6 46.0 16.1 43.4 15.1 40.8 14.1 39.4 13.6 38.1 13.2 35.5 12.2
-3.0 -3.7 46.0 15.3 43.4 14.4 40.8 13.5 39.4 13.0 38.1 12.6 35.5 11.7
0.0 -0.746.014.243.413.440.812.539.412.138.111.735.510.9
3.0 2.2 46.0 13.4 43.4 12.6 40.8 11.8 39.4 11.4 38.1 11.0 35.5 10.3
5.0 4.1 46.0 12.8 43.4 12.1 40.8 11.3 39.4 11.0 38.1 10.6 35.5 9.91
7.0 6.0 46.0 12.4 43.4 11.6 40.8 10.9 39.4 10.6 38.1 10.2 35.5 9.57
9.0 7.9 46.0 11.9 43.4 11.2 40.8 10.6 39.4 10.2 38.1 9.90 35.5 9.25
11.0 9.8 46.011.543.410.940.810.239.49.9038.19.5835.58.96
13.0 11.8 46.0 11.1 43.4 10.5 40.8 9.88 39.4 9.57 38.1 9.27 35.5 8.67
15.0 13.7 46.0 10.8 43.4 10.2 40.8 9.58 39.4 9.29 38.1 9.00 35.5 8.42
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
