Daikin RXYQ22M7W1B [82/182] Capacity tables
![Daikin RXYQ44M7W1B [82/182] Capacity tables](/views2/1707499/page82/bg52.png)
18
3
• Systems • Outdoor Units
81
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-21 46HP
46HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90 1,035 10 78.4 14.0 93.5 16.9 109 20.0 116 21.5 124 23.1 139 26.4 154 29.8
12 78.4 14.3 93.5 17.2 109 20.3 116 21.9 124 23.6 139 26.9 154 30.4
14 78.4 14.5 93.5 17.5 109 20.7 116 22.4 124 24.0 139 27.5 154 30.9
16 78.4 14.8 93.5 17.8 109 21.1 116 22.8 124 24.5 139 28.0 154 31.5
18 78.4 15.0 93.5 18.2 109 21.5 116 23.2 124 25.0 139 28.6 154 32.4
20 78.4 15.3 93.5 18.5 109 21.9 116 23.7 124 25.9 139 30.7 154 34.0
21 78.4 15.4 93.5 18.7 109 22.3 116 24.5 124 26.8 139 31.8 154 34.8
23 78.4 15.7 93.5 19.5 109 23.9 116 26.3 124 28.8 139 34.1 152 36.4
25 78.4 16.6 93.5 20.8 109 25.5 116 28.1 124 30.8 139 36.5 150 38.0
27 78.4 17.6 93.5 22.2 109 27.3 116 30.0 124 32.9 139 39.1 148 39.6
29 78.4 18.8 93.5 23.6 109 29.1 116 32.0 124 35.1 139 40.9 146 41.2
31 78.4 20.0 93.5 25.2 109 31.0 116 34.2 124 37.5 139 42.5 143 42.8
33 78.4 21.2 93.5 26.8 109 33.0 116 36.4 124 40.0 138 44.1 141 44.4
35 78.4 22.5 93.5 28.5 109 35.2 116 38.8 124 42.6 136 45.7 139 46.0
37 78.4 23.9 93.5 30.3 109 37.5 116 41.3 124 45.4 134 47.3 137 47.7
39 78.4 25.3 93.5 32.2 109 39.9 116 44.0 124 48.4 131 48.9 134 49.3
80 920 10 69.6 12.4 83.1 14.9 96.5 17.5 103 18.9 110 20.2 123 23.1 137 26.0
12 69.6 12.6 83.1 15.2 96.5 17.8 103 19.2 110 20.6 123 23.5 137 26.5
14 69.6 12.9 83.1 15.4 96.5 18.1 103 19.6 110 21.0 123 24.0 137 27.0
16 69.6 13.1 83.1 15.7 96.5 18.5 103 19.9 110 21.4 123 24.4 137 27.5
18 69.6 13.3 83.1 16.0 96.5 18.8 103 20.3 110 21.8 123 24.9 137 28.1
20 69.6 13.5 83.1 16.3 96.5 19.2 103 20.7 110 22.3 123 25.8 137 30.0
21 69.6 13.7 83.1 16.4 96.5 19.4 103 20.9 110 22.7 123 26.7 137 31.1
23 69.6 13.9 83.1 16.8 96.5 20.3 103 22.3 110 24.3 123 28.6 137 33.4
25 69.6 14.4 83.1 17.8 96.5 21.7 103 23.8 110 26.0 123 30.7 137 35.7
27 69.6 15.3 83.1 19.0 96.5 23.2 103 25.4 110 27.8 123 32.8 137 38.2
29 69.6 16.2 83.1 20.2 96.5 24.7 103 27.1 110 29.6 123 35.0 137 40.8
31 69.6 17.2 83.1 21.5 96.5 26.3 103 28.9 110 31.6 123 37.3 137 42.4
33 69.6 18.3 83.1 22.9 96.5 28.0 103 30.8 110 33.6 123 39.8 137 44.0
35 69.6 19.4 83.1 24.3 96.5 29.8 103 32.7 110 35.8 123 42.5 136 45.6
37 69.6 20.6 83.1 25.8 96.5 31.7 103 34.8 110 38.1 123 45.3 133 47.2
39 69.6 21.8 83.1 27.4 96.5 33.7 103 37.0 110 40.6 123 48.2 131 48.9
70 805 10 60.9 10.9 72.7 13.0 84.4 15.2 90.3 16.3 96.2 17.4 108 19.8 120 22.3
12 60.9 11.1 72.7 13.2 84.4 15.4 90.3 16.6 96.2 17.8 108 20.2 120 22.7
14 60.9 11.3 72.7 13.4 84.4 15.7 90.3 16.9 96.2 18.1 108 20.6 120 23.1
16 60.9 11.5 72.7 13.6 84.4 16.0 90.3 17.2 96.2 18.4 108 21.0 120 23.6
18 60.9 11.6 72.7 13.9 84.4 16.3 90.3 17.5 96.2 18.8 108 21.4 120 24.1
20 60.9 11.8 72.7 14.1 84.4 16.6 90.3 17.8 96.2 19.1 108 21.8 120 24.7
21 60.9 11.9 72.7 14.3 84.4 16.7 90.3 18.0 96.2 19.3 108 22.1 120 25.6
23 60.9 12.2 72.7 14.5 84.4 17.1 90.3 18.6 96.2 20.2 108 23.7 120 27.4
25 60.9 12.4 72.7 15.1 84.4 18.2 90.3 19.9 96.2 21.6 108 25.3 120 29.3
27 60.9 13.1 72.7 16.1 84.4 19.4 90.3 21.2 96.2 23.1 108 27.0 120 31.4
29 60.9 13.9 72.7 17.1 84.4 20.7 90.3 22.6 96.2 24.6 108 28.9 120 33.5
31 60.9 14.7 72.7 18.2 84.4 22.0 90.3 24.0 96.2 26.2 108 30.8 120 35.7
33 60.9 15.6 72.7 19.3 84.4 23.4 90.3 25.6 96.2 27.9 108 32.8 120 38.1
35 60.9 16.5 72.7 20.4 84.4 24.8 90.3 27.2 96.2 29.6 108 34.9 120 40.6
37 60.9 17.5 72.7 21.7 84.4 26.4 90.3 28.9 96.2 31.5 108 37.1 120 43.2
39 60.9 18.5 72.7 23.0 84.4 28.0 90.3 30.7 96.2 33.5 108 39.5 120 46.1
60 690 10 52.29.5262.311.272.412.977.413.882.414.892.516.710318.7
12 52.29.6562.311.372.413.177.414.182.415.092.517.010319.1
14 52.29.7962.311.572.413.477.414.382.415.392.517.310319.4
16 52.29.9462.311.772.413.677.414.682.415.692.517.610319.8
18 52.2 10.1 62.3 11.9 72.4 13.8 77.4 14.8 82.4 15.9 92.5 18.0 103 20.2
20 52.2 10.2 62.3 12.1 72.4 14.1 77.4 15.1 82.4 16.1 92.5 18.3 103 20.6
21 52.2 10.3 62.3 12.2 72.4 14.2 77.4 15.2 82.4 16.3 92.5 18.5 103 20.8
23 52.2 10.5 62.3 12.4 72.4 14.5 77.4 15.5 82.4 16.6 92.5 19.2 103 22.1
25 52.2 10.7 62.3 12.6 72.4 15.0 77.4 16.3 82.4 17.7 92.5 20.5 103 23.6
27 52.2 11.1 62.3 13.4 72.4 16.0 77.4 17.4 82.4 18.8 92.5 21.9 103 25.2
29 52.2 11.7 62.3 14.2 72.4 17.0 77.4 18.5 82.4 20.0 92.5 23.3 103 26.9
31 52.2 12.4 62.3 15.1 72.4 18.1 77.4 19.6 82.4 21.3 92.5 24.8 103 28.6
33 52.2 13.1 62.3 16.0 72.4 19.2 77.4 20.9 82.4 22.6 92.5 26.4 103 30.5
35 52.2 13.9 62.3 16.9 72.4 20.3 77.4 22.2 82.4 24.0 92.5 28.1 103 32.4
37 52.2 14.7 62.3 17.9 72.4 21.6 77.4 23.5 82.4 25.5 92.5 29.9 103 34.5
39 52.2 15.5 62.3 19.0 72.4 22.9 77.4 24.9 82.4 27.1 92.5 31.7 103 36.7
