Daikin RXYQ22M7W1B [116/182] Capacity tables
![Daikin RXYQ22M7W1B [116/182] Capacity tables](/views2/1707499/page116/bg74.png)
18
3
• Systems • Outdoor Units
115
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-10 24HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 300
-19.8 -20.0 41.3 23.7 40.7 23.6 38.3 21.9 37.0 21.1 35.8 20.2 33.3 18.6
-18.8 -19.0 42.9 24.0 40.7 22.6 38.3 21.0 37.0 20.2 35.8 19.4 33.3 17.9
-16.7 -17.0 43.2 22.3 40.7 20.8 38.3 19.3 37.0 18.6 35.8 17.9 33.3 16.5
-14.7 -15.0 43.2 20.6 40.7 19.2 38.3 17.9 37.0 17.3 35.8 16.6 33.3 15.3
-12.6 -13.0 43.2 19.2 40.7 17.9 38.3 16.7 37.0 16.1 35.8 15.5 33.3 14.3
-10.5 -11.0 43.2 17.9 40.7 16.8 38.3 15.7 37.0 15.1 35.8 14.6 33.3 13.5
-9.5-10.043.217.440.716.338.315.237.014.735.814.133.313.1
-8.5 -9.1 43.2 16.9 40.7 15.8 38.3 14.8 37.0 14.3 35.8 13.8 33.3 12.8
-7.0 -7.6 43.2 16.2 40.7 15.2 38.3 14.2 37.0 13.7 35.8 13.2 33.3 12.2
-5.0 -5.6 43.2 15.3 40.7 14.4 38.3 13.4 37.0 13.0 35.8 12.5 33.3 11.6
-3.0 -3.7 43.2 14.6 40.7 13.7 38.3 12.8 37.0 12.4 35.8 11.9 33.3 11.1
0.0 -0.743.213.540.712.738.311.937.011.535.811.133.310.4
3.0 2.2 43.2 12.7 40.7 11.9 38.3 11.2 37.0 10.8 35.8 10.5 33.3 9.77
5.0 4.1 43.2 12.2 40.7 11.5 38.3 10.8 37.0 10.4 35.8 10.1 33.3 9.42
7.0 6.0 43.2 11.7 40.7 11.1 38.3 10.4 37.0 10.1 35.8 9.74 33.3 9.09
9.0 7.9 43.2 11.3 40.7 10.7 38.3 10.0 37.0 9.72 35.8 9.41 33.3 8.79
11.0 9.8 43.210.940.710.338.39.7137.09.4135.89.1133.38.52
13.0 11.8 43.2 10.6 40.7 9.98 38.3 9.39 37.0 9.10 35.8 8.81 33.3 8.25
15.0 13.7 43.2 10.2 40.7 9.67 38.3 9.11 37.0 8.83 35.8 8.55 33.3 8.01
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
