• Systems • Outdoor Units
25
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-2 8HP
8HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
50 100 10 7.561.259.021.4510.51.6611.21.7711.91.8813.42.1114.82.36
12 7.56 1.27 9.02 1.47 10.5 1.69 11.2 1.80 11.9 1.91 13.4 2.15 14.8 2.40
14 7.56 1.29 9.02 1.49 10.5 1.71 11.2 1.83 11.9 1.94 13.4 2.19 14.8 2.44
16 7.56 1.31 9.02 1.52 10.5 1.74 11.2 1.86 11.9 1.98 13.4 2.22 14.8 2.48
18 7.56 1.32 9.02 1.54 10.5 1.77 11.2 1.89 11.9 2.01 13.4 2.26 14.8 2.53
20 7.56 1.34 9.02 1.56 10.5 1.80 11.2 1.92 11.9 2.05 13.4 2.31 14.8 2.58
21 7.56 1.35 9.02 1.58 10.5 1.81 11.2 1.94 11.9 2.06 13.4 2.33 14.8 2.60
23 7.56 1.37 9.02 1.60 10.5 1.85 11.2 1.97 11.9 2.10 13.4 2.37 14.8 2.65
25 7.56 1.39 9.02 1.63 10.5 1.88 11.2 2.01 11.9 2.15 13.4 2.47 14.8 2.81
27 7.56 1.42 9.02 1.68 10.5 1.97 11.2 2.13 11.9 2.29 13.4 2.63 14.8 3.01
29 7.56 1.49 9.02 1.78 10.5 2.09 11.2 2.26 11.9 2.44 13.4 2.81 14.8 3.21
31 7.56 1.58 9.02 1.89 10.5 2.22 11.2 2.40 11.9 2.59 13.4 2.99 14.8 3.42
33 7.56 1.67 9.02 2.00 10.5 2.36 11.2 2.55 11.9 2.75 13.4 3.18 14.8 3.64
35 7.56 1.76 9.02 2.12 10.5 2.50 11.2 2.71 11.9 2.92 13.4 3.38 14.8 3.87
37 7.56 1.86 9.02 2.24 10.5 2.65 11.2 2.87 11.9 3.10 13.4 3.59 14.8 4.12
39 7.56 1.97 9.02 2.37 10.5 2.81 11.2 3.05 11.9 3.29 13.4 3.81 14.8 4.38
