Daikin RXYQ22M7W1B [85/182] Capacity tables
![Daikin RXYQ22M7W1B [85/182] Capacity tables](/views2/1707499/page85/bg55.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
84
3 Capacity tables
3-1 Cooling capacity
3-1-22 48HP
48HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90 1,080 10 81.1 14.5 96.7 17.4 112 20.6 120 22.2 128 23.9 144 27.3 159 30.7
12 81.1 14.7 96.7 17.7 112 21.0 120 22.6 128 24.3 144 27.8 159 31.3
14 81.1 15.0 96.7 18.1 112 21.4 120 23.1 128 24.8 144 28.3 159 31.9
16 81.1 15.2 96.7 18.4 112 21.8 120 23.5 128 25.3 144 28.9 159 32.4
18 81.1 15.5 96.7 18.7 112 22.2 120 24.0 128 25.8 144 29.4 159 33.4
20 81.1 15.8 96.7 19.1 112 22.6 120 24.4 128 26.7 144 31.6 159 35.1
21 81.1 15.9 96.7 19.3 112 23.0 120 25.3 128 27.7 144 32.8 159 35.9
23 81.1 16.2 96.7 20.1 112 24.6 120 27.1 128 29.7 144 35.1 157 37.5
25 81.1 17.1 96.7 21.5 112 26.3 120 29.0 128 31.7 144 37.6 155 39.2
27 81.1 18.2 96.7 22.9 112 28.1 120 30.9 128 33.9 144 40.3 153 40.8
29 81.1 19.4 96.7 24.4 112 30.0 120 33.0 128 36.2 144 42.2 151 42.5
31 81.1 20.6 96.7 26.0 112 32.0 120 35.2 128 38.7 144 43.8 148 44.1
33 81.1 21.9 96.7 27.6 112 34.1 120 37.6 128 41.2 143 45.4 146 45.8
35 81.1 23.2 96.7 29.4 112 36.3 120 40.0 128 44.0 141 47.1 144 47.5
37 81.1 24.6 96.7 31.2 112 38.6 120 42.6 128 46.8 139 48.8 141 49.2
39 81.1 26.1 96.7 33.2 112 41.1 120 45.4 127 49.9 129 50.4 132 50.8
80 960 10 72.1 12.8 86.0 15.4 99.9 18.1 107 19.4 114 20.9 128 23.8 142 26.8
12 72.1 13.0 86.0 15.6 99.9 18.4 107 19.8 114 21.3 128 24.2 142 27.3
14 72.1 13.3 86.0 15.9 99.9 18.7 107 20.2 114 21.7 128 24.7 142 27.8
16 72.1 13.5 86.0 16.2 99.9 19.1 107 20.6 114 22.1 128 25.2 142 28.4
18 72.1 13.7 86.0 16.5 99.9 19.4 107 20.9 114 22.5 128 25.7 142 28.9
20 72.1 14.0 86.0 16.8 99.9 19.8 107 21.4 114 22.9 128 26.6 142 31.0
21 72.1 14.1 86.0 17.0 99.9 20.0 107 21.6 114 23.4 128 27.6 142 32.1
23 72.1 14.3 86.0 17.3 99.9 21.0 107 23.0 114 25.1 128 29.5 142 34.4
25 72.1 14.8 86.0 18.4 99.9 22.4 107 24.5 114 26.8 128 31.6 142 36.8
27 72.1 15.7 86.0 19.6 99.9 23.9 107 26.2 114 28.6 128 33.8 142 39.4
29 72.1 16.7 86.0 20.9 99.9 25.5 107 27.9 114 30.5 128 36.1 142 42.1
31 72.1 17.8 86.0 22.2 99.9 27.1 107 29.8 114 32.6 128 38.5 142 43.8
33 72.1 18.9 86.0 23.6 99.9 28.9 107 31.7 114 34.7 128 41.1 142 45.4
35 72.1 20.0 86.0 25.1 99.9 30.7 107 33.8 114 37.0 128 43.8 140 47.1
37 72.1 21.2 86.0 26.6 99.9 32.7 107 35.9 114 39.3 128 46.7 138 48.7
39 72.1 22.5 86.0 28.2 99.9 34.7 107 38.2 114 41.9 128 49.7 132 50.4
70 840 10 63.1 11.3 75.2 13.4 87.4 15.6 93.5 16.8 99.5 18.0 112 20.4 124 23.0
12 63.1 11.5 75.2 13.6 87.4 15.9 93.5 17.1 99.5 18.3 112 20.8 124 23.4
14 63.1 11.6 75.2 13.8 87.4 16.2 93.5 17.4 99.5 18.6 112 21.2 124 23.9
16 63.1 11.8 75.2 14.1 87.4 16.5 93.5 17.7 99.5 19.0 112 21.6 124 24.3
18 63.1 12.0 75.2 14.3 87.4 16.8 93.5 18.0 99.5 19.4 112 22.0 124 24.8
20 63.1 12.2 75.2 14.6 87.4 17.1 93.5 18.4 99.5 19.7 112 22.5 124 25.5
21 63.1 12.3 75.2 14.7 87.4 17.3 93.5 18.6 99.5 19.9 112 22.8 124 26.4
23 63.1 12.5 75.2 15.0 87.4 17.6 93.5 19.2 99.5 20.9 112 24.4 124 28.3
25 63.1 12.8 75.2 15.6 87.4 18.8 93.5 20.5 99.5 22.3 112 26.1 124 30.3
27 63.1 13.5 75.2 16.6 87.4 20.0 93.5 21.9 99.5 23.8 112 27.9 124 32.3
29 63.1 14.3 75.2 17.6 87.4 21.3 93.5 23.3 99.5 25.3 112 29.8 124 34.5
31 63.1 15.2 75.2 18.7 87.4 22.7 93.5 24.8 99.5 27.0 112 31.7 124 36.8
33 63.1 16.1 75.2 19.9 87.4 24.1 93.5 26.4 99.5 28.7 112 33.8 124 39.3
35 63.1 17.0 75.2 21.1 87.4 25.6 93.5 28.0 99.5 30.6 112 36.0 124 41.9
37 63.1 18.0 75.2 22.4 87.4 27.2 93.5 29.8 99.5 32.5 112 38.3 124 44.6
39 63.1 19.1 75.2 23.7 87.4 28.9 93.5 31.6 99.5 34.6 112 40.8 124 47.5
60 720 10 54.19.8164.511.574.913.380.114.385.315.295.717.210619.3
12 54.19.9564.511.774.913.580.114.585.315.595.717.510619.7
14 54.1 10.1 64.5 11.9 74.9 13.8 80.1 14.8 85.3 15.8 95.7 17.9 106 20.0
16 54.1 10.2 64.5 12.1 74.9 14.0 80.1 15.0 85.3 16.1 95.7 18.2 106 20.4
18 54.1 10.4 64.5 12.3 74.9 14.3 80.1 15.3 85.3 16.3 95.7 18.5 106 20.8
20 54.1 10.6 64.5 12.5 74.9 14.5 80.1 15.6 85.3 16.7 95.7 18.9 106 21.2
21 54.1 10.7 64.5 12.6 74.9 14.6 80.1 15.7 85.3 16.8 95.7 19.1 106 21.4
23 54.1 10.8 64.5 12.8 74.9 14.9 80.1 16.0 85.3 17.1 95.7 19.8 106 22.8
25 54.1 11.0 64.5 13.0 74.9 15.5 80.1 16.8 85.3 18.2 95.7 21.2 106 24.3
27 54.1 11.4 64.5 13.8 74.9 16.5 80.1 17.9 85.3 19.4 95.7 22.6 106 26.0
29 54.1 12.1 64.5 14.7 74.9 17.5 80.1 19.1 85.3 20.7 95.7 24.0 106 27.7
31 54.1 12.8 64.5 15.6 74.9 18.6 80.1 20.3 85.3 22.0 95.7 25.6 106 29.5
33 54.1 13.5 64.5 16.5 74.9 19.8 80.1 21.5 85.3 23.3 95.7 27.2 106 31.4
35 54.1 14.3 64.5 17.5 74.9 21.0 80.1 22.8 85.3 24.8 95.7 29.0 106 33.5
37 54.1 15.1 64.5 18.5 74.9 22.2 80.1 24.2 85.3 26.3 95.7 30.8 106 35.6
39 54.1 16.0 64.5 19.6 74.9 23.6 80.1 25.7 85.3 28.0 95.7 32.7 106 37.9
