Daikin RXYQ22M7W1B [95/182] Capacity tables
![Daikin RXYQ22M7W1B [95/182] Capacity tables](/views2/1707499/page95/bg5f.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
94
3 Capacity tables
3-2 Heating capacity
3-2-3 10HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 125
-19.8 -20.0 17.8 9.52 16.8 8.87 15.8 8.25 15.2 7.94 14.7 7.64 13.7 7.04
-18.8 -19.0 17.8 9.17 16.8 8.56 15.8 7.96 15.2 7.66 14.7 7.37 13.7 6.80
-16.7 -17.0 17.8 8.56 16.8 7.99 15.8 7.44 15.2 7.17 14.7 6.90 13.7 6.38
-14.7 -15.0 17.8 8.02 16.8 7.50 15.8 6.99 15.2 6.74 14.7 6.49 13.7 6.00
-12.6 -13.0 17.8 7.55 16.8 7.06 15.8 6.59 15.2 6.36 14.7 6.13 13.7 5.67
-10.5 -11.0 17.8 7.14 16.8 6.68 15.8 6.24 15.2 6.02 14.7 5.80 13.7 5.38
-9.5-10.017.86.9516.86.5115.86.0815.25.8714.75.6613.75.25
-8.5 -9.1 17.8 6.78 16.8 6.36 15.8 5.94 15.2 5.74 14.7 5.53 13.7 5.13
-7.0 -7.6 17.8 6.53 16.8 6.13 15.8 5.73 15.2 5.53 14.7 5.34 13.7 4.96
-5.0 -5.6 17.8 6.23 16.8 5.84 15.8 5.47 15.2 5.28 14.7 5.10 13.7 4.74
-3.0 -3.7 17.8 5.96 16.8 5.60 15.8 5.24 15.2 5.07 14.7 4.89 13.7 4.55
0.0 -0.717.85.5916.85.2615.84.9315.24.7714.74.6113.74.29
3.0 2.2 17.8 5.28 16.8 4.97 15.8 4.66 15.2 4.51 14.7 4.36 13.7 4.07
5.0 4.1 17.8 5.10 16.8 4.80 15.8 4.51 15.2 4.36 14.7 4.22 13.7 3.94
7.0 6.0 17.8 4.93 16.8 4.64 15.8 4.36 15.2 4.22 14.7 4.09 13.7 3.82
9.0 7.9 17.8 4.77 16.8 4.50 15.8 4.23 15.2 4.09 14.7 3.96 13.7 3.70
11.0 9.8 17.84.6316.84.3615.84.1015.23.9714.73.8513.73.60
13.0 11.8 17.8 4.48 16.8 4.23 15.8 3.98 15.2 3.86 14.7 3.74 13.7 3.49
15.0 13.7 17.8 4.36 16.8 4.11 15.8 3.87 15.2 3.75 14.7 3.64 13.7 3.40
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
