Daikin RXYQ22M7W1B [92/182] Capacity tables
![Daikin RXYQ22M7W1B [92/182] Capacity tables](/views2/1707499/page92/bg5c.png)
18
3
• Systems • Outdoor Units
91
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-2 8HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 100
-19.8 -20.0 14.1 7.04 13.3 6.57 12.5 6.10 12.1 5.88 11.7 5.65 10.9 5.21
-18.8 -19.0 14.1 6.79 13.3 6.33 12.5 5.89 12.1 5.67 11.7 5.46 10.9 5.04
-16.7 -17.0 14.1 6.33 13.3 5.91 12.5 5.50 12.1 5.30 11.7 5.11 10.9 4.72
-14.7 -15.0 14.1 5.94 13.3 5.55 12.5 5.17 12.1 4.98 11.7 4.80 10.9 4.44
-12.6 -13.0 14.1 5.59 13.3 5.23 12.5 4.88 12.1 4.70 11.7 4.53 10.9 4.20
-10.5 -11.0 14.1 5.28 13.3 4.95 12.5 4.62 12.1 4.46 11.7 4.30 10.9 3.98
-9.5-10.014.15.1413.34.8212.54.5012.14.3411.74.1910.93.88
-8.5 -9.1 14.1 5.02 13.3 4.71 12.5 4.40 12.1 4.24 11.7 4.09 10.9 3.80
-7.0 -7.6 14.1 4.83 13.3 4.53 12.5 4.24 12.1 4.09 11.7 3.95 10.9 3.67
-5.0 -5.6 14.1 4.61 13.3 4.32 12.5 4.05 12.1 3.91 11.7 3.77 10.9 3.51
-3.0 -3.7 14.1 4.41 13.3 4.14 12.5 3.88 12.1 3.75 11.7 3.62 10.9 3.37
0.0 -0.714.14.1413.33.8912.53.6512.13.5311.73.4110.93.18
3.0 2.2 14.1 3.91 13.3 3.68 12.5 3.45 12.1 3.34 11.7 3.23 10.9 3.01
5.0 4.1 14.1 3.77 13.3 3.55 12.5 3.34 12.1 3.23 11.7 3.12 10.9 2.91
7.0 6.0 14.1 3.65 13.3 3.44 12.5 3.23 12.1 3.13 11.7 3.02 10.9 2.82
9.0 7.9 14.1 3.53 13.3 3.33 12.5 3.13 12.1 3.03 11.7 2.93 10.9 2.74
11.0 9.8 14.13.4213.33.2312.53.0412.12.9411.72.8510.92.66
13.0 11.8 14.1 3.32 13.3 3.13 12.5 2.95 12.1 2.85 11.7 2.76 10.9 2.59
15.0 13.7 14.1 3.22 13.3 3.04 12.5 2.87 12.1 2.78 11.7 2.69 10.9 2.52
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
