Daikin RXYQ22M7W1B [75/182] Capacity tables
![Daikin RXYQ22M7W1B [75/182] Capacity tables](/views2/1707499/page75/bg4b.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
74
3 Capacity tables
3-1 Cooling capacity
3-1-19 42HP
42HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 1,365 10 103 18.5 122 22.7 142 27.0 152 27.5 155 27.0 159 25.8 163 24.7
12 103 18.9 122 23.1 142 27.5 151 27.4 153 26.8 157 25.7 161 25.3
14 103 19.2 122 23.6 142 27.8 149 27.3 151 26.7 155 26.5 159 26.7
16 103 19.6 122 24.0 142 27.7 147 27.5 149 27.6 153 27.9 157 28.2
18 103 20.0 122 24.5 142 28.8 145 28.9 147 29.0 151 29.3 155 29.6
20 103 20.4 122 26.1 141 30.2 143 30.3 145 30.5 149 30.8 153 31.1
21 103 21.0 122 27.0 140 30.9 142 31.0 144 31.2 148 31.5 152 31.8
23 103 22.4 122 29.0 138 32.3 140 32.4 142 32.6 146 32.9 150 33.3
25 103 24.0 122 31.0 136 33.7 138 33.9 140 34.0 144 34.4 148 34.7
27 103 25.6 122 33.2 134 35.1 136 35.3 138 35.5 142 35.8 146 36.2
29 103 27.3 122 35.5 132 36.5 134 36.7 136 36.9 140 37.3 144 37.7
31 103 29.2 122 37.5 130 38.0 132 38.2 134 38.4 138 38.8 142 39.2
33 103 31.1 122 38.9 128 39.4 130 39.6 132 39.8 136 40.3 140 40.7
35 103 33.1 122 40.4 126 40.8 128 41.1 130 41.3 134 41.8 138 42.2
37 103 35.3 121 41.8 123 42.3 124 42.5 125 42.8 127 43.3 129 43.7
39 103 37.5 112 43.2 114 43.7 115 44.0 116 44.2 118 44.8 120 45.3
120 1,260 10 94.8 16.9 113 20.7 131 24.6 140 26.6 150 27.7 156 26.7 160 25.6
12 94.8 17.2 113 21.1 131 25.1 140 27.1 150 27.6 154 26.5 158 25.4
14 94.8 17.6 113 21.5 131 25.5 140 27.6 149 27.4 152 26.3 156 26.5
16 94.8 17.9 113 21.9 131 26.0 140 27.8 147 27.5 150 27.7 154 28.0
18 94.8 18.2 113 22.3 131 26.9 140 28.7 145 28.9 148 29.1 152 29.4
20 94.8 18.6 113 23.2 131 28.9 140 30.1 143 30.3 146 30.5 150 30.8
21 94.8 18.8 113 24.0 131 30.0 140 30.8 142 31.0 145 31.3 149 31.5
23 94.8 20.1 113 25.7 131 32.1 138 32.2 140 32.4 143 32.7 147 33.0
25 94.8 21.4 113 27.6 131 33.5 136 33.6 138 33.8 141 34.1 145 34.5
27 94.8 22.9 113 29.5 131 34.9 134 35.1 136 35.2 139 35.6 143 35.9
29 94.8 24.4 113 31.5 130 36.3 132 36.5 134 36.7 137 37.0 141 37.4
31 94.8 26.0 113 33.6 128 37.7 130 37.9 132 38.1 135 38.5 139 38.9
33 94.8 27.7 113 35.8 126 39.1 128 39.3 130 39.5 133 40.0 137 40.4
35 94.8 29.5 113 38.2 124 40.6 126 40.8 128 41.0 131 41.4 135 41.9
37 94.8 31.4 113 40.7 122 42.0 124 42.2 125 42.5 127 42.9 129 43.4
39 94.8 33.4 112 43.0 114 43.5 115 43.7 116 43.9 118 44.4 120 44.9
110 1,155 10 86.9 15.4 104 18.7 120 22.2 129 24.0 137 25.9 154 27.4 157 26.5
12 86.9 15.6 104 19.1 120 22.7 129 24.5 137 26.3 152 27.3 155 26.3
14 86.9 15.9 104 19.4 120 23.1 129 25.0 137 26.8 150 27.2 153 26.3
16 86.9 16.2 104 19.8 120 23.5 129 25.4 137 27.4 148 27.5 151 27.7
18 86.9 16.5 104 20.2 120 24.0 129 26.1 137 28.7 146 28.9 149 29.2
20 86.9 16.9 104 20.6 120 25.4 129 28.1 137 30.1 144 30.3 147 30.6
21 86.9 17.0 104 21.2 120 26.3 129 29.1 137 30.8 143 31.0 146 31.3
23 86.9 17.8 104 22.7 120 28.2 129 31.2 137 32.2 141 32.5 144 32.7
25 86.9 19.0 104 24.3 120 30.2 129 33.4 136 33.6 139 33.9 142 34.2
27 86.9 20.3 104 26.0 120 32.3 129 34.8 134 35.0 137 35.3 140 35.6
29 86.9 21.6 104 27.7 120 34.5 129 36.3 132 36.4 135 36.8 138 37.1
31 86.9 23.0 104 29.6 120 36.9 128 37.7 130 37.8 133 38.2 136 38.5
33 86.9 24.5 104 31.5 120 38.9 126 39.1 128 39.3 131 39.6 134 40.0
35 86.9 26.1 104 33.6 120 40.3 124 40.5 126 40.7 129 41.1 132 41.5
37 86.9 27.7 104 35.7 120 41.7 122 41.9 124 42.2 127 42.6 129 43.0
39 86.9 29.5 104 38.1 114 43.2 115 43.4 116 43.6 118 44.0 120 44.5
100 1,050 10 79.0 13.9 94.2 16.8 109 19.9 117 21.5 125 23.1 140 26.5 154 27.4
12 79.0 14.1 94.2 17.1 109 20.3 117 21.9 125 23.6 140 27.0 152 27.2
14 79.0 14.4 94.2 17.4 109 20.7 117 22.3 125 24.0 140 27.5 150 27.1
16 79.0 14.6 94.2 17.8 109 21.1 117 22.8 125 24.5 140 27.8 148 27.5
18 79.0 14.9 94.2 18.1 109 21.5 117 23.2 125 25.0 140 28.7 146 28.9
20 79.0 15.2 94.2 18.5 109 22.1 117 24.4 125 26.8 140 30.1 144 30.4
21 79.0 15.3 94.2 18.7 109 22.9 117 25.3 125 27.7 140 30.8 143 31.1
23 79.0 15.7 94.2 19.9 109 24.6 117 27.1 125 29.7 138 32.2 141 32.5
25 79.0 16.8 94.2 21.3 109 26.3 117 29.0 125 31.8 136 33.6 139 33.9
27 79.0 17.9 94.2 22.7 109 28.1 117 31.0 125 34.1 134 35.1 137 35.3
29 79.0 19.0 94.2 24.2 109 30.0 117 33.1 125 36.2 132 36.5 135 36.8
31 79.0 20.3 94.2 25.8 109 32.0 117 35.4 125 37.6 130 37.9 133 38.2
33 79.0 21.6 94.2 27.5 109 34.1 117 37.7 125 39.0 128 39.3 131 39.7
35 79.0 22.9 94.2 29.2 109 36.4 117 40.2 123 40.4 126 40.8 129 41.1
37 79.0 24.3 94.2 31.1 109 38.8 117 41.7 121 41.8 124 42.2 127 42.6
39 79.0 25.8 94.2 33.1 109 41.3 115 43.1 116 43.3 118 43.7 120 44.1
