Daikin RXYQ22M7W1B [63/182] Capacity tables
![Daikin RXYQ22M7W1B [63/182] Capacity tables](/views2/1707499/page63/bg3f.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
62
3 Capacity tables
3-1 Cooling capacity
3-1-15 34HP
34HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 1,105 10 84.2 14.8 100 18.1 117 21.6 125 22.0 127 21.6 130 20.7 133 19.8
12 84.2 15.1 100 18.5 117 22.0 124 21.9 126 21.5 129 20.5 132 20.2
14 84.2 15.4 100 18.8 117 22.3 123 21.8 124 21.3 127 21.2 130 21.4
16 84.2 15.7 100 19.2 117 22.2 121 22.0 122 22.1 125 22.3 128 22.5
18 84.2 16.0 100 19.6 117 23.0 119 23.1 121 23.2 124 23.5 127 23.7
20 84.2 16.3 100 20.9 116 24.1 118 24.3 119 24.4 122 24.6 125 24.9
21 84.2 16.8 100 21.6 115 24.7 117 24.8 118 24.9 121 25.2 124 25.4
23 84.2 17.9 100 23.2 114 25.8 115 26.0 117 26.1 120 26.3 123 26.6
25 84.2 19.2 100 24.8 112 27.0 113 27.1 115 27.2 118 27.5 121 27.8
27 84.2 20.5 100 26.6 110 28.1 112 28.2 113 28.4 116 28.7 119 29.0
29 84.2 21.9 100 28.4 109 29.2 110 29.4 112 29.5 115 29.9 118 30.2
31 84.2 23.3 100 30.0 107 30.4 109 30.5 110 30.7 113 31.0 116 31.4
33 84.2 24.9 100 31.2 105 31.5 107 31.7 108 31.9 111 32.2 115 32.6
35 84.2 26.5 100 32.3 104 32.7 105 32.9 107 33.0 110 33.4 113 33.8
37 84.2 28.2 99.1 33.4 102 33.8 104 34.0 105 34.2 108 34.6 111 35.0
39 84.2 30.0 97.5 34.6 100 35.0 102 35.2 104 35.4 107 35.8 110 36.2
120 1,020 10 77.7 13.5 92.7 16.5 108 19.7 115 21.3 123 22.2 128 21.3 131 20.5
12 77.7 13.8 92.7 16.9 108 20.0 115 21.7 123 22.0 127 21.2 129 20.3
14 77.7 14.1 92.7 17.2 108 20.4 115 22.1 122 21.9 125 21.1 128 21.2
16 77.7 14.3 92.7 17.5 108 20.8 115 22.2 120 22.0 123 22.2 126 22.4
18 77.7 14.6 92.7 17.9 108 21.5 115 23.0 119 23.1 122 23.3 124 23.5
20 77.7 14.9 92.7 18.6 108 23.2 115 24.1 117 24.2 120 24.4 123 24.7
21 77.7 15.0 92.7 19.2 108 24.0 115 24.7 116 24.8 119 25.0 122 25.2
23 77.7 16.1 92.7 20.6 108 25.7 113 25.8 115 25.9 118 26.2 120 26.4
25 77.7 17.2 92.7 22.0 108 26.8 112 26.9 113 27.1 116 27.3 119 27.6
27 77.7 18.3 92.7 23.6 108 27.9 110 28.1 111 28.2 114 28.5 117 28.7
29 77.7 19.5 92.7 25.2 107 29.1 108 29.2 110 29.3 113 29.6 115 29.9
31 77.7 20.8 92.7 26.9 105 30.2 107 30.3 108 30.5 111 30.8 114 31.1
33 77.7 22.2 92.7 28.7 104 31.3 105 31.5 107 31.6 109 32.0 112 32.3
35 77.7 23.6 92.7 30.6 102 32.5 103 32.6 105 32.8 108 33.2 111 33.5
37 77.7 25.1 92.7 32.6 100 33.6 102 33.8 103 34.0 106 34.3 109 34.7
39 77.7 26.7 92.7 34.4 98.8 34.8 100 35.0 102 35.1 104 35.5 107 35.9
110 935 10 71.3 12.3 85.0 15.0 98.7 17.8 106 19.2 112 20.7 126 22.0 129 21.2
12 71.3 12.5 85.0 15.3 98.7 18.1 106 19.6 112 21.1 124 21.9 127 21.1
14 71.3 12.8 85.0 15.5 98.7 18.5 106 20.0 112 21.5 123 21.7 125 21.1
16 71.3 13.0 85.0 15.8 98.7 18.8 106 20.4 112 21.9 121 22.0 124 22.2
18 71.3 13.2 85.0 16.2 98.7 19.2 106 20.9 112 23.0 119 23.1 122 23.3
20 71.3 13.5 85.0 16.5 98.7 20.3 106 22.5 112 24.1 118 24.3 120 24.5
21 71.3 13.6 85.0 17.0 98.7 21.1 106 23.3 112 24.6 117 24.8 120 25.1
23 71.3 14.3 85.0 18.2 98.7 22.6 106 25.0 112 25.8 115 26.0 118 26.2
25 71.3 15.2 85.0 19.4 98.7 24.2 106 26.8 111 26.9 114 27.1 116 27.4
27 71.3 16.2 85.0 20.8 98.7 25.9 106 27.9 110 28.0 112 28.3 115 28.5
29 71.3 17.3 85.0 22.2 98.7 27.6 106 29.0 108 29.1 110 29.4 113 29.7
31 71.3 18.4 85.0 23.6 98.7 29.5 105 30.1 106 30.3 109 30.6 111 30.8
33 71.3 19.6 85.0 25.2 98.7 31.1 103 31.3 105 31.4 107 31.7 110 32.0
35 71.3 20.9 85.0 26.9 98.7 32.3 102 32.4 103 32.6 106 32.9 108 33.2
37 71.3 22.2 85.0 28.6 98.7 33.4 100 33.6 101 33.7 104 34.1 106 34.4
39 71.3 23.6 85.0 30.5 97.1 34.5 98.4 34.7 99.7 34.9 102 35.2 105 35.6
100 850 10 64.8 11.1 77.3 13.5 89.8 15.9 96.0 17.2 102 18.5 115 21.2 126 21.9
12 64.8 11.3 77.3 13.7 89.8 16.2 96.0 17.5 102 18.9 115 21.6 125 21.8
14 64.8 11.5 77.3 14.0 89.8 16.5 96.0 17.9 102 19.2 115 22.0 123 21.7
16 64.8 11.7 77.3 14.2 89.8 16.9 96.0 18.2 102 19.6 115 22.3 121 22.0
18 64.8 11.9 77.3 14.5 89.8 17.2 96.0 18.6 102 20.0 115 23.0 120 23.2
20 64.8 12.1 77.3 14.8 89.8 17.7 96.0 19.5 102 21.4 115 24.1 118 24.3
21 64.8 12.3 77.3 14.9 89.8 18.3 96.0 20.2 102 22.2 115 24.7 117 24.9
23 64.8 12.6 77.3 15.9 89.8 19.7 96.0 21.7 102 23.8 113 25.8 116 26.0
25 64.8 13.4 77.3 17.0 89.8 21.0 96.0 23.2 102 25.5 112 26.9 114 27.1
27 64.8 14.3 77.3 18.2 89.8 22.5 96.0 24.8 102 27.3 110 28.1 112 28.3
29 64.8 15.2 77.3 19.4 89.8 24.0 96.0 26.5 102 28.9 108 29.2 111 29.4
31 64.8 16.2 77.3 20.6 89.8 25.6 96.0 28.3 102 30.1 107 30.3 109 30.6
33 64.8 17.2 77.3 22.0 89.8 27.3 96.0 30.2 102 31.2 105 31.5 107 31.7
35 64.8 18.3 77.3 23.4 89.8 29.1 96.0 32.2 101 32.3 103 32.6 106 32.9
37 64.8 19.5 77.3 24.9 89.8 31.0 96.0 33.3 99.4 33.5 102 33.8 104 34.1
39 64.8 20.7 77.3 26.5 89.8 33.0 96.0 34.5 97.8 34.6 100 34.9 102 35.3
