Daikin RXYQ22M7W1B [70/182] Capacity tables
![Daikin RXYQ22M7W1B [70/182] Capacity tables](/views2/1707499/page70/bg46.png)
18
3
• Systems • Outdoor Units
69
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-17 38HP
38HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90 855 10 64.4 10.8 76.8 13.1 89.2 15.4 95.4 16.7 102 17.9 114 20.5 126 23.1
12 64.4 11.0 76.8 13.3 89.2 15.7 95.4 17.0 102 18.3 114 20.9 126 23.5
14 64.4 11.2 76.8 13.6 89.2 16.0 95.4 17.3 102 18.6 114 21.3 126 24.0
16 64.4 11.4 76.8 13.8 89.2 16.3 95.4 17.6 102 19.0 114 21.7 126 24.3
18 64.4 11.6 76.8 14.1 89.2 16.6 95.4 18.0 102 19.3 114 22.1 126 25.1
20 64.4 11.8 76.8 14.3 89.2 17.0 95.4 18.3 102 20.1 114 23.7 126 26.3
21 64.4 11.9 76.8 14.5 89.2 17.3 95.4 19.0 102 20.8 114 24.6 126 26.9
23 64.4 12.2 76.8 15.1 89.2 18.5 95.4 20.3 102 22.3 114 26.4 125 28.2
25 64.4 12.8 76.8 16.1 89.2 19.8 95.4 21.7 102 23.8 114 28.3 123 29.4
27 64.4 13.7 76.8 17.2 89.2 21.1 95.4 23.2 102 25.5 114 30.2 121 30.6
29 64.4 14.5 76.8 18.3 89.2 22.5 95.4 24.8 102 27.2 114 31.6 120 31.9
31 64.4 15.4 76.8 19.5 89.2 24.0 95.4 26.5 102 29.0 114 32.9 118 33.1
33 64.4 16.4 76.8 20.7 89.2 25.6 95.4 28.2 102 30.9 114 34.1 116 34.4
35 64.4 17.4 76.8 22.0 89.2 27.2 95.4 30.0 102 33.0 112 35.4 114 35.6
37 64.4 18.5 76.8 23.4 89.2 29.0 95.4 32.0 102 35.2 110 36.6 112 36.9
39 64.4 19.6 76.8 24.9 89.2 30.9 95.4 34.1 102 37.5 108 37.9 111 38.2
80 760 10 57.2 9.63 68.3 11.5 79.3 13.5 84.8 14.6 90.3 15.7 101 17.9 112 20.1
12 57.2 9.78 68.3 11.7 79.3 13.8 84.8 14.9 90.3 16.0 101 18.2 112 20.5
14 57.2 9.95 68.3 11.9 79.3 14.0 84.8 15.1 90.3 16.3 101 18.5 112 20.9
16 57.2 10.1 68.3 12.1 79.3 14.3 84.8 15.4 90.3 16.6 101 18.9 112 21.3
18 57.2 10.3 68.3 12.4 79.3 14.6 84.8 15.7 90.3 16.9 101 19.3 112 21.7
20 57.2 10.5 68.3 12.6 79.3 14.9 84.8 16.0 90.3 17.2 101 20.0 112 23.2
21 57.2 10.6 68.3 12.7 79.3 15.0 84.8 16.2 90.3 17.6 101 20.7 112 24.1
23 57.2 10.8 68.3 13.0 79.3 15.7 84.8 17.2 90.3 18.8 101 22.2 112 25.8
25 57.2 11.1 68.3 13.8 79.3 16.8 84.8 18.4 90.3 20.1 101 23.7 112 27.6
27 57.2 11.8 68.3 14.7 79.3 17.9 84.8 19.7 90.3 21.5 101 25.4 112 29.6
29 57.2 12.6 68.3 15.7 79.3 19.1 84.8 21.0 90.3 22.9 101 27.1 112 31.6
31 57.2 13.3 68.3 16.7 79.3 20.4 84.8 22.3 90.3 24.4 101 28.9 112 32.8
33 57.2 14.2 68.3 17.7 79.3 21.7 84.8 23.8 90.3 26.0 101 30.8 112 34.1
35 57.2 15.0 68.3 18.8 79.3 23.0 84.8 25.3 90.3 27.7 101 32.9 112 35.3
37 57.2 15.9 68.3 20.0 79.3 24.5 84.8 27.0 90.3 29.5 101 35.0 110 36.6
39 57.2 16.9 68.3 21.2 79.3 26.1 84.8 28.7 90.3 31.4 101 37.3 108 37.8
70 665 10 50.18.4759.710.069.411.774.212.679.013.588.715.398.317.3
12 50.18.6059.710.269.411.974.212.879.013.788.715.698.317.6
14 50.18.7359.710.469.412.174.213.179.014.088.715.998.317.9
16 50.18.8759.710.669.412.474.213.379.014.388.716.298.318.3
18 50.19.0259.710.769.412.674.213.579.014.588.716.598.318.6
20 50.19.1759.710.969.412.874.213.879.014.888.716.998.319.1
21 50.19.2559.711.069.412.974.213.979.015.088.717.198.319.8
23 50.19.4159.711.269.413.274.214.479.015.788.718.398.321.2
25 50.19.5859.711.769.414.174.215.479.016.788.719.698.322.7
27 50.1 10.1 59.7 12.4 69.4 15.0 74.2 16.4 79.0 17.8 88.7 20.9 98.3 24.3
29 50.1 10.7 59.7 13.2 69.4 16.0 74.2 17.5 79.0 19.0 88.7 22.3 98.3 25.9
31 50.1 11.4 59.7 14.1 69.4 17.0 74.2 18.6 79.0 20.3 88.7 23.8 98.3 27.6
33 50.1 12.1 59.7 14.9 69.4 18.1 74.2 19.8 79.0 21.6 88.7 25.4 98.3 29.5
35 50.1 12.8 59.7 15.8 69.4 19.2 74.2 21.0 79.0 22.9 88.7 27.0 98.3 31.4
37 50.1 13.5 59.7 16.8 69.4 20.4 74.2 22.4 79.0 24.4 88.7 28.7 98.3 33.5
39 50.1 14.3 59.7 17.8 69.4 21.7 74.2 23.7 79.0 25.9 88.7 30.6 98.3 35.7
60 570 10 42.97.3751.28.6459.510.063.610.767.711.476.012.984.314.5
12 42.97.4751.28.7859.510.263.610.967.711.676.013.284.314.8
14 42.97.5851.28.9259.510.363.611.167.711.876.013.484.315.0
16 42.97.6951.29.0659.510.563.611.367.712.076.013.784.315.3
18 42.97.8151.29.2159.510.763.611.567.712.376.013.984.315.6
20 42.97.9351.29.3759.510.963.611.767.712.576.014.284.315.9
21 42.98.0051.29.4559.511.063.611.867.712.676.014.384.316.1
23 42.98.1351.29.6159.511.263.612.067.712.976.014.984.317.1
25 42.98.2651.29.7959.511.663.612.667.713.776.015.984.318.3
27 42.98.5651.210.459.512.463.613.467.714.676.016.984.319.5
29 42.99.0751.211.059.513.263.614.367.715.576.018.084.320.8
31 42.99.6151.211.759.514.063.615.267.716.576.019.284.322.2
33 42.9 10.2 51.2 12.4 59.5 14.8 63.6 16.2 67.7 17.5 76.0 20.4 84.3 23.6
35 42.9 10.7 51.2 13.1 59.5 15.7 63.6 17.1 67.7 18.6 76.0 21.7 84.3 25.1
37 42.9 11.4 51.2 13.9 59.5 16.7 63.6 18.2 67.7 19.8 76.0 23.1 84.3 26.7
39 42.9 12.0 51.2 14.7 59.5 17.7 63.6 19.3 67.7 21.0 76.0 24.6 84.3 28.4
