Daikin RXYQ22M7W1B [66/182] Capacity tables
![Daikin RXYQ22M7W1B [66/182] Capacity tables](/views2/1707499/page66/bg42.png)
18
3
• Systems • Outdoor Units
65
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-16 36HP
36HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 1,170 10 88.2 15.5 105 18.9 122 22.5 131 23.0 133 22.5 136 21.6 140 20.6
12 88.2 15.8 105 19.3 122 23.0 130 22.9 132 22.4 135 21.5 138 21.1
14 88.2 16.1 105 19.7 122 23.3 128 22.8 130 22.3 133 22.1 136 22.3
16 88.2 16.4 105 20.1 122 23.1 127 23.0 128 23.1 131 23.3 134 23.5
18 88.2 16.7 105 20.5 122 24.0 125 24.1 126 24.3 130 24.5 133 24.7
20 88.2 17.0 105 21.8 122 25.2 123 25.3 125 25.4 128 25.7 131 26.0
21 88.2 17.5 105 22.6 121 25.8 122 25.9 124 26.0 127 26.3 130 26.6
23 88.2 18.7 105 24.2 119 27.0 121 27.1 122 27.2 125 27.5 128 27.8
25 88.2 20.0 105 25.9 117 28.1 119 28.3 120 28.4 124 28.7 127 29.0
27 88.2 21.4 105 27.7 116 29.3 117 29.5 119 29.6 122 29.9 125 30.3
29 88.2 22.8 105 29.6 114 30.5 115 30.7 117 30.8 120 31.2 123 31.5
31 88.2 24.4 105 31.4 112 31.7 114 31.9 115 32.1 118 32.4 122 32.7
33 88.2 26.0 105 32.5 110 32.9 112 33.1 114 33.3 117 33.6 120 34.0
35 88.2 27.7 105 33.7 109 34.1 110 34.3 112 34.5 115 34.9 118 35.3
37 88.2 29.5 104 34.9 107 35.3 109 35.5 110 35.7 113 36.1 116 36.5
39 88.2 31.4 102 36.1 105 36.5 106 36.8 106 37.0 108 37.4 110 37.8
120 1,080 10 81.4 14.1 97.1 17.3 113 20.5 121 22.2 128 23.1 134 22.3 137 21.4
12 81.4 14.4 97.1 17.6 113 20.9 121 22.6 128 23.0 132 22.1 135 21.2
14 81.4 14.7 97.1 17.9 113 21.3 121 23.1 128 22.9 131 22.0 134 22.2
16 81.4 14.9 97.1 18.3 113 21.7 121 23.2 126 22.9 129 23.1 132 23.4
18 81.4 15.2 97.1 18.6 113 22.5 121 24.0 124 24.1 127 24.3 130 24.6
20 81.4 15.5 97.1 19.4 113 24.2 121 25.2 123 25.3 126 25.5 129 25.8
21 81.4 15.7 97.1 20.1 113 25.1 120 25.8 122 25.9 125 26.1 128 26.4
23 81.4 16.8 97.1 21.5 113 26.8 119 26.9 120 27.1 123 27.3 126 27.6
25 81.4 17.9 97.1 23.0 113 28.0 117 28.1 118 28.2 121 28.5 124 28.8
27 81.4 19.1 97.1 24.6 113 29.2 115 29.3 117 29.4 120 29.7 123 30.0
29 81.4 20.4 97.1 26.3 112 30.3 113 30.5 115 30.6 118 30.9 121 31.2
31 81.4 21.7 97.1 28.1 110 31.5 112 31.7 113 31.8 116 32.2 119 32.5
33 81.4 23.1 97.1 29.9 109 32.7 110 32.9 112 33.0 114 33.4 117 33.7
35 81.4 24.6 97.1 31.9 107 33.9 108 34.1 110 34.3 113 34.6 116 35.0
37 81.4 26.2 97.1 34.0 105 35.1 107 35.3 108 35.5 111 35.9 114 36.2
39 81.4 27.9 97.1 35.9 103 36.3 105 36.5 106 36.7 108 37.1 110 37.5
110 990 10 74.6 12.8 89.0 15.6 103 18.6 111 20.1 118 21.6 132 22.9 135 22.1
12 74.6 13.1 89.0 15.9 103 18.9 111 20.5 118 22.0 130 22.8 133 22.0
14 74.6 13.3 89.0 16.2 103 19.3 111 20.9 118 22.4 129 22.7 131 22.0
16 74.6 13.6 89.0 16.5 103 19.7 111 21.3 118 22.9 127 23.0 129 23.2
18 74.6 13.8 89.0 16.9 103 20.1 111 21.8 118 24.0 125 24.2 128 24.4
20 74.6 14.1 89.0 17.2 103 21.2 111 23.5 118 25.1 123 25.3 126 25.6
21 74.6 14.2 89.0 17.7 103 22.0 111 24.3 118 25.7 123 25.9 125 26.2
23 74.6 14.9 89.0 19.0 103 23.6 111 26.1 118 26.9 121 27.1 123 27.4
25 74.6 15.9 89.0 20.3 103 25.3 111 27.9 116 28.1 119 28.3 122 28.6
27 74.6 17.0 89.0 21.7 103 27.0 111 29.1 115 29.2 117 29.5 120 29.8
29 74.6 18.1 89.0 23.2 103 28.9 111 30.3 113 30.4 116 30.7 118 31.0
31 74.6 19.3 89.0 24.7 103 30.8 110 31.5 111 31.6 114 31.9 117 32.2
33 74.6 20.5 89.0 26.3 103 32.5 108 32.7 110 32.8 112 33.1 115 33.4
35 74.6 21.8 89.0 28.0 103 33.7 106 33.8 108 34.0 111 34.3 113 34.7
37 74.6 23.2 89.0 29.9 103 34.9 105 35.0 106 35.2 109 35.6 111 35.9
39 74.6 24.6 89.0 31.8 102 36.1 103 36.2 104 36.4 107 36.8 110 37.2
100 900 10 67.8 11.6 80.9 14.0 94.0 16.6 101 18.0 107 19.3 120 22.1 132 22.9
12 67.8 11.8 80.9 14.3 94.0 17.0 101 18.3 107 19.7 120 22.5 130 22.8
14 67.8 12.0 80.9 14.6 94.0 17.3 101 18.7 107 20.1 120 23.0 129 22.6
16 67.8 12.2 80.9 14.8 94.0 17.6 101 19.0 107 20.5 120 23.3 127 23.0
18 67.8 12.4 80.9 15.1 94.0 18.0 101 19.4 107 20.9 120 24.0 125 24.2
20 67.8 12.7 80.9 15.4 94.0 18.5 101 20.4 107 22.4 120 25.2 124 25.4
21 67.8 12.8 80.9 15.6 94.0 19.2 101 21.1 107 23.2 120 25.8 123 26.0
23 67.8 13.1 80.9 16.6 94.0 20.5 101 22.6 107 24.8 119 26.9 121 27.1
25 67.8 14.0 80.9 17.8 94.0 22.0 101 24.2 107 26.6 117 28.1 119 28.3
27 67.8 14.9 80.9 19.0 94.0 23.5 101 25.9 107 28.5 115 29.3 118 29.5
29 67.8 15.9 80.9 20.2 94.0 25.1 101 27.7 107 30.2 113 30.5 116 30.7
31 67.8 16.9 80.9 21.5 94.0 26.7 101 29.5 107 31.4 112 31.7 114 31.9
33 67.8 18.0 80.9 22.9 94.0 28.5 101 31.5 107 32.6 110 32.9 112 33.1
35 67.8 19.1 80.9 24.4 94.0 30.4 101 33.6 106 33.8 108 34.1 111 34.4
37 67.8 20.3 80.9 26.0 94.0 32.4 101 34.8 104 35.0 107 35.3 109 35.6
39 67.8 21.6 80.9 27.7 94.0 34.5 101 36.0 102 36.2 105 36.5 107 36.8
