• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
44
3 Capacity tables
3-1 Cooling capacity
3-1-9 22HP
22HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 715 10 54.09.0064.411.074.813.180.013.481.613.183.512.685.412.0
12 54.09.1764.411.274.813.479.513.380.513.082.512.584.412.3
14 54.09.3464.411.474.813.578.513.279.513.081.412.983.313.0
16 54.09.5264.411.774.813.577.413.478.413.480.313.682.313.7
18 54.09.7164.411.974.814.076.414.077.414.179.314.281.214.4
20 54.09.9064.412.774.414.775.314.776.314.878.214.980.215.1
21 54.0 10.2 64.4 13.1 73.8 15.0 74.8 15.1 75.8 15.1 77.7 15.3 79.7 15.4
23 54.0 10.9 64.4 14.1 72.8 15.7 73.8 15.8 74.7 15.8 76.7 16.0 78.6 16.2
25 54.0 11.7 64.4 15.1 71.7 16.4 72.7 16.4 73.7 16.5 75.6 16.7 77.6 16.9
27 54.0 12.4 64.4 16.1 70.7 17.1 71.7 17.1 72.6 17.2 74.6 17.4 76.5 17.6
29 54.0 13.3 64.4 17.2 69.6 17.7 70.6 17.8 71.6 17.9 73.5 18.1 75.5 18.3
31 54.0 14.2 64.4 18.2 68.6 18.4 69.6 18.5 70.5 18.6 72.5 18.8 74.4 19.0
33 54.0 15.1 64.4 18.9 67.5 19.1 68.5 19.2 69.5 19.3 71.4 19.6 73.4 19.8
35 54.0 16.1 64.4 19.6 66.5 19.8 67.5 19.9 68.4 20.1 70.4 20.3 72.3 20.5
37 54.0 17.1 63.5 20.3 65.4 20.5 66.4 20.7 67.4 20.8 69.3 21.0 71.3 21.3
39 54.0 18.2 62.4 21.0 64.4 21.2 65.4 21.4 66.3 21.5 68.3 21.7 70.2 22.0
120 660 10 49.88.2259.410.069.011.973.812.978.613.582.112.983.912.4
12 49.88.3859.410.269.012.273.813.278.613.481.112.982.912.4
14 49.88.5359.410.469.012.473.813.478.213.380.012.881.812.9
16 49.88.6959.410.669.012.673.813.577.213.379.013.580.813.6
18 49.88.8659.410.869.013.173.814.076.114.077.914.279.714.3
20 49.89.0459.411.369.014.173.814.675.114.776.914.878.715.0
21 49.8 9.1 59.4 11.7 69.0 14.6 73.7 15.0 74.6 15.0 76.3 15.2 78.1 15.3
23 49.8 9.7 59.4 12.5 69.0 15.6 72.6 15.7 73.5 15.7 75.3 15.9 77.1 16.0
25 49.8 10.4 59.4 13.4 69.0 16.3 71.6 16.3 72.5 16.4 74.2 16.6 76.0 16.7
27 49.8 11.1 59.4 14.3 69.0 17.0 70.5 17.0 71.4 17.1 73.2 17.3 75.0 17.5
29 49.8 11.9 59.4 15.3 68.6 17.6 69.5 17.7 70.4 17.8 72.1 18.0 73.9 18.2
31 49.8 12.6 59.4 16.3 67.5 18.3 68.4 18.4 69.3 18.5 71.1 18.7 72.9 18.9
33 49.8 13.5 59.4 17.4 66.5 19.0 67.4 19.1 68.2 19.2 70.0 19.4 71.8 19.6
35 49.8 14.3 59.4 18.6 65.4 19.7 66.3 19.8 67.2 19.9 69.0 20.1 70.8 20.3
37 49.8 15.3 59.4 19.8 64.4 20.4 65.3 20.5 66.1 20.6 67.9 20.8 69.7 21.1
39 49.8 16.2 59.4 20.9 63.3 21.1 64.2 21.2 65.1 21.3 66.9 21.6 68.7 21.8
110 605 10 45.7 7.47 54.5 9.1 63.3 10.8 67.7 11.7 72.0 12.6 80.8 13.3 82.4 12.9
12 45.7 7.60 54.5 9.3 63.3 11.0 67.7 11.9 72.0 12.8 79.7 13.3 81.3 12.8
14 45.7 7.74 54.5 9.4 63.3 11.2 67.7 12.1 72.0 13.0 78.6 13.2 80.3 12.8
16 45.7 7.89 54.5 9.6 63.3 11.4 67.7 12.4 72.0 13.3 77.6 13.4 79.2 13.5
18 45.7 8.04 54.5 9.8 63.3 11.7 67.7 12.7 72.0 13.9 76.5 14.1 78.2 14.2
20 45.78.1954.510.063.312.467.713.672.014.675.514.777.114.9
21 45.7 8.3 54.5 10.3 63.3 12.8 67.7 14.1 72.0 15.0 75.0 15.1 76.6 15.2
23 45.7 8.7 54.5 11.0 63.3 13.7 67.7 15.2 72.0 15.6 73.9 15.8 75.6 15.9
25 45.7 9.2 54.5 11.8 63.3 14.7 67.7 16.2 71.2 16.3 72.9 16.5 74.5 16.6
27 45.7 9.9 54.5 12.6 63.3 15.7 67.7 16.9 70.2 17.0 71.8 17.2 73.5 17.3
29 45.7 10.5 54.5 13.5 63.3 16.8 67.7 17.6 69.1 17.7 70.8 17.9 72.4 18.0
31 45.7 11.2 54.5 14.4 63.3 17.9 67.3 18.3 68.1 18.4 69.7 18.6 71.4 18.7
33 45.7 11.9 54.5 15.3 63.3 18.9 66.2 19.0 67.0 19.1 68.7 19.3 70.3 19.4
35 45.7 12.7 54.5 16.3 63.3 19.6 65.2 19.7 66.0 19.8 67.6 20.0 69.3 20.2
37 45.7 13.5 54.5 17.4 63.3 20.3 64.1 20.4 64.9 20.5 66.6 20.7 68.2 20.9
39 45.7 14.3 54.5 18.5 62.2 21.0 63.0 21.1 63.9 21.2 65.5 21.4 67.2 21.6
100 550 10 41.5 6.74 49.5 8.2 57.5 9.7 61.5 10.5 65.5 11.2 73.5 12.9 80.9 13.3
12 41.5 6.85 49.5 8.3 57.5 9.9 61.5 10.7 65.5 11.5 73.5 13.1 79.8 13.2
14 41.5 6.98 49.5 8.5 57.5 10.0 61.5 10.9 65.5 11.7 73.5 13.3 78.8 13.2
16 41.5 7.10 49.5 8.6 57.5 10.2 61.5 11.1 65.5 11.9 73.5 13.5 77.7 13.4
18 41.5 7.24 49.5 8.8 57.5 10.4 61.5 11.3 65.5 12.1 73.5 14.0 76.7 14.1
20 41.5 7.37 49.5 9.0 57.5 10.8 61.5 11.9 65.5 13.0 73.5 14.6 75.6 14.7
21 41.5 7.4 49.5 9.1 57.5 11.1 61.5 12.3 65.5 13.5 73.5 15.0 75.1 15.1
23 41.5 7.6 49.5 9.7 57.5 11.9 61.5 13.2 65.5 14.4 72.5 15.7 74.0 15.8
25 41.5 8.2 49.5 10.3 57.5 12.8 61.5 14.1 65.5 15.5 71.5 16.3 73.0 16.5
27 41.5 8.7 49.5 11.0 57.5 13.6 61.5 15.1 65.5 16.6 70.4 17.0 71.9 17.2
29 41.5 9.3 49.5 11.8 57.5 14.6 61.5 16.1 65.5 17.6 69.4 17.7 70.9 17.9
31 41.5 9.8 49.5 12.5 57.5 15.5 61.5 17.2 65.5 18.3 68.3 18.4 69.8 18.6
33 41.5 10.5 49.5 13.3 57.5 16.6 61.5 18.3 65.5 18.9 67.3 19.1 68.8 19.3
35 41.5 11.1 49.5 14.2 57.5 17.7 61.5 19.6 64.7 19.6 66.2 19.8 67.7 20.0
37 41.5 11.8 49.5 15.1 57.5 18.8 61.5 20.2 63.7 20.3 65.2 20.5 66.7 20.7
39 41.5 12.6 49.5 16.1 57.5 20.1 61.5 20.9 62.6 21.0 64.1 21.2 65.6 21.4
