• Systems • Outdoor Units
139
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-18 40HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 500
-19.8 -20.0 66.6 37.1 66.5 37.8 63.3 35.7 61.2 34.4 59.2 33.0 55.1 30.4
-18.8 -19.0 69.1 37.6 67.3 36.8 63.3 34.2 61.2 32.9 59.2 31.6 55.1 29.2
-16.7 -17.0 71.4 36.3 67.3 33.9 63.3 31.5 61.2 30.3 59.2 29.2 55.1 26.9
-14.7 -15.0 71.4 33.6 67.3 31.4 63.3 29.2 61.2 28.2 59.2 27.1 55.1 25.0
-12.6 -13.0 71.4 31.3 67.3 29.2 63.3 27.3 61.2 26.3 59.2 25.3 55.1 23.4
-10.5 -11.0 71.4 29.3 67.3 27.4 63.3 25.6 61.2 24.7 59.2 23.8 55.1 22.0
-9.5-10.071.428.467.326.663.324.861.223.959.223.155.121.4
-8.5 -9.1 71.4 27.6 67.3 25.8 63.3 24.1 61.2 23.3 59.2 22.5 55.1 20.8
-7.0 -7.6 71.4 26.4 67.3 24.8 63.3 23.1 61.2 22.3 59.2 21.5 55.1 20.0
-5.0 -5.6 71.4 25.0 67.3 23.4 63.3 21.9 61.2 21.2 59.2 20.4 55.1 19.0
-3.0 -3.7 71.4 23.8 67.3 22.3 63.3 20.9 61.2 20.2 59.2 19.5 55.1 18.1
0.0 -0.771.422.167.320.863.319.561.218.859.218.255.116.9
3.0 2.2 71.4 20.7 67.3 19.5 63.3 18.3 61.2 17.7 59.2 17.1 55.1 16.0
5.0 4.1 71.4 19.9 67.3 18.7 63.3 17.6 61.2 17.0 59.2 16.5 55.1 15.4
7.0 6.0 71.4 19.2 67.3 18.1 63.3 17.0 61.2 16.4 59.2 15.9 55.1 14.8
9.0 7.9 71.4 18.5 67.3 17.4 63.3 16.4 61.2 15.9 59.2 15.4 55.1 14.4
11.0 9.8 71.417.967.316.863.315.961.215.459.214.955.113.9
13.0 11.8 71.4 17.3 67.3 16.3 63.3 15.3 61.2 14.9 59.2 14.4 55.1 13.5
15.0 13.7 71.4 16.7 67.3 15.8 63.3 14.9 61.2 14.4 59.2 14.0 55.1 13.1
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
