Daikin RXYQ22M7W1B [151/182] Capacity tables
![Daikin RXYQ22M7W1B [151/182] Capacity tables](/views2/1707499/page151/bg97.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
150
3 Capacity tables
3-2 Heating capacity
3-2-22 48HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
90 1,080
-19.8 -20.0 77.7 28.4 77.5 29.9 77.2 31.4 77.1 32.2 77.0 33.0 76.8 34.5
-18.8 -19.0 80.5 29.3 80.3 30.8 80.0 32.3 79.9 33.1 79.8 33.8 79.6 35.3
-16.7 -17.0 86.1 31.1 85.8 32.5 85.6 33.9 85.5 34.6 85.4 35.3 85.1 36.6
-14.7 -15.0 91.6 32.7 91.4 34.0 91.2 35.3 91.0 35.9 90.9 36.6 90.7 37.8
-12.6 -13.0 97.2 34.0 97.0 35.3 96.7 36.5 96.6 37.1 96.5 37.7 96.2 38.9
-10.5 -11.0 103 35.3 103 36.4 102 37.6 102 38.1 102 38.7 102 39.8
-9.5 -10.0 106 35.8 105 36.9 105 38.0 105 38.6 105 39.2 105 40.3
-8.5 -9.1 108 36.3 108 37.4 108 38.5 107 39.0 107 39.6 107 40.6
-7.0 -7.6 112 37.0 112 38.1 112 39.1 112 39.7 112 40.2 111 41.2
-5.0 -5.6 118 37.9 118 38.9 117 39.9 117 40.4 117 40.9 117 41.9
-3.0 -3.7 123 38.7 123 39.7 123 40.6 122 41.1 122 41.6 118 40.2
0.0 -0.7 131 39.8 131 40.7 131 41.6 131 42.0 126 40.3 118 37.1
3.0 2.2 139 40.8 139 41.6 135 40.6 131 39.1 126 37.5 118 34.6
5.0 4.1 145 41.4 144 41.8 135 38.8 131 37.3 126 35.9 118 33.1
7.0 6.0 150 41.9 144 40.0 135 37.2 131 35.8 126 34.4 118 31.8
9.0 7.9 152 41.1 144 38.4 135 35.7 131 34.4 126 33.1 118 30.5
11.0 9.8 152 39.5 144 36.9 135 34.3 131 33.1 126 31.8 118 29.4
13.0 11.8 152 37.9 144 35.4 135 33.0 131 31.8 126 30.6 118 28.3
15.0 13.7 152 36.5 144 34.1 135 31.8 131 30.7 126 29.5 118 27.3
80 960
-19.8 -20.0 77.3 31.4 77.0 32.7 76.8 34.1 76.7 34.8 76.6 35.5 76.4 36.8
-18.8 -19.0 80.0 32.2 79.8 33.6 79.6 34.9 79.5 35.5 79.4 36.2 79.2 37.5
-16.7 -17.0 85.6 33.8 85.4 35.0 85.2 36.3 85.1 36.9 85.0 37.5 84.8 38.7
-14.7 -15.0 91.2 35.2 91.0 36.3 90.7 37.5 90.6 38.1 90.5 38.6 90.3 39.8
-12.6 -13.0 96.7 36.4 96.5 37.5 96.3 38.6 96.2 39.1 96.1 39.7 95.9 40.7
-10.5 -11.0 102 37.5 102 38.5 102 39.5 102 40.0 102 40.6 101 41.6
-9.5 -10.0 105 38.0 105 39.0 105 40.0 105 40.5 104 41.0 104 42.0
-8.5 -9.1 108 38.4 107 39.4 107 40.4 107 40.8 107 41.3 105 41.0
-7.0 -7.6 112 39.1 112 40.0 111 40.9 111 41.4 111 41.9 105 39.1
-5.0 -5.6 117 39.9 117 40.8 117 41.7 116 41.7 112 40.1 105 36.9
-3.0 -3.7 123 40.6 122 41.4 120 41.1 116 39.6 112 38.0 105 35.0
0.0 -0.7 131 41.6 128 40.9 120 38.0 116 36.6 112 35.2 105 32.4
3.0 2.2 135 40.7 128 38.0 120 35.4 116 34.1 112 32.8 105 30.3
5.0 4.1 135 38.9 128 36.4 120 33.9 116 32.6 112 31.4 105 29.0
7.0 6.0 135 37.3 128 34.9 120 32.5 116 31.3 112 30.1 105 27.9
9.0 7.9 135 35.8 128 33.5 120 31.2 116 30.1 112 29.0 105 26.8
11.0 9.8 135 34.4 128 32.2 120 30.0 116 29.0 112 27.9 105 25.9
13.0 11.8 135 33.1 128 31.0 120 28.9 116 27.9 112 26.9 105 24.9
15.0 13.7 135 31.9 128 29.9 120 27.9 116 26.9 112 26.0 105 24.1
70 840
-19.8 -20.0 76.8 34.4 76.6 35.6 76.4 36.7 76.3 37.3 76.2 37.9 76.1 39.1
-18.8 -19.0 79.6 35.1 79.4 36.3 79.2 37.4 79.1 38.0 79.0 38.6 78.8 39.7
-16.7 -17.0 85.1 36.5 85.0 37.6 84.8 38.7 84.7 39.2 84.6 39.7 84.4 40.8
-14.7 -15.0 90.7 37.7 90.5 38.7 90.3 39.7 90.2 40.2 90.2 40.7 90.0 41.7
-12.6 -13.0 96.3 38.8 96.1 39.7 95.9 40.7 95.8 41.2 95.7 41.6 91.5 39.8
-10.5 -11.0 102 39.7 102 40.6 101 41.5 101 42.0 98.3 40.5 91.5 37.2
-9.5 -10.0 105 40.2 104 41.0 104 41.9 102 40.8 98.3 39.2 91.5 36.0
-8.5 -9.1 107 40.5 107 41.4 105 41.2 102 39.6 98.3 38.1 91.5 35.0
-7.0 -7.6 111 41.1 111 41.9 105 39.3 102 37.8 98.3 36.4 91.5 33.5
-5.0 -5.6 117 41.8 112 39.9 105 37.1 102 35.7 98.3 34.3 91.5 31.7
-3.0 -3.7 118 40.5 112 37.8 105 35.2 102 33.9 98.3 32.6 91.5 30.1
0.0 -0.7 118 37.4 112 35.0 105 32.6 102 31.4 98.3 30.2 91.5 28.0
3.0 2.2 118 34.9 112 32.6 105 30.4 102 29.3 98.3 28.3 91.5 26.2
5.0 4.1 118 33.4 112 31.2 105 29.1 102 28.1 98.3 27.1 91.5 25.1
7.0 6.0 118 32.0 112 30.0 105 28.0 102 27.0 98.3 26.1 91.5 24.2
9.0 7.9 118 30.8 112 28.8 105 26.9 102 26.0 98.3 25.1 91.5 23.3
11.0 9.8 118 29.6 112 27.8 105 26.0 102 25.1 98.3 24.2 91.5 22.5
13.0 11.8 118 28.5 112 26.8 105 25.0 102 24.2 98.3 23.3 91.5 21.7
15.0 13.7 118 27.5 112 25.9 105 24.2 102 23.4 98.3 22.6 91.5 21.0
60 720
-19.8 -20.0 76.3 37.4 76.2 38.4 76.0 39.4 75.9 39.9 75.9 40.4 75.7 41.5
-18.8 -19.0 79.1 38.0 79.0 39.0 78.8 40.0 78.7 40.5 78.6 41.0 78.4 41.9
-16.7 -17.0 84.7 39.2 84.5 40.1 84.4 41.0 84.3 41.5 84.2 42.0 78.4 38.6
-14.7 -15.0 90.2 40.2 90.1 41.1 89.9 42.0 87.1 40.4 84.2 38.8 78.4 35.7
-12.6 -13.0 95.8 41.2 95.7 42.0 90.0 39.1 87.1 37.6 84.2 36.2 78.4 33.3
-10.5-11.010142.095.839.390.036.587.135.284.233.878.431.2
-9.5 -10.0 102 40.7 95.8 38.0 90.0 35.4 87.1 34.1 84.2 32.8 78.4 30.3
-8.5 -9.110239.695.836.990.034.487.133.184.231.978.429.5
-7.0 -7.610237.895.835.390.032.987.131.784.230.578.428.2
-5.0 -5.610235.795.833.390.031.187.130.084.228.978.426.7
-3.0 -3.710233.995.831.790.029.687.128.584.227.578.425.5
0.0 -0.7 102 31.4 95.8 29.4 90.0 27.5 87.1 26.5 84.2 25.6 78.4 23.7
3.0 2.2 10229.395.827.590.025.787.124.884.224.078.422.3
5.0 4.1 10228.195.826.490.024.787.123.984.223.078.421.4
7.0 6.0 10227.095.825.490.023.787.123.084.222.278.420.6
9.0 7.9 10226.095.824.490.022.987.122.184.221.478.419.9
11.0 9.8 102 25.1 95.8 23.6 90.0 22.1 87.1 21.4 84.2 20.7 78.4 19.2
13.011.810224.295.822.790.021.387.120.684.220.078.418.6
15.013.710223.495.822.090.020.787.120.084.219.378.418.0
