• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
130
3 Capacity tables
3-2 Heating capacity
3-2-15 34HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 425
-19.8 -20.0 58.0 33.3 57.5 33.5 54.0 31.1 52.3 29.9 50.5 28.7 47.1 26.5
-18.8 -19.0 60.1 33.7 57.5 32.0 54.0 29.8 52.3 28.6 50.5 27.5 47.1 25.4
-16.7 -17.0 60.9 31.6 57.5 29.5 54.0 27.4 52.3 26.4 50.5 25.4 47.1 23.4
-14.7 -15.0 60.9 29.2 57.5 27.3 54.0 25.4 52.3 24.5 50.5 23.6 47.1 21.8
-12.6 -13.0 60.9 27.2 57.5 25.4 54.0 23.7 52.3 22.9 50.5 22.0 47.1 20.4
-10.5 -11.0 60.9 25.5 57.5 23.8 54.0 22.2 52.3 21.4 50.5 20.7 47.1 19.1
-9.5-10.060.924.757.523.154.021.652.320.850.520.147.118.6
-8.5 -9.1 60.9 24.0 57.5 22.5 54.0 21.0 52.3 20.3 50.5 19.5 47.1 18.1
-7.0 -7.6 60.9 23.0 57.5 21.5 54.0 20.1 52.3 19.4 50.5 18.7 47.1 17.4
-5.0 -5.6 60.9 21.7 57.5 20.4 54.0 19.1 52.3 18.4 50.5 17.8 47.1 16.5
-3.0 -3.7 60.9 20.7 57.5 19.4 54.0 18.2 52.3 17.6 50.5 17.0 47.1 15.8
0.0 -0.760.919.257.518.154.016.952.316.450.515.847.114.7
3.0 2.2 60.9 18.0 57.5 17.0 54.0 15.9 52.3 15.4 50.5 14.9 47.1 13.9
5.0 4.1 60.9 17.3 57.5 16.3 54.0 15.3 52.3 14.8 50.5 14.3 47.1 13.4
7.0 6.0 60.9 16.7 57.5 15.7 54.0 14.8 52.3 14.3 50.5 13.8 47.1 12.9
9.0 7.9 60.9 16.1 57.5 15.2 54.0 14.3 52.3 13.8 50.5 13.4 47.1 12.5
11.0 9.8 60.915.557.514.754.013.852.313.450.512.947.112.1
13.0 11.8 60.9 15.0 57.5 14.2 54.0 13.3 52.3 12.9 50.5 12.5 47.1 11.7
15.0 13.7 60.9 14.5 57.5 13.7 54.0 12.9 52.3 12.5 50.5 12.1 47.1 11.4
NOTE
1 is shown as reference
