Daikin RXYQ22M7W1B [76/182] Capacity tables
![Daikin RXYQ22M7W1B [76/182] Capacity tables](/views2/1707499/page76/bg4c.png)
18
3
• Systems • Outdoor Units
75
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-19 42HP
42HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90 945 10 71.1 12.4 84.8 15.0 98.5 17.7 105 19.1 112 20.5 126 23.4 140 26.4
12 71.1 12.6 84.8 15.2 98.5 18.0 105 19.4 112 20.9 126 23.9 140 26.9
14 71.1 12.8 84.8 15.5 98.5 18.3 105 19.8 112 21.3 126 24.3 140 27.4
16 71.1 13.1 84.8 15.8 98.5 18.7 105 20.2 112 21.7 126 24.8 140 27.9
18 71.1 13.3 84.8 16.1 98.5 19.0 105 20.6 112 22.1 126 25.3 140 28.7
20 71.1 13.5 84.8 16.4 98.5 19.4 105 21.0 112 22.9 126 27.2 140 30.1
21 71.1 13.7 84.8 16.6 98.5 19.8 105 21.7 112 23.8 126 28.1 140 30.8
23 71.1 13.9 84.8 17.3 98.5 21.2 105 23.3 112 25.5 126 30.2 138 32.2
25 71.1 14.7 84.8 18.4 98.5 22.6 105 24.9 112 27.2 126 32.3 136 33.6
27 71.1 15.6 84.8 19.6 98.5 24.1 105 26.6 112 29.1 126 34.6 134 35.0
29 71.1 16.6 84.8 20.9 98.5 25.8 105 28.4 112 31.1 126 36.2 132 36.5
31 71.1 17.7 84.8 22.3 98.5 27.5 105 30.3 112 33.2 126 37.6 130 37.9
33 71.1 18.8 84.8 23.7 98.5 29.3 105 32.3 112 35.4 125 39.0 128 39.3
35 71.1 19.9 84.8 25.2 98.5 31.2 105 34.4 112 37.8 123 40.4 126 40.8
37 71.1 21.2 84.8 26.8 98.5 33.2 105 36.6 112 40.2 121 41.9 124 42.2
39 71.1 22.4 84.8 28.5 98.5 35.3 105 39.0 112 42.9 118 43.3 120 43.7
80 840 10 63.2 11.0 75.3 13.2 87.5 15.5 93.6 16.7 99.7 17.9 112 20.4 124 23.0
12 63.2 11.2 75.3 13.4 87.5 15.8 93.6 17.0 99.7 18.3 112 20.8 124 23.5
14 63.2 11.4 75.3 13.7 87.5 16.1 93.6 17.3 99.7 18.6 112 21.2 124 23.9
16 63.2 11.6 75.3 13.9 87.5 16.4 93.6 17.6 99.7 19.0 112 21.6 124 24.4
18 63.2 11.8 75.3 14.2 87.5 16.7 93.6 18.0 99.7 19.3 112 22.1 124 24.9
20 63.2 12.0 75.3 14.4 87.5 17.0 93.6 18.3 99.7 19.7 112 22.9 124 26.6
21 63.2 12.1 75.3 14.6 87.5 17.2 93.6 18.5 99.7 20.1 112 23.7 124 27.5
23 63.2 12.3 75.3 14.8 87.5 18.0 93.6 19.7 99.7 21.5 112 25.4 124 29.5
25 63.2 12.7 75.3 15.8 87.5 19.2 93.6 21.1 99.7 23.0 112 27.1 124 31.6
27 63.2 13.5 75.3 16.8 87.5 20.5 93.6 22.5 99.7 24.6 112 29.0 124 33.8
29 63.2 14.4 75.3 17.9 87.5 21.9 93.6 24.0 99.7 26.2 112 31.0 124 36.2
31 63.2 15.3 75.3 19.1 87.5 23.3 93.6 25.6 99.7 28.0 112 33.1 124 37.6
33 63.2 16.2 75.3 20.3 87.5 24.8 93.6 27.2 99.7 29.8 112 35.3 124 39.0
35 63.2 17.2 75.3 21.5 87.5 26.4 93.6 29.0 99.7 31.7 112 37.6 123 40.4
37 63.2 18.2 75.3 22.8 87.5 28.0 93.6 30.8 99.7 33.8 112 40.1 121 41.8
39 63.2 19.3 75.3 24.3 87.5 29.8 93.6 32.8 99.7 36.0 112 42.7 119 43.3
70 735 10 55.39.6965.911.576.613.481.914.487.215.497.917.610919.7
12 55.39.8465.911.776.613.781.914.787.215.797.917.910920.1
14 55.39.9965.911.976.613.981.914.987.216.097.918.210920.5
16 55.3 10.1 65.9 12.1 76.6 14.1 81.9 15.2 87.2 16.3 97.9 18.6 109 20.9
18 55.3 10.3 65.9 12.3 76.6 14.4 81.9 15.5 87.2 16.6 97.9 18.9 109 21.3
20 55.3 10.5 65.9 12.5 76.6 14.7 81.9 15.8 87.2 16.9 97.9 19.3 109 21.9
21 55.3 10.6 65.9 12.6 76.6 14.8 81.9 15.9 87.2 17.1 97.9 19.6 109 22.7
23 55.3 10.8 65.9 12.9 76.6 15.1 81.9 16.5 87.2 17.9 97.9 21.0 109 24.3
25 55.3 11.0 65.9 13.4 76.6 16.1 81.9 17.6 87.2 19.1 97.9 22.4 109 26.0
27 55.3 11.6 65.9 14.2 76.6 17.2 81.9 18.8 87.2 20.4 97.9 23.9 109 27.8
29 55.3 12.3 65.9 15.1 76.6 18.3 81.9 20.0 87.2 21.8 97.9 25.5 109 29.6
31 55.3 13.0 65.9 16.1 76.6 19.5 81.9 21.3 87.2 23.2 97.9 27.2 109 31.6
33 55.3 13.8 65.9 17.1 76.6 20.7 81.9 22.6 87.2 24.7 97.9 29.0 109 33.7
35 55.3 14.6 65.9 18.1 76.6 22.0 81.9 24.1 87.2 26.2 97.9 30.9 109 35.9
37 55.3 15.5 65.9 19.2 76.6 23.3 81.9 25.6 87.2 27.9 97.9 32.9 109 38.3
39 55.3 16.4 65.9 20.4 76.6 24.8 81.9 27.2 87.2 29.7 97.9 35.0 109 40.8
60 630 10 47.48.4356.59.8965.611.470.212.374.813.183.914.893.016.6
12 47.48.5556.510.065.611.670.212.574.813.383.915.193.016.9
14 47.48.6756.510.265.611.870.212.774.813.583.915.393.017.2
16 47.48.8056.510.465.612.070.212.974.813.883.915.693.017.5
18 47.48.9456.510.565.612.270.213.174.814.083.915.993.017.9
20 47.49.0856.510.765.612.570.213.474.814.383.916.293.018.2
21 47.49.1556.510.865.612.670.213.574.814.483.916.493.018.4
23 47.49.3056.511.065.612.870.213.874.814.783.917.093.019.6
25 47.49.4556.511.265.613.370.214.574.815.683.918.293.020.9
27 47.49.8056.511.965.614.270.215.474.816.783.919.493.022.3
29 47.4 10.4 56.5 12.6 65.6 15.1 70.2 16.4 74.8 17.7 83.9 20.6 93.0 23.8
31 47.4 11.0 56.5 13.4 65.6 16.0 70.2 17.4 74.8 18.9 83.9 22.0 93.0 25.3
33 47.4 11.6 56.5 14.2 65.6 17.0 70.2 18.5 74.8 20.0 83.9 23.4 93.0 27.0
35 47.4 12.3 56.5 15.0 65.6 18.0 70.2 19.6 74.8 21.3 83.9 24.9 93.0 28.7
37 47.4 13.0 56.5 15.9 65.6 19.1 70.2 20.8 74.8 22.6 83.9 26.4 93.0 30.6
39 47.4 13.7 56.5 16.8 65.6 20.2 70.2 22.1 74.8 24.0 83.9 28.1 93.0 32.5
