• Systems • Outdoor Units
83
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-22 48HP
48HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 1,560 10 117 21.6 140 26.4 162 31.4 174 32.1 177 31.4 181 30.1 185 28.7
12 117 22.0 140 26.9 162 32.0 173 31.9 175 31.2 179 29.9 183 29.4
14 117 22.4 140 27.4 162 32.4 170 31.7 172 31.1 177 30.8 181 31.1
16 117 22.8 140 28.0 162 32.3 168 32.0 170 32.2 174 32.5 179 32.8
18 117 23.3 140 28.5 162 33.5 166 33.7 168 33.8 172 34.1 176 34.5
20 117 23.7 140 30.4 161 35.1 164 35.3 166 35.5 170 35.8 174 36.2
21 117 24.4 140 31.5 160 35.9 162 36.1 164 36.3 169 36.7 173 37.0
23 117 26.1 140 33.7 158 37.6 160 37.8 162 38.0 166 38.3 171 38.7
25 117 27.9 140 36.1 156 39.2 158 39.4 160 39.6 164 40.0 168 40.4
27 117 29.8 140 38.6 153 40.9 156 41.1 158 41.3 162 41.7 166 42.2
29 117 31.8 140 41.3 151 42.5 153 42.8 155 43.0 160 43.4 164 43.9
31 117 34.0 140 43.7 149 44.2 151 44.4 153 44.7 157 45.2 162 45.6
33 117 36.2 140 45.4 147 45.9 149 46.1 151 46.4 155 46.9 159 47.4
35 117 38.6 140 47.0 144 47.5 146 47.8 148 48.1 150 48.6 152 49.2
37 117 41.1 133 48.7 135 49.2 136 49.5 137 49.8 140 50.4 142 50.9
39 117 43.7 123 50.3 125 50.9 126 51.2 127 51.5 129 52.1 132 52.7
120 1,440 10 108 19.7 129 24.1 150 28.6 160 31.0 171 32.2 178 31.0 182 29.8
12 108 20.1 129 24.5 150 29.2 160 31.5 171 32.1 176 30.9 180 29.6
14 108 20.4 129 25.0 150 29.7 160 32.1 170 31.9 174 30.7 178 30.9
16 108 20.8 129 25.5 150 30.3 160 32.4 168 32.0 171 32.3 175 32.5
18 108 21.2 129 26.0 150 31.4 160 33.5 165 33.6 169 33.9 173 34.2
20 108 21.7 129 27.0 150 33.7 160 35.1 163 35.3 167 35.6 171 35.9
21 108 21.9 129 28.0 150 34.9 160 35.9 162 36.1 166 36.4 170 36.7
23 108 23.4 129 30.0 150 37.4 158 37.5 160 37.7 163 38.1 167 38.4
25 108 25.0 129 32.1 150 39.0 155 39.2 157 39.4 161 39.7 165 40.1
27 108 26.6 129 34.3 150 40.6 153 40.8 155 41.0 159 41.4 163 41.8
29 108 28.4 129 36.6 149 42.3 151 42.5 153 42.7 157 43.1 161 43.5
31 108 30.3 129 39.1 147 43.9 148 44.2 150 44.4 154 44.8 158 45.3
33 108 32.3 129 41.7 144 45.6 146 45.8 148 46.1 152 46.5 156 47.0
35 108 34.3 129 44.5 142 47.2 144 47.5 146 47.7 150 48.2 152 48.7
37 108 36.6 129 47.4 135 48.9 136 49.2 137 49.4 140 50.0 142 50.5
39 108 38.9 123 50.0 125 50.6 126 50.9 127 51.2 129 51.7 132 52.3
110 1,320 10 99.1 17.9 118 21.8 137 25.9 147 28.0 156 30.1 175 32.0 179 30.9
12 99.1 18.2 118 22.2 137 26.4 147 28.5 156 30.7 173 31.8 177 30.7
14 99.1 18.6 118 22.6 137 26.9 147 29.1 156 31.3 171 31.6 174 30.7
16 99.1 18.9 118 23.1 137 27.4 147 29.6 156 31.9 168 32.0 172 32.3
18 99.1 19.3 118 23.5 137 28.0 147 30.4 156 33.4 166 33.7 170 34.0
20 99.1 19.6 118 24.0 137 29.6 147 32.7 156 35.0 164 35.3 167 35.6
21 99.1 19.8 118 24.7 137 30.7 147 33.9 156 35.8 163 36.2 166 36.5
23 99.1 20.8 118 26.5 137 32.9 147 36.4 156 37.5 160 37.8 164 38.1
25 99.1 22.2 118 28.3 137 35.2 147 38.9 155 39.1 158 39.5 162 39.8
27 99.1 23.6 118 30.2 137 37.6 147 40.6 152 40.8 156 41.1 159 41.5
29 99.1 25.2 118 32.3 137 40.2 147 42.2 150 42.4 154 42.8 157 43.2
31 99.1 26.8 118 34.4 137 43.0 146 43.9 148 44.1 151 44.5 155 44.9
33 99.1 28.6 118 36.7 137 45.3 144 45.5 145 45.7 149 46.2 153 46.6
35 99.1 30.4 118 39.1 137 47.0 141 47.2 143 47.4 147 47.9 150 48.3
37 99.1 32.3 118 41.6 135 48.6 136 48.8 137 49.1 140 49.6 142 50.0
39 99.1 34.3 118 44.3 125 50.3 126 50.5 127 50.8 129 51.3 132 51.8
100 1,200 10 90.1 16.1 107 19.6 125 23.2 134 25.1 142 27.0 160 30.8 176 31.9
12 90.1 16.4 107 19.9 125 23.6 134 25.5 142 27.5 160 31.4 173 31.7
14 90.1 16.7 107 20.3 125 24.1 134 26.0 142 28.0 160 32.0 171 31.5
16 90.1 17.0 107 20.7 125 24.5 134 26.5 142 28.5 160 32.4 169 32.1
18 90.1 17.3 107 21.1 125 25.0 134 27.1 142 29.1 160 33.5 166 33.7
20 90.1 17.7 107 21.5 125 25.8 134 28.4 142 31.2 160 35.1 164 35.3
21 90.1 17.8 107 21.7 125 26.7 134 29.4 142 32.3 160 35.9 163 36.2
23 90.1 18.3 107 23.2 125 28.6 134 31.5 142 34.6 157 37.5 161 37.8
25 90.1 19.5 107 24.8 125 30.6 134 33.8 142 37.1 155 39.2 158 39.5
27 90.1 20.8 107 26.4 125 32.7 134 36.1 142 39.7 153 40.8 156 41.2
29 90.1 22.2 107 28.2 125 34.9 134 38.6 142 42.1 151 42.5 154 42.8
31 90.1 23.6 107 30.0 125 37.3 134 41.2 142 43.8 148 44.1 152 44.5
33 90.1 25.1 107 32.0 125 39.7 134 43.9 142 45.4 146 45.8 149 46.2
35 90.1 26.7 107 34.1 125 42.4 134 46.9 141 47.1 144 47.5 147 47.9
37 90.1 28.3 107 36.2 125 45.1 134 48.5 137 48.7 140 49.2 142 49.6
39 90.1 30.1 107 38.5 125 48.1 126 50.2 127 50.4 129 50.9 132 51.3
