Daikin RXYQ22M7W1B [73/182] Capacity tables
![Daikin RXYQ22M7W1B [73/182] Capacity tables](/views2/1707499/page73/bg49.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
72
3 Capacity tables
3-1 Cooling capacity
3-1-18 40HP
40HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90 900 10 68.3 12.0 81.5 14.4 94.7 17.0 101 18.4 108 19.8 121 22.6 134 25.5
12 68.3 12.2 81.5 14.7 94.7 17.4 101 18.7 108 20.1 121 23.0 134 25.9
14 68.3 12.4 81.5 15.0 94.7 17.7 101 19.1 108 20.5 121 23.5 134 26.4
16 68.3 12.6 81.5 15.2 94.7 18.0 101 19.5 108 20.9 121 23.9 134 26.9
18 68.3 12.8 81.5 15.5 94.7 18.4 101 19.8 108 21.3 121 24.4 134 27.7
20 68.3 13.1 81.5 15.8 94.7 18.7 101 20.2 108 22.1 121 26.2 134 29.1
21 68.3 13.2 81.5 16.0 94.7 19.1 101 21.0 108 22.9 121 27.2 134 29.7
23 68.3 13.4 81.5 16.6 94.7 20.4 101 22.4 108 24.6 121 29.1 133 31.1
25 68.3 14.2 81.5 17.8 94.7 21.8 101 24.0 108 26.3 121 31.2 131 32.4
27 68.3 15.1 81.5 19.0 94.7 23.3 101 25.6 108 28.1 121 33.4 129 33.8
29 68.3 16.0 81.5 20.2 94.7 24.9 101 27.4 108 30.0 121 34.9 127 35.2
31 68.3 17.0 81.5 21.5 94.7 26.5 101 29.2 108 32.0 121 36.3 125 36.6
33 68.3 18.1 81.5 22.9 94.7 28.2 101 31.1 108 34.2 121 37.6 123 37.9
35 68.3 19.2 81.5 24.3 94.7 30.1 101 33.2 108 36.4 119 39.0 121 39.3
37 68.3 20.4 81.5 25.9 94.7 32.0 101 35.3 108 38.8 117 40.4 119 40.7
39 68.3 21.6 81.5 27.5 94.7 34.1 101 37.6 108 41.3 115 41.8 117 42.1
80 800 10 60.7 10.6 72.4 12.7 84.1 15.0 90.0 16.1 95.9 17.3 108 19.7 119 22.2
12 60.7 10.8 72.4 12.9 84.1 15.2 90.0 16.4 95.9 17.6 108 20.1 119 22.6
14 60.7 11.0 72.4 13.2 84.1 15.5 90.0 16.7 95.9 17.9 108 20.5 119 23.1
16 60.7 11.2 72.4 13.4 84.1 15.8 90.0 17.0 95.9 18.3 108 20.9 119 23.5
18 60.7 11.4 72.4 13.7 84.1 16.1 90.0 17.4 95.9 18.6 108 21.3 119 24.0
20 60.7 11.6 72.4 13.9 84.1 16.4 90.0 17.7 95.9 19.0 108 22.1 119 25.7
21 60.7 11.7 72.4 14.0 84.1 16.6 90.0 17.9 95.9 19.4 108 22.8 119 26.6
23 60.7 11.9 72.4 14.3 84.1 17.4 90.0 19.0 95.9 20.8 108 24.5 119 28.5
25 60.7 12.3 72.4 15.2 84.1 18.6 90.0 20.3 95.9 22.2 108 26.2 119 30.5
27 60.7 13.0 72.4 16.2 84.1 19.8 90.0 21.7 95.9 23.7 108 28.0 119 32.6
29 60.7 13.9 72.4 17.3 84.1 21.1 90.0 23.1 95.9 25.3 108 29.9 119 34.9
31 60.7 14.7 72.4 18.4 84.1 22.5 90.0 24.7 95.9 27.0 108 31.9 119 36.2
33 60.7 15.6 72.4 19.5 84.1 23.9 90.0 26.3 95.9 28.7 108 34.0 119 37.6
35 60.7 16.6 72.4 20.8 84.1 25.4 90.0 28.0 95.9 30.6 108 36.3 118 39.0
37 60.7 17.6 72.4 22.0 84.1 27.1 90.0 29.8 95.9 32.6 108 38.7 116 40.4
39 60.7 18.6 72.4 23.4 84.1 28.8 90.0 31.7 95.9 34.7 108 41.2 114 41.7
70 700 10 53.19.3563.411.173.612.978.813.983.914.994.116.910419.0
12 53.19.4963.411.373.613.278.814.283.915.294.117.210419.4
14 53.19.6463.411.573.613.478.814.483.915.494.117.610419.8
16 53.19.7963.411.773.613.678.814.783.915.794.117.910420.2
18 53.19.9563.411.973.613.978.815.083.916.094.118.310420.5
20 53.1 10.1 63.4 12.1 73.6 14.2 78.8 15.2 83.9 16.3 94.1 18.6 104 21.1
21 53.1 10.2 63.4 12.2 73.6 14.3 78.8 15.4 83.9 16.5 94.1 18.9 104 21.9
23 53.1 10.4 63.4 12.4 73.6 14.6 78.8 15.9 83.9 17.3 94.1 20.2 104 23.4
25 53.1 10.6 63.4 12.9 73.6 15.6 78.8 17.0 83.9 18.5 94.1 21.6 104 25.1
27 53.1 11.2 63.4 13.7 73.6 16.6 78.8 18.1 83.9 19.7 94.1 23.1 104 26.8
29 53.1 11.9 63.4 14.6 73.6 17.6 78.8 19.3 83.9 21.0 94.1 24.6 104 28.6
31 53.1 12.6 63.4 15.5 73.6 18.8 78.8 20.5 83.9 22.4 94.1 26.3 104 30.5
33 53.1 13.3 63.4 16.5 73.6 20.0 78.8 21.8 83.9 23.8 94.1 28.0 104 32.5
35 53.1 14.1 63.4 17.5 73.6 21.2 78.8 23.2 83.9 25.3 94.1 29.8 104 34.7
37 53.1 14.9 63.4 18.5 73.6 22.5 78.8 24.7 83.9 26.9 94.1 31.7 104 36.9
39 53.1 15.8 63.4 19.6 73.6 23.9 78.8 26.2 83.9 28.6 94.1 33.8 104 39.4
60 600 10 45.68.1354.39.5463.111.067.511.871.912.680.714.389.416.0
12 45.68.2554.39.6963.111.267.512.071.912.880.714.589.416.3
14 45.68.3754.39.8463.111.467.512.271.913.180.714.889.416.6
16 45.68.4954.310.063.111.667.512.471.913.380.715.189.416.9
18 45.68.6254.310.263.111.867.512.771.913.580.715.489.417.2
20 45.68.7654.310.363.112.067.512.971.913.880.715.789.417.6
21 45.68.8354.310.463.112.167.513.071.913.980.715.889.417.7
23 45.68.9754.310.663.112.467.513.371.914.280.716.489.418.9
25 45.69.1254.310.863.112.867.513.971.915.180.717.589.420.2
27 45.69.4554.311.563.113.767.514.871.916.180.718.789.421.5
29 45.6 10.0 54.3 12.2 63.1 14.5 67.5 15.8 71.9 17.1 80.7 19.9 89.4 22.9
31 45.6 10.6 54.3 12.9 63.1 15.4 67.5 16.8 71.9 18.2 80.7 21.2 89.4 24.5
33 45.6 11.2 54.3 13.7 63.1 16.4 67.5 17.8 71.9 19.3 80.7 22.6 89.4 26.0
35 45.6 11.9 54.3 14.5 63.1 17.4 67.5 18.9 71.9 20.5 80.7 24.0 89.4 27.7
37 45.6 12.5 54.3 15.3 63.1 18.4 67.5 20.1 71.9 21.8 80.7 25.5 89.4 29.5
39 45.6 13.2 54.3 16.2 63.1 19.5 67.5 21.3 71.9 23.2 80.7 27.1 89.4 31.4
