Daikin RXYQ22M7W1B [138/182] Capacity tables
![Daikin RXYQ22M7W1B [138/182] Capacity tables](/views2/1707499/page138/bg8a.png)
18
3
• Systems • Outdoor Units
137
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-18 40HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
130 1,300
-19.8 -20.0 69.8 16.4 69.5 18.3 69.2 20.3 69.0 21.2 68.9 22.2 68.6 24.1
-18.8 -19.0 72.2 17.7 71.9 19.5 71.6 21.3 71.5 22.3 71.3 23.2 71.0 25.0
-16.7 -17.0 77.1 19.9 76.8 21.6 76.5 23.3 76.4 24.2 76.2 25.0 75.9 26.7
-14.7 -15.0 82.0 21.8 81.7 23.4 81.4 25.0 81.3 25.8 81.1 26.6 80.8 28.2
-12.6 -13.0 86.9 23.5 86.6 25.0 86.3 26.5 86.2 27.3 86.0 28.0 85.7 29.5
-10.5 -11.0 91.8 25.0 91.5 26.4 91.2 27.8 91.1 28.5 90.9 29.3 90.6 30.7
-9.5-10.094.225.793.927.193.628.493.529.193.429.893.131.2
-8.5 -9.1 96.4 26.3 96.1 27.6 95.8 29.0 95.7 29.6 95.6 30.3 95.3 31.7
-7.0-7.6 10027.299.828.599.529.899.430.499.231.198.932.4
-5.0 -5.6 105 28.3 105 29.6 104 30.8 104 31.4 104 32.0 104 33.3
-3.0 -3.7 110 29.3 109 30.5 109 31.7 109 32.2 109 32.8 108 34.0
0.0 -0.7 117 30.7 117 31.8 116 32.9 116 33.4 116 34.0 116 35.1
3.0 2.2 124 31.8 124 32.9 123 33.9 123 34.4 123 35.0 123 36.0
5.0 4.1 129 32.5 128 33.5 128 34.5 128 35.0 128 35.5 128 36.5
7.0 6.0 133 33.2 133 34.1 133 35.1 133 35.6 133 36.1 132 37.0
9.0 7.9 138 33.8 138 34.7 137 35.6 137 36.1 137 36.6 137 37.5
11.0 9.8 143 34.3 142 35.2 142 36.1 142 36.6 142 37.0 142 37.9
13.0 11.8 148 34.9 147 35.8 147 36.6 147 37.1 147 37.5 143 37.1
15.0 13.7 152 35.4 152 36.2 152 37.1 151 37.5 151 37.9 143 35.7
120 1,200
-19.8 -20.0 69.4 19.0 69.1 20.8 68.8 22.5 68.7 23.4 68.6 24.3 68.3 26.1
-18.8 -19.0 71.8 20.1 71.5 21.8 71.3 23.5 71.1 24.4 71.0 25.2 70.7 26.9
-16.7 -17.0 76.7 22.2 76.4 23.8 76.2 25.3 76.0 26.1 75.9 26.9 75.6 28.5
-14.7 -15.0 81.6 24.0 81.3 25.4 81.1 26.9 80.9 27.7 80.8 28.4 80.5 29.9
-12.6 -13.0 86.5 25.5 86.2 26.9 86.0 28.3 85.8 29.0 85.7 29.7 85.4 31.1
-10.5 -11.0 91.4 26.9 91.1 28.2 90.9 29.5 90.7 30.2 90.6 30.9 90.3 32.2
-9.5-10.093.827.593.628.893.330.193.230.893.031.492.832.7
-8.5 -9.1 96.0 28.1 95.8 29.3 95.5 30.6 95.4 31.2 95.2 31.8 95.0 33.1
-7.0 -7.6 99.7 28.9 99.4 30.1 99.2 31.4 99.0 32.0 98.9 32.6 98.6 33.8
-5.0 -5.6 105 30.0 104 31.1 104 32.3 104 32.8 104 33.4 104 34.6
-3.0 -3.7 109 30.9 109 32.0 109 33.1 109 33.6 108 34.2 108 35.3
0.0 -0.7 117 32.2 116 33.2 116 34.2 116 34.7 116 35.2 116 36.2
3.0 2.2 124 33.2 123 34.2 123 35.2 123 35.6 123 36.1 123 37.1
5.0 4.1 128 33.9 128 34.8 128 35.7 128 36.2 128 36.7 127 37.6
7.0 6.0 133 34.5 133 35.4 132 36.3 132 36.7 132 37.2 132 38.0
9.0 7.9 138 35.0 137 35.9 137 36.8 137 37.2 137 37.6 132 36.6
11.0 9.8 142 35.6 142 36.4 142 37.2 142 37.6 141 38.1 132 35.2
13.0 11.8 147 36.1 147 36.9 147 37.7 147 38.1 142 36.7 132 33.7
15.0 13.7 152 36.5 152 37.3 151 38.1 147 36.8 142 35.4 132 32.5
110 1,100
-19.8 -20.0 69.0 21.6 68.7 23.2 68.5 24.8 68.4 25.6 68.2 26.4 68.0 28.1
-18.8 -19.0 71.4 22.6 71.2 24.2 70.9 25.7 70.8 26.5 70.7 27.3 70.4 28.9
-16.7 -17.0 76.3 24.5 76.1 25.9 75.8 27.4 75.7 28.1 75.6 28.9 75.3 30.3
-14.7 -15.0 81.2 26.1 81.0 27.5 80.7 28.8 80.6 29.5 80.5 30.2 80.2 31.6
-12.6 -13.0 86.1 27.6 85.9 28.8 85.6 30.1 85.5 30.8 85.4 31.4 85.1 32.7
-10.5 -11.0 91.0 28.8 90.8 30.0 90.5 31.3 90.4 31.9 90.3 32.5 90.0 33.7
-9.5-10.093.429.493.230.693.031.892.832.492.732.992.534.1
-8.5 -9.1 95.6 29.9 95.4 31.1 95.2 32.2 95.0 32.8 94.9 33.4 94.7 34.5
-7.0 -7.6 99.3 30.7 99.1 31.8 98.8 32.9 98.7 33.5 98.6 34.0 98.3 35.1
-5.0 -5.6 104 31.7 104 32.7 104 33.8 104 34.3 103 34.8 103 35.9
-3.0 -3.7 109 32.5 109 33.5 108 34.5 108 35.0 108 35.5 108 36.5
0.0 -0.7 116 33.7 116 34.6 116 35.5 116 36.0 115 36.5 115 37.4
3.0 2.2 123 34.6 123 35.5 123 36.4 123 36.8 123 37.3 121 37.7
5.0 4.1 128 35.2 128 36.1 127 36.9 127 37.4 127 37.8 121 36.0
7.0 6.0 133 35.8 132 36.6 132 37.4 132 37.8 130 37.5 121 34.4
9.0 7.9 137 36.3 137 37.1 137 37.9 135 37.4 130 35.9 121 33.0
11.0 9.8 142 36.8 142 37.5 139 37.4 135 35.9 130 34.5 121 31.7
13.0 11.8 147 37.2 147 38.0 139 35.8 135 34.5 130 33.1 121 30.5
15.0 13.7 151 37.7 148 37.2 139 34.5 135 33.2 130 31.9 121 29.4
100 1,000
-19.8 -20.0 68.6 24.2 68.4 25.6 68.1 27.1 68.0 27.8 67.9 28.6 67.7 30.1
-18.8 -19.0 71.0 25.1 70.8 26.5 70.6 28.0 70.5 28.7 70.4 29.4 70.1 30.8
-16.7 -17.0 75.9 26.8 75.7 28.1 75.5 29.5 75.4 30.1 75.3 30.8 75.0 32.1
-14.7 -15.0 80.8 28.3 80.6 29.5 80.4 30.8 80.3 31.4 80.2 32.0 79.9 33.2
-12.6 -13.0 85.7 29.6 85.5 30.8 85.3 31.9 85.2 32.5 85.0 33.1 84.8 34.3
-10.5 -11.0 90.6 30.8 90.4 31.9 90.2 33.0 90.0 33.5 89.9 34.1 89.7 35.2
-9.5-10.093.131.392.832.492.633.492.534.092.434.592.235.6
-8.5 -9.1 95.3 31.8 95.0 32.8 94.8 33.8 94.7 34.4 94.6 34.9 94.4 35.9
-7.0 -7.6 98.9 32.5 98.7 33.5 98.5 34.5 98.4 35.0 98.3 35.5 98.0 36.5
-5.0 -5.6 104 33.3 104 34.3 103 35.2 103 35.7 103 36.2 103 37.1
-3.0 -3.7 108 34.1 108 35.0 108 35.9 108 36.4 108 36.8 108 37.7
0.0 -0.7 116 35.1 116 36.0 115 36.9 115 37.3 115 37.7 110 36.2
3.0 2.2 123 36.1 123 36.9 122 37.7 122 38.1 118 36.6 110 33.6
5.0 4.1 128 36.6 127 37.4 127 37.8 122 36.4 118 35.0 110 32.2
7.0 6.0 132 37.1 132 37.8
127 36.2 122 34.8 118 33.5 110 30.8
9.0 7.9 137 37.6 135 37.4 127 34.7 122 33.4 118 32.1 110 29.6
11.0 9.8 141 38.0 135 35.9 127 33.4 122 32.1 118 30.9 110 28.5
13.0 11.8 143 36.9 135 34.5 127 32.0 122 30.8 118 29.7 110 27.4
15.0 13.7 143 35.6 135 33.2 127 30.9 122 29.7 118 28.6 110 26.4
