• Systems • Outdoor Units
85
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-22 48HP
48HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
50 600 10 45.08.4453.79.7662.411.266.811.971.112.779.814.288.515.8
12 45.08.5453.79.9062.411.366.812.171.112.979.814.588.516.1
14 45.08.6653.710.062.411.566.812.371.113.179.814.788.516.4
16 45.08.7753.710.262.411.766.812.571.113.379.815.088.516.7
18 45.08.9053.710.362.411.966.812.771.113.579.815.288.517.0
20 45.09.0253.710.562.412.166.812.971.113.879.815.588.517.3
21 45.09.0953.710.662.412.266.813.071.113.979.815.688.517.5
23 45.09.2253.710.862.412.466.813.371.114.179.815.988.517.9
25 45.09.3753.710.962.412.666.813.571.114.679.816.788.519.1
27 45.09.5253.711.362.413.366.814.471.115.579.817.888.520.3
29 45.0 10.1 53.7 12.0 62.4 14.1 66.8 15.3 71.1 16.5 79.8 19.0 88.5 21.6
31 45.0 10.6 53.7 12.7 62.4 15.0 66.8 16.2 71.1 17.5 79.8 20.2 88.5 23.0
33 45.0 11.2 53.7 13.5 62.4 15.9 66.8 17.2 71.1 18.5 79.8 21.4 88.5 24.5
35 45.0 11.9 53.7 14.2 62.4 16.8 66.8 18.2 71.1 19.7 79.8 22.7 88.5 26.0
37 45.0 12.5 53.7 15.0 62.4 17.8 66.8 19.3 71.1 20.8 79.8 24.1 88.5 27.6
39 45.0 13.2 53.7 15.9 62.4 18.8 66.8 20.4 71.1 22.1 79.8 25.6 88.5 29.4
