• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
50
3 Capacity tables
3-1 Cooling capacity
3-1-11 26HP
26HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 845 10 63.6 11.3 75.9 13.9 88.1 16.51 94.3 16.9 96.1 16.5 98.4 15.8 101 15.1
12 63.6 11.5 75.9 14.1 88.1 16.82 93.8 16.8 94.9 16.4 97.2 15.7 99.5 15.5
14 63.6 11.8 75.9 14.4 88.1 17.03 92.5 16.7 93.7 16.3 96.0 16.2 98.3 16.3
16 63.6 12.0 75.9 14.7 88.1 16.94 91.3 16.8 92.4 16.9 94.7 17.1 97.0 17.2
18 63.6 12.2 75.9 15.0 88.1 17.60 90.0 17.7 91.2 17.8 93.5 17.9 95.8 18.1
20 63.6 12.5 75.9 16.0 87.7 18.45 88.8 18.5 90.0 18.6 92.2 18.8 94.5 19.0
21 63.6 12.8 75.9 16.5 87.0 18.88 88.2 19.0 89.3 19.1 91.6 19.3 93.9 19.5
23 63.6 13.7 75.9 17.7 85.8 19.74 86.9 19.8 88.1 19.9 90.4 20.1 92.7 20.3
25 63.6 14.7 75.9 19.0 84.6 20.61 85.7 20.7 86.9 20.8 89.1 21.0 91.4 21.2
27 63.6 15.7 75.9 20.3 83.3 21.47 84.5 21.6 85.6 21.7 87.9 21.9 90.2 22.2
29 63.6 16.7 75.9 21.7 82.1 22.35 83.2 22.5 84.4 22.6 86.7 22.8 89.0 23.1
31 63.6 17.8 75.9 23.0 80.8 23.22 82.0 23.3 83.1 23.5 85.4 23.7 87.7 24.0
33 63.6 19.0 75.9 23.8 79.6 24.10 80.8 24.2 81.9 24.4 84.2 24.6 86.5 24.9
35 63.6 20.3 75.9 24.7 78.4 24.98 79.5 25.1 80.7 25.3 83.0 25.5 85.3 25.8
37 63.6 21.6 74.8 25.6 77.1 25.87 78.3 26.0 79.4 26.2 81.7 26.5 83.6 26.8
39 63.6 23.0 73.1 26.4 74.3 26.76 74.9 26.9 75.6 27.1 76.8 27.4 78.0 27.7
120 780 10 58.7 10.4 70.0 12.7 81.3 15.04 87.0 16.3 92.7 16.9 96.8 16.3 98.9 15.7
12 58.7 10.5 70.0 12.9 81.3 15.33 87.0 16.6 92.7 16.9 95.6 16.2 97.7 15.6
14 58.7 10.7 70.0 13.1 81.3 15.62 87.0 16.9 92.2 16.8 94.3 16.1 96.5 16.2
16 58.7 10.9 70.0 13.4 81.3 15.93 87.0 17.0 91.0 16.8 93.1 17.0 95.2 17.1
18 58.7 11.2 70.0 13.7 81.3 16.47 87.0 17.6 89.7 17.7 91.9 17.8 94.0 18.0
20 58.7 11.4 70.0 14.2 81.3 17.71 87.0 18.4 88.5 18.5 90.6 18.7 92.7 18.9
21 58.7 11.5 70.0 14.7 81.3 18.35 86.8 18.9 87.9 19.0 90.0 19.1 92.1 19.3
23 58.7 12.3 70.0 15.8 81.3 19.63 85.6 19.7 86.6 19.8 88.8 20.0 90.9 20.2
25 58.7 13.1 70.0 16.9 81.3 20.49 84.4 20.6 85.4 20.7 87.5 20.9 89.6 21.1
27 58.7 14.0 70.0 18.0 81.3 21.35 83.1 21.5 84.2 21.6 86.3 21.8 88.4 22.0
29 58.7 14.9 70.0 19.3 80.8 22.21 81.9 22.3 82.9 22.4 85.1 22.7 87.2 22.9
31 58.7 15.9 70.0 20.5 79.6 23.08 80.6 23.2 81.7 23.3 83.8 23.5 85.9 23.8
33 58.7 17.0 70.0 21.9 78.3 23.95 79.4 24.1 80.5 24.2 82.6 24.4 84.7 24.7
35 58.7 18.0 70.0 23.4 77.1 24.82 78.2 25.0 79.2 25.1 81.3 25.3 83.5 25.6
37 58.7 19.2 70.0 24.9 75.9 25.70 76.9 25.8 78.0 26.0 80.1 26.3 82.2 26.5
39 58.7 20.4 70.0 26.3 74.3 26.58 74.9 26.7 75.6 26.9 76.8 27.2 78.0 27.5
110 715 10 53.8 9.41 64.2 11.5 74.6 13.60 79.8 14.7 84.9 15.8 95.2 16.8 97.1 16.2
12 53.8 9.57 64.2 11.7 74.6 13.86 79.8 15.0 84.9 16.1 94.0 16.7 95.9 16.1
14 53.8 9.75 64.2 11.9 74.6 14.12 79.8 15.3 84.9 16.4 92.7 16.6 94.7 16.1
16 53.8 9.93 64.2 12.1 74.6 14.40 79.8 15.6 84.9 16.7 91.5 16.8 93.4 17.0
18 53.8 10.1 64.2 12.4 74.6 14.69 79.8 16.0 84.9 17.6 90.2 17.7 92.2 17.8
20 53.8 10.3 64.2 12.6 74.6 15.56 79.8 17.2 84.9 18.4 89.0 18.6 90.9 18.7
21 53.8 10.4 64.2 13.0 74.6 16.11 79.8 17.8 84.9 18.8 88.4 19.0 90.3 19.2
23 53.8 10.9 64.2 13.9 74.6 17.27 79.8 19.1 84.9 19.7 87.1 19.9 89.1 20.0
25 53.8 11.6 64.2 14.9 74.6 18.49 79.8 20.5 84.0 20.6 85.9 20.7 87.8 20.9
27 53.8 12.4 64.2 15.9 74.6 19.78 79.8 21.3 82.7 21.4 84.7 21.6 86.6 21.8
29 53.8 13.2 64.2 17.0 74.6 21.14 79.8 22.2 81.5 22.3 83.4 22.5 85.4 22.7
31 53.8 14.1 64.2 18.1 74.6 22.57 79.3 23.0 80.3 23.2 82.2 23.4 84.1 23.6
33 53.8 15.0 64.2 19.3 74.6 23.80 78.0 23.9 79.0 24.0 81.0 24.3 82.9 24.5
35 53.8 16.0 64.2 20.5 74.6 24.67 76.8 24.8 77.8 24.9 79.7 25.1 81.7 25.4
37 53.8 17.0 64.2 21.9 74.6 25.54 75.6 25.7 76.5 25.8 78.5 26.0 80.4 26.3
39 53.8 18.0 64.2 23.3 73.4 26.41 74.3 26.5 75.3 26.7 76.8 26.9 78.0 27.2
100 650 10 48.9 8.48 58.4 10.3 67.8 12.19 72.5 13.2 77.2 14.2 86.6 16.2 95.3 16.8
12 48.9 8.63 58.4 10.5 67.8 12.42 72.5 13.4 77.2 14.4 86.6 16.5 94.1 16.7
14 48.9 8.79 58.4 10.7 67.8 12.65 72.5 13.7 77.2 14.7 86.6 16.8 92.9 16.6
16 48.9 8.95 58.4 10.9 67.8 12.90 72.5 13.9 77.2 15.0 86.6 17.0 91.6 16.8
18 48.9 9.11 58.4 11.1 67.8 13.15 72.5 14.2 77.2 15.3 86.6 17.6 90.4 17.7
20 48.9 9.28 58.4 11.3 67.8 13.55 72.5 14.9 77.2 16.4 86.6 18.4 89.1 18.6
21 48.9 9.37 58.4 11.4 67.8 14.03 72.5 15.5 77.2 17.0 86.6 18.9 88.5 19.0
23 48.9 9.62 58.4 12.2 67.8 15.03 72.5 16.6 77.2 18.2 85.5 19.7 87.3 19.9
25 48.9 10.3 58.4 13.0 67.8 16.08 72.5 17.7 77.2 19.5 84.3 20.6 86.0 20.7
27 48.9 10.9 58.4 13.9 67.8 17.18 72.5 19.0 77.2 20.8 83.0 21.4 84.8 21.6
29 48.9 11.7 58.4 14.8 67.8 18.35 72.5 20.3 77.2 22.1 81.8 22.3 83.6 22.5
31 48.9 12.4 58.4 15.8 67.8 19.58 72.5 21.6 77.2 23.0 80.6 23.2 82.3 23.4
33 48.9 13.2 58.4 16.8 67.8 20.88 72.5 23.1 77.2 23.9 79.3 24.1 81.1 24.3
35 48.9 14.0 58.4 17.9 67.8 22.26 72.5 24.6 76.3 24.7 78.1 24.9 79.9 25.2
37 48.9 14.9 58.4 19.0 67.8 23.71 72.5 25.5 75.1 25.6 76.9 25.8 78.6 26.1
39 48.9 15.8 58.4 20.3 67.8 25.26 72.5 26.4 73.9 26.5 75.6 26.7 77.4 27.0
