• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
78
3 Capacity tables
3-1 Cooling capacity
3-1-20 44HP
44HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90 990 10 74.4 12.9 88.7 15.5 103 18.4 110 19.8 117 21.3 132 24.3 146 27.4
12 74.4 13.1 88.7 15.8 103 18.7 110 20.2 117 21.7 132 24.8 146 27.9
14 74.4 13.3 88.7 16.1 103 19.0 110 20.6 117 22.1 132 25.3 146 28.5
16 74.4 13.6 88.7 16.4 103 19.4 110 21.0 117 22.5 132 25.7 146 28.9
18 74.4 13.8 88.7 16.7 103 19.8 110 21.4 117 23.0 132 26.3 146 29.8
20 74.4 14.1 88.7 17.0 103 20.2 110 21.8 117 23.8 132 28.2 146 31.3
21 74.4 14.2 88.7 17.2 103 20.5 110 22.6 117 24.7 132 29.2 146 32.0
23 74.4 14.5 88.7 17.9 103 22.0 110 24.2 117 26.4 132 31.3 144 33.5
25 74.4 15.2 88.7 19.1 103 23.5 110 25.8 117 28.3 132 33.6 142 34.9
27 74.4 16.2 88.7 20.4 103 25.1 110 27.6 117 30.2 132 35.9 140 36.4
29 74.4 17.3 88.7 21.7 103 26.8 110 29.5 117 32.3 132 37.6 138 37.9
31 74.4 18.4 88.7 23.1 103 28.5 110 31.4 117 34.5 132 39.1 136 39.4
33 74.4 19.5 88.7 24.6 103 30.4 110 33.5 117 36.8 131 40.5 134 40.8
35 74.4 20.7 88.7 26.2 103 32.4 110 35.7 117 39.2 129 42.0 132 42.3
37 74.4 22.0 88.7 27.8 103 34.5 110 38.0 117 41.8 127 43.5 130 43.8
39 74.4 23.3 88.7 29.6 103 36.7 110 40.5 117 44.5 123 45.0 125 45.3
80 880 10 66.1 11.4 78.9 13.7 91.6 16.1 98.0 17.3 104 18.6 117 21.2 130 23.9
12 66.1 11.6 78.9 13.9 91.6 16.4 98.0 17.7 104 19.0 117 21.6 130 24.4
14 66.1 11.8 78.9 14.2 91.6 16.7 98.0 18.0 104 19.3 117 22.0 130 24.8
16 66.1 12.0 78.9 14.4 91.6 17.0 98.0 18.3 104 19.7 117 22.5 130 25.3
18 66.1 12.2 78.9 14.7 91.6 17.3 98.0 18.7 104 20.1 117 22.9 130 25.8
20 66.1 12.4 78.9 15.0 91.6 17.7 98.0 19.0 104 20.5 117 23.7 130 27.6
21 66.1 12.6 78.9 15.1 91.6 17.8 98.0 19.2 104 20.9 117 24.6 130 28.6
23 66.1 12.8 78.9 15.4 91.6 18.7 98.0 20.5 104 22.4 117 26.3 130 30.7
25 66.1 13.2 78.9 16.4 91.6 20.0 98.0 21.9 104 23.9 117 28.2 130 32.8
27 66.1 14.0 78.9 17.5 91.6 21.3 98.0 23.4 104 25.5 117 30.1 130 35.1
29 66.1 14.9 78.9 18.6 91.6 22.7 98.0 24.9 104 27.2 117 32.2 130 37.6
31 66.1 15.8 78.9 19.8 91.6 24.2 98.0 26.6 104 29.0 117 34.3 130 39.0
33 66.1 16.8 78.9 21.0 91.6 25.7 98.0 28.3 104 30.9 117 36.6 130 40.5
35 66.1 17.8 78.9 22.3 91.6 27.4 98.0 30.1 104 33.0 117 39.1 129 42.0
37 66.1 18.9 78.9 23.7 91.6 29.1 98.0 32.0 104 35.1 117 41.6 127 43.4
39 66.1 20.0 78.9 25.2 91.6 31.0 98.0 34.1 104 37.3 117 44.3 125 44.9
70 770 10 57.9 10.1 69.0 11.9 80.2 13.9 85.8 15.0 91.3 16.0 102 18.2 114 20.5
12 57.9 10.2 69.0 12.1 80.2 14.2 85.8 15.2 91.3 16.3 102 18.6 114 20.9
14 57.9 10.4 69.0 12.3 80.2 14.4 85.8 15.5 91.3 16.6 102 18.9 114 21.3
16 57.9 10.5 69.0 12.6 80.2 14.7 85.8 15.8 91.3 16.9 102 19.3 114 21.7
18 57.9 10.7 69.0 12.8 80.2 15.0 85.8 16.1 91.3 17.3 102 19.7 114 22.1
20 57.9 10.9 69.0 13.0 80.2 15.2 85.8 16.4 91.3 17.6 102 20.0 114 22.7
21 57.9 11.0 69.0 13.1 80.2 15.4 85.8 16.6 91.3 17.8 102 20.4 114 23.5
23 57.9 11.2 69.0 13.4 80.2 15.7 85.8 17.1 91.3 18.6 102 21.8 114 25.2
25 57.9 11.4 69.0 13.9 80.2 16.7 85.8 18.3 91.3 19.9 102 23.3 114 27.0
27 57.9 12.0 69.0 14.8 80.2 17.8 85.8 19.5 91.3 21.2 102 24.9 114 28.8
29 57.9 12.8 69.0 15.7 80.2 19.0 85.8 20.8 91.3 22.6 102 26.5 114 30.8
31 57.9 13.5 69.0 16.7 80.2 20.2 85.8 22.1 91.3 24.1 102 28.3 114 32.8
33 57.9 14.3 69.0 17.7 80.2 21.5 85.8 23.5 91.3 25.6 102 30.1 114 35.0
35 57.9 15.2 69.0 18.8 80.2 22.8 85.8 25.0 91.3 27.3 102 32.1 114 37.3
37 57.9 16.1 69.0 19.9 80.2 24.2 85.8 26.6 91.3 29.0 102 34.2 114 39.8
39 57.9 17.0 69.0 21.1 80.2 25.7 85.8 28.2 91.3 30.8 102 36.4 114 42.4
60 660 10 49.68.7559.210.368.711.973.512.778.313.687.815.497.417.2
12 49.68.8859.210.468.712.173.512.978.313.887.815.697.417.5
14 49.69.0159.210.668.712.373.513.278.314.187.815.997.417.9
16 49.69.1459.210.868.712.573.513.478.314.387.816.297.418.2
18 49.69.2859.210.968.712.773.513.678.314.687.816.597.418.6
20 49.69.4359.211.168.712.973.513.978.314.987.816.897.418.9
21 49.69.5059.211.268.713.173.514.078.315.087.817.097.419.1
23 49.69.6659.211.468.713.373.514.378.315.387.817.797.420.3
25 49.69.8259.211.668.713.873.515.078.316.287.818.997.421.7
27 49.6 10.2 59.2 12.3 68.7 14.7 73.5 16.0 78.3 17.3 87.8 20.1 97.4 23.2
29 49.6 10.8 59.2 13.1 68.7 15.6 73.5 17.0 78.3 18.4 87.8 21.4 97.4 24.7
31 49.6 11.4 59.2 13.9 68.7 16.6 73.5 18.1 78.3 19.6 87.8 22.8 97.4 26.3
33 49.6 12.1 59.2 14.7 68.7 17.6 73.5 19.2 78.3 20.8 87.8 24.3 97.4 28.0
35 49.6 12.8 59.2 15.6 68.7 18.7 73.5 20.4 78.3 22.1 87.8 25.8 97.4 29.8
37 49.6 13.5 59.2 16.5 68.7 19.8 73.5 21.6 78.3 23.5 87.8 27.5 97.4 31.7
39 49.6 14.3 59.2 17.5 68.7 21.0 73.5 22.9 78.3 24.9 87.8 29.2 97.4 33.8
