Daikin RXYQ22M7W1B [149/182] Capacity tables
![Daikin RXYQ22M7W1B [149/182] Capacity tables](/views2/1707499/page149/bg95.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
148
3 Capacity tables
3-2 Heating capacity
3-2-21 46HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 575
-19.8 -20.0 75.3 40.9 75.1 41.8 72.5 40.4 70.2 38.9 67.8 37.4 63.2 34.4
-18.8 -19.0 78.0 41.5 77.2 41.6 72.5 38.7 70.2 37.2 67.8 35.8 63.2 33.0
-16.7 -17.0 81.8 41.1 77.2 38.3 72.5 35.6 70.2 34.3 67.8 33.0 63.2 30.4
-14.7 -15.0 81.8 38.0 77.2 35.5 72.5 33.0 70.2 31.8 67.8 30.6 63.2 28.3
-12.6 -13.0 81.8 35.4 77.2 33.1 72.5 30.8 70.2 29.7 67.8 28.6 63.2 26.5
-10.5 -11.0 81.8 33.1 77.2 31.0 72.5 28.9 70.2 27.9 67.8 26.9 63.2 24.9
-9.5-10.081.832.177.230.072.528.070.227.067.826.163.224.2
-8.5 -9.1 81.8 31.2 77.2 29.2 72.5 27.3 70.2 26.3 67.8 25.4 63.2 23.5
-7.0 -7.6 81.8 29.9 77.2 28.0 72.5 26.1 70.2 25.2 67.8 24.3 63.2 22.6
-5.0 -5.6 81.8 28.2 77.2 26.5 72.5 24.8 70.2 23.9 67.8 23.1 63.2 21.5
-3.0 -3.7 81.8 26.9 77.2 25.2 72.5 23.6 70.2 22.8 67.8 22.0 63.2 20.5
0.0 -0.781.825.077.223.572.522.070.221.367.820.663.219.2
3.0 2.2 81.8 23.4 77.2 22.0 72.5 20.7 70.2 20.0 67.8 19.3 63.2 18.0
5.0 4.1 81.8 22.5 77.2 21.2 72.5 19.9 70.2 19.3 67.8 18.6 63.2 17.4
7.0 6.0 81.8 21.7 77.2 20.4 72.5 19.2 70.2 18.6 67.8 18.0 63.2 16.8
9.0 7.9 81.8 20.9 77.2 19.7 72.5 18.5 70.2 17.9 67.8 17.4 63.2 16.2
11.0 9.8 81.820.277.219.072.517.970.217.467.816.863.215.7
13.0 11.8 81.8 19.5 77.2 18.4 72.5 17.3 70.2 16.8 67.8 16.3 63.2 15.2
15.0 13.7 81.8 18.9 77.2 17.8 72.5 16.8 70.2 16.3 67.8 15.8 63.2 14.8
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
