Si39-502A Test Operation
Test Operation 89
1.1.2 Turn Power On
Be sure to turn the power on 6 hours before starting operation to protect
compressors. (to power on clankcase heater)
Check to be sure the transmission is normal.
The transmission is normal if the LEDs display conditions as shown in
table below.
(*) The master unit is the outdoor unit to which the transmission wiring for
the indoor units is conncted.
The other outdoor units are slave units.
Make field settings if needed.
(For the setting procedure, refer to information in "3.2 Field Settings from
Outdoor Unit" on page onward.)
For the outdoor-multi system, make field settings with the master unit.
(Field settings made with the slave unit will be all invalid.)
If a full amount of refrigerant cannot be charged with the outdoor unit OFF,
charge the refrigerant by the deficient amount according to the following
procedure.
Is the power supplied to the outdoor unit and the indoor unit?
Bring the stop valves to the following conditions, respectively.
The system will automatically start operation.
*The "H2P" blinks during operation, and "TEST OPERAION" and
"UNDER CENTRALIZED CONTROL" are displayed on the remote
controller.
Even if no stop operation is conducted, the equipment will automatically
stop after a lapse of 30 minutes at maximum.
Disconnect the refrigerant charge hose and then open the liquid-side
stop valve.
Turn outdoor unit and indoor
unit power on.
Check the LED display of the
outdoor unit PC board.
Set the system to "refrigerant
additional charging operation"
while in Setting mode 2.
Stopping equipment
Check the power supply.
Check the stop valves.
Make field settings with outdoor
unit PC board.
Additional charging of
refrigerant
LED display
(Default status before
delivery)
Micro-
computer
operation
monitor
MODE
HAP
9
9
9
9
9
9
9
9
H1P
7
7
7
7
7
7
7
7
H2P
7
7
7
7
7
7
7
7
H3P
7
7
7
7
7
7
H4P
7
7
7
7
7
7
7
7
H5P
7
7
7
7
7
7
7
7
H6P
7
7
7
7
7
7
7
7
H7P
7
7
7
7
7
7
7
7
H8P
7
7
7
9
9
7
7
Master
Slave1
Slave2
One outdoor unit installed
Liquid-side stop valve
Closed
Gas-side stop valve
Open
When multiple
outdoor unit
installed (*)
TEST
COOL/HEAT select
LED display
7
ON 7
7
OFF 9
9
Blinking
IND
MASTER
SLAVE
Low
noise
Demand
Multi
Operation after stop
Press the CHECK button (BS3)
after charging the specified
amount of refrigerant.
