Si39-502A Specifications
Specifications 29
Ceiling Mounted Duct Type
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
4 External static pressure is changeable to change over the connectors inside electrical box, this pressure
means
"High static pressure-Standard".
5 Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its
colorimetric method (gravity method) 50% or more.
6 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
7 Anechoic chamber conversion value, measured at a point 1.5m downward from the unit center. These
values are normally somewhat higher during actual operation as a result of ambient conditions.
Model FXMQ100MVE FXMQ125MVE FXMQ200MVE FXMQ250MVE
1 Cooling Capacity (19.5°CWB)
RT 3.3 4.1 6.5 8.2
kcal/h 10,000 12,500 19,800 24,800
Btu/h 39,600 49,500 78,500 98,300
kW 11.6 14.5 23.0 28.8
2 Cooling Capacity (19.0°CWB) kW 11.2 14.0 22.4 28.0
3 Heating Capacity
RT 3.6 4.5 7.1 8.9
kcal/h 10,800 13,800 21,500 27,100
Btu/h 42,700 54,600 85,300 107,000
kW 12.5 16.0 25.0 31.5
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 390×1,110×690 390×1,110×690 470×1,380×1,100 470×1,380×1,100
Coil (Cross
Fin Coil)
Rows×Stages×Fin
Pitch
mm 3×16×2.0 3×16×2.0 3×26×2.0 3×26×2.0
Face Area m² 0.319 0.319 0.68 0.68
Fan
Model 2D11/2D3AG1VE 2D11/2D3AF1VE D13/4G2DA1×2D13/4G2DA1×2
Type Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output × Number
of Units
W 270×1 430×1380×2 380×2
Air Flow Rate (H/L)
m³/min 29/23 36/29 58/50 72/62
cfm 1,024/812 1,271/1,024 2,047/1,765 2,542/2,189
External Static
Pressure 50 / 60Hz
Pa 157/172-98/98
4 191/245-152/172
4 221/270-132
4 270/191-147
4
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber Glass Fiber
Air Filter
5
5
5
5
Piping
Connections
Liquid Pipes mm φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ19.1(Brazing Connection) φ22.2 (Brazing Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
PS1B PS1B
Machine Weight (Mass) kg 63 65 137 137
7 Sound Level (H/L)
50/60Hz
220V
dBA
43/39 45/42 48/45 48/45
50Hz
240V
45/41 47/44 49/46 49/46
Safety Devices
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Protector for Fan
Motor
Fuse,
Thermal Protector for Fan
Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A M(A) Series R-410A M(A) Series R-410A M(A) Series R-410A M(A) Series
Standard Accessories
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Sealing
Pads, Connection Pipes,
Screws, Clamps.
Operation Manual,
Installation Manual, Sealing
Pads, Connection Pipes,
Screws, Clamps.
Drawing No. C: 3D038814
()()
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
RT=kW×0.284
cfm=m³/min×35.3
