Daikin RXYQ10MY1K [192/310] Outdoor unit malfunction of discharge pipe thermistor r3 r31 or 32t
![Daikin RXYQ8MY1K [192/310] Outdoor unit malfunction of discharge pipe thermistor r3 r31 or 32t](/views2/1714922/page192/bgc0.png)
Si39-502A Troubleshooting by Indication on the Remote Controller
Troubleshooting 181
3.25
“
J3
”
Outdoor Unit: Malfunction of Discharge Pipe
Thermistor (R3, R31 or 32T)
Remote
Controller
Display
J3
Applicable
Models
RXYQ8~30MY1K (E), YLK (E)
Method of
Malfunction
Detection
Malfunction is detected from the temperature detected by discharge pipe temperature
thermistor.
Malfunction
Decision
Conditions
When a short circuit or an open circuit in the discharge pipe temperature thermistor is detected.
Supposed
Causes
Defect of thermistor (R31T or R32T) for outdoor unit discharge pipe
Defect of outdoor unit PC board (A1P)
Troubleshooting
The alarm indicator is displayed when the fan is being used also.
∗ Refer to “Thermistor Resistance / Temperature Characteristics” table on P278.
(V3072)
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Resistance
is normal when
measured after
disconnecting the thermistor
R31 or 32T from the outdoor
unit PC board.
(3.5kΩ~
400kΩ)
Replace outdoor unit PC board
(A1P).
Connect the connector and turn on
again.
NO
NO
Replace the thermistor
(R31 or 32T).
YES
YES
Connector
is connected to X34A
of outdoor unit
PC board
(A1P).
