Daikin RXYQ10MY1K [79/310] Pressure equalization prior to startup
![Daikin RXYQ8MY1K [79/310] Pressure equalization prior to startup](/views2/1714922/page79/bg4f.png)
Special Control Si39-502A
68 Function
3.7 Pressure Equalization Prior to Startup
Actuator Operation Remarks
Compressor OFF —
Outdoor unit fan
Cooling:OFF
Heating:STEP 4
—
Four way valve Holds —
Main motorized valve (EV1) 0 pls —
Subcooling motorized valve (EV2) 0 pls —
Hot gas bypass valve (SVP) OFF —
Receiver gas discharging valve
(SVG)
OFF —
Non-operating unit liquid pipe stop
valve (SVSL)
ON —
Ending conditions 10 sec. —
Indoor unit actuator Operation
Cooling operation
Fan Remote controller
EV All indoor units:0 pls
Heating operation
Fan OFF
EV All indoor units:0 pls
