Specifications Si39-502A
8 Specifications
1. Specifications
1.1 Outdoor Units
1.1.1 50Hz
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB.
2 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 46°CDB.
3 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB.
4 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 46°CDB.
5 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB.
6 Sound level : Anechoic chamber conversion value, measured at a point 1 m in front of the unit at a height
of 1.5m. The Sound level of “Combination Unit” is a supposed value. During actual operation, these
values are normally somewhat higher as a result of ambient conditions.
7 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as
RXYQ8MY1KE.
Model Name RXYQ8MY1K(E) RXYQ10MY1K(E)
1 /
2 Cooling Capacity
RT 6.6 / 6.5 8.0 / 6.8
Btu / h 78,800 / 77,800 96,200 / 82,200
kcal / h 19,900 / 19,600 24,300 / 20,700
kW 23.1 / 22.8 28.2 / 24.1
3 /
4 Cooling Capacity
RT 6.4 / 6.4 8.0 / 6.8
Btu / h 76,400 / 76,400 95,500 / 82,200
kcal / h 19,300 / 19,300 24,100 / 20,700
kW 22.4 / 22.4 28.0 / 24.1
5 Heating Capacity
RT 7.1 8.9
Btu / h 85,300 107,000
kcal / h 21,500 27,100
kW 25.0 31.5
Casing Color
Without (E): Ivory White (5Y7.5 / 1)
With (E): Light Camel (2.5Y6.5 / 1.5)
Without (E): Ivory White (5Y7.5 / 1)
With (E): Light Camel (2.5Y6.5 / 1.5)
Dimensions: (H×W×D) mm 1600×1240×765 1600×1240×765
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 13.72+10.53 13.72+10.53
Number of Revolutions r.p.m 6480, 2900 6480, 2900
Motor Output×Number
of Units
kW (0.7+4.5)×1 (1.6+4.5)×1
Starting Method Direct on line (inverter drive) Direct on line (inverter drive)
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×10.75×1
Air Flow Rate m³/min 210 210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipe mm φ19.1 (Flare Connection) φ22.2 (Brazing Connection)
Product Mass (Machine Weight) kg 268 268
6 Sound Level dBA 60 60
Safety Devices
High Pressure Switch, Fan Driver Overload Protector,
Over Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector,
Over Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 14~100 14~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 9.4 9.6
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C: 4D050288 C: 4D050289
The Reference Number
C~: Partly corrected drawings.
J~: Original drawing is Japanese
V~: Printing Convenience
Conversion Formulae
RT=kW×0.284
Btu/h=kW×3412
kcal/h=kW×860
cfm=m³/min×35.3
