Daikin RXYQ10MY1K [50/310] Bev units
![Daikin RXYQ8MY1K [50/310] Bev units](/views2/1714922/page50/bg32.png)
Si39-502A Specifications
Specifications 39
Wall Mounted Type
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp; 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp; 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
5 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of ambient conditions.
BEV Units
Model FXAQ40MHV1 FXAQ50MHV1
1 Cooling Capacity (19.5°CWB)
RT 1.3 1.6
kcal/h 4,000 5,000
Btu/h 16,000 19,800
kW 4.7 5.8
2 Cooling Capacity (19.0°CWB) kW 4.5 5.6
3 Heating Capacity
RT 1.4 1.8
kcal/h 4,300 5,400
Btu/h 17,100 21,500
kW 5.0 6.3
Casing Color White (3.0Y8.5/0.5) White (3.0Y8.5/0.5)
Dimensions: (H×W×D) mm 290×1,050×230 290×1,050×230
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×14×1.4 2×14×1.4
Face Area m² 0.213 0.213
Fan
Model QCL9686M QCL9686M
Type Cross Flow Fan Cross Flow Fan
Motor Output × Number
of Units
W43×143×1
Air Flow Rate (H/L)
m³/min 12/9 15/12
cfm 424/318 530/424
Drive Direct Drive Direct Drive
Temperature Control Microprocessor Thermostat for Cooling and Heating Microprocessor Thermostat for Cooling and Heating
Sound Absorbing Thermal Insulation Material
Foamed Polystyrene /
Foamed Polyethylene
Foamed Polystyrene /
Foamed Polyethylene
Air Filter Resin Net (Washable) Resin Net (Washable)
Piping
Connections
Liquid Pipes mm φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ12.7 (Flare Connection)
Drain Pipe mm
VP13
(External Dia. 18 Internal Dia. 13)
VP13
(External Dia. 18 Internal Dia. 13)
Machine Weight (Mass) kg 13 13
5 Sound Level (H/L) dBA 39/34 42/36
Safety Devices Fuse Fuse
Refrigerant Control ——
Connectable outdoor unit R-410A M(A) Series R-410A M(A) Series
Standard Accessories
Operation Manual, Installation Manual, Installation Panel,
Paper Pattern for Installation, Insulation Tape, Clamps,
screws.
Operation Manual, Installation Manual, Installation Panel,
Paper Pattern for Installation, Insulation Tape, Clamps,
screws.
Drawing No. C: 3D046711
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
RT=kW×0.284
cfm=m³/min×35.3
Model BEVQ50MVE
Power Supply 1 Phase 50Hz 220~240V
Casing Galvanized Steel Plate
Dimensions: (H×W×D) mm 100×350×225
Sound Absorbing Thermal Insulation Material Flame and Heat Resistant Foamed Polyethylene
Piping
Connection
Indoor
Unit
Liquid Pipes 6.4mm (Flare Connection)
Gas Pipes 12.7mm (Flare Connection)
Outdoor
Unit
Liquid Pipes
6.4mm (Flare Connection)
Suction Gas Pipes
12.7mm (Flare Connection)
Machine Weight kg 3.0
Standard Accessories Installation manual, Gas piping connections, Insulation for fitting, Sealing material, Clamps
Drawing No. 4D046708
