Specifications Si39-502A
28 Specifications
Ceiling Mounted Duct Type
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
4 External static pressure is changeable to change over the connectors inside electrical box, this pressure
means
"High static pressure-Standard".
5 Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its
colorimetric method (gravity method) 50% or more.
6 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
7 Anechoic chamber conversion value, measured at a point 1.5m downward from the unit center. These
values are normally somewhat higher during actual operation as a result of ambient conditions.
Model FXMQ40MVE FXMQ50MVE FXMQ63MVE FXMQ80MVE
1 Cooling Capacity (19.5°CWB)
RT 1.3 1.6 2.1 2.6
kcal/h 4,000 5,000 6,300 8,000
Btu/h 16,000 19,800 24,900 31,700
kW 4.7 5.8 7.3 9.3
2 Cooling Capacity (19.0°CWB) kW 4.5 5.6 7.1 9.0
3 Heating Capacity
RT 1.4 1.8 2.3 2.8
kcal/h 4,300 5,400 6,900 8,600
Btu/h 17,100 21,500 27,300 34,100
kW 5.0 6.3 8.0 10.0
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 390×720×690 390×720×690 390×720×690 390×720×690
Coil (Cross
Fin Coil)
Rows×Stages×Fin
Pitch
mm 3×16×2.0 3×16×2.0 3×16×2.0 3×16×2.0
Face Area m² 0.181 0.181 0.181 0.181
Fan
Model D11/2D3AB1VE D11/2D3AB1VE D11/2D3AB1VE D11/2D3AA1VE
Type Sirocco Fan Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output ×
Number of Units
W 100×1 100×1 100×1 160×1
Air Flow Rate (H/L)
m³/min 14/11.5 14/11.5 14/11.5 19.5/16
cfm 494/406 494/406 494/406 688/565
External Static
Pressure 50 / 60Hz
Pa 157/157-118/108
4 157/157-118/108
4 157/157-118/108
4 157/160-108/98
4
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber Glass Fiber Glass Fiber Glass Fiber
Air Filter
5
5
5
5
Piping
Connections
Liquid Pipes mm φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Machine Weight (Mass) kg 44 44 44 45
7 Sound Level (H/L)
50/60Hz
220V
dBA
39/35 39/35 39/35 42/38
50Hz
240V
41/37 41/37 41/37 44/40
Safety Devices
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Fuse for Fan Motor
Fuse,
Thermal Fuse for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A M(A) Series R-410A M(A) Series R-410A M(A) Series R-410A M(A) Series
Standard Accessories
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Operation Manual,
Installation Manual, Drain
Hose, Clamp Metal,
Insulation for Fitting, Sealing
Pads, Clamps, Screws.
Drawing No. C: 3D038814
()()()()
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
RT=kW×0.284
cfm=m³/min×35.3
