Specifications Si39-502A
14 Specifications
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB.
2 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 46°CDB.
3 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB.
4 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 46°CDB.
5 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB.
6 Sound level : Anechoic chamber conversion value, measured at a point 1 m in front of the unit at a height
of 1.5m. The Sound level of “Combination Unit” is a supposed value. During actual operation, these
values are normally somewhat higher as a result of ambient conditions.
7 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as
RXYQ8MYLKE.
Model Name (Combination Unit) RXYQ24MYLK(E) RXYQ26MYLK(E)
Model Name (Independent Unit) RXYQ8MYLK(E)+RXYQ8MYLK(E)+RXYQ8MYLK(E) RXYQ8MYLK(E)+RXYQ8MYLK(E)+RXYQ10MYLK(E)
1 /
2 Cooling Capacity
RT 19.7 / 19.4 21.1 / 19.8
Btu / h 236,000 / 233,000 254,000 / 238,000
kcal / h 59,600 / 58,800 64,000 / 59,900
kW 69.3 / 68.4 74.4 / 69.7
3 /
4 Cooling Capacity
RT 19.1 / 19.1 20.7 / 19.6
Btu / h 229,000 / 229,000 248,000 / 235,000
kcal / h 57,800 / 57,800 62,600 / 59,300
kW 67.2 / 67.2 72.8 / 68.9
5 Heating Capacity
RT 21.3 23.1
Btu / h 256,000 278,000
kcal / h 64,500 70,100
kW 75.0 81.5
Casing Color
Without (E): Ivory White (5Y7.5 / 1)
With (E): Light Camel (2.5Y6.5 / 1.5)
Without (E): Ivory White (5Y7.5 / 1)
With (E): Light Camel (2.5Y6.5 / 1.5)
Dimensions: (H×W×D) mm (1600×1240×765)+(1600×1240×765)+(1600×1240×765) (1600×1240×765)+(1600×1240×765)+(1600×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72+10.53)×3 (13.72+10.53)×3
Number of Revolutions r.p.m (6480, 2900)×3 (6480, 2900)×3
Motor Output×Number
of Units
kW (0.7+4.5)×3 (0.7+4.5)×2+(1.6+4.5)
Starting Method Direct on line (inverter drive) Direct on line (inverter drive)
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×30.75×3
Air Flow Rate m³/min 210+210+210 210+210+210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ15.9 (Flare Connection) φ19.1 (Flare Connection)
Gas Pipe mm φ34.9 (Brazing Connection) φ34.9 (Brazing Connection)
Product Mass (Machine Weight) kg 268+268+268 268+268+268
6 Sound Level dBA 65 65
Safety Devices
High Pressure Switch, Fan Driver Overload Protector,
Over Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector,
Over Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 5~100 5~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 28.2 28.4
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C: 4D050535 C: 4D050535, 4D050536
Conversion Formulae
RT=kW×0.284
Btu/h=kW×3412
kcal/h=kW×860
cfm=m³/min×35.3
