Si39-502A Other Control
Function 75
5.2 Emergency Operation
If the compressor cannot operate, this control inhibits any applicable compressor or outdoor unit
from operating to perform emergency operation only with the operative compressor or outdoor
unit.
5.2.1 Restrictions for Emergency Operation
• In the case of system with 1 outdoor unit installed, only when thermostats of indoor units
having a capacity of 50% or more of the outdoor unit capacity turn ON, the emergency
operation is functional. (If the total capacity of indoor units with thermostat ON is small, the
outdoor unit cannot operate.)
• If the emergency operation is set while the outdoor unit is in operation, the outdoor unit stops
once after pump-down residual operation (a maximum of 5 minutes elapsed).
5.2.2 In the Case of 1-Outdoor-Unit System (RXYQ8M, 10M)
[Set the system to operation prohibition mode by compressor]
• In order to set an INV compressor to operation
prohibition mode, set No. 42 of Setting mode 2 to
"EMERGENCY OPERATION".
(Procedure)
(1) Press and hold the MODE button (BS1) for a
period of 5 seconds or more.
(2) Press the SET button (BS2) 42 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
• In order to set STD1 compressors to operation
prohibition mode, set No. 19 of Setting mode 2 to
"STD1, OPERATION PROHIBITION". (RXYQ8M,
10M)
(Procedure)
(1) Press and hold the MODE button (BS1) for a
period of 5 seconds or more.
(2) Press the SET button (BS2) 19 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
• For the system with a single outdoor unit (RXYQ8M, 10M), automatic backup operation is not
functional.
Caution
In order to disable the compressor operation due to a failure or else, be sure to do so
in emergency operation mode.
NEVER attempt to disconnect power supply wires from magnetic contactors or else.
(Doing so will operate compressors in combination that disables oil equalization
between the compressors, thus resulting in malfunctions of other normal
compressors.)
LED display (
7
:ON
7
7
:OFF
9
:Blink)
H1P
----
H7P
(Factory set)
7
777777
777777
77
7
77
7
77
7
7
7
7777
7777
7
7
9
7
777
777
7
7
97
7
7
777777
777777
77
777
7777
7777
LED display (
7
:ON
7
7
:OFF
9
:Blink)
H1P
----
H7P
(Factory set)
7
777777
777777
7
7
77
77
7777
7
777777
777777
7
7777
7777
7
7
9
7
777777
777777
77
777
7777
7777
