Specifications Si39-502A
18 Specifications
Ceiling Mounted Cassette Type (Multi-flow)
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
5 Anechoic chamber conversion value, measured under JISB8616 conditions. During actual operation,
these values are normally somewhat higher as a result of ambient conditions.
Model FXFQ25MVE FXFQ32MVE FXFQ40MVE FXFQ50MVE
1 Cooling Capacity (19.5°CWB)
RT 0.8 1.1 1.3 1.6
kcal/h 2,500 3,200 4,000 5,000
Btu/h 9,900 12,600 16,000 19,800
kW 2.9 3.7 4.7 5.8
2 Cooling Capacity (19.0°CWB) kW 2.8 3.6 4.5 5.6
3 Heating Capacity
RT 0.9 1.1 1.4 1.8
kcal/h 2,800 3,400 4,300 5,400
Btu/h 10,900 13,600 17,100 21,500
kW 3.2 4.0 5.0 6.3
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 246×840×840 246×840×840 246×840×840 246×840×840
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 2×8×1.2 2×8×1.2 2×8×1.2 2×8×1.2
Face Area m² 0.363 0.363 0.363 0.363
Fan
Model QTS46D14M QTS46D14M QTS46D14M QTS46D14M
Type Turbo Fan Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W30×130×130×130×1
Air Flow Rate (H/L)
m³/min 13/10 13/10 15/11 16/11
cfm 459/353 459/353 530/388 565/388
Drive Direct Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Microprocessor Thermostat
for Cooling and Heating
Sound Absorbing Thermal Insulation Material Polyurethane Form Polyurethane Form Polyurethane Form Polyurethane Form
Piping
Connections
Liquid Pipes mm φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ12.7 (Flare Connection)
Drain Pipe mm
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
VP25
External Dia. 32
Internal Dia. 25
Machine Weight (Mass) kg 24 24 24 24
5 Sound Level (H/L) dBA 30/27 30/27 31/27 32/27
Safety Devices FuseFuseFuseFuse
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable outdoor unit R-410A M(A) Series R-410A M(A) Series R-410A M(A) Series R-410A M(A) Series
Decoration
Panels
(Option)
Model BYCP125D-W1 BYCP125D-W1 BYCP125D-W1 BYCP125D-W1
Panel Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 45×950×950 45×950×950 45×950×950 45×950×950
Air Filter
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Resin Net
(with Mold Resistant)
Weight kg 5.5 5.5 5.5 5.5
Standard Accessories
Operation manual,
Installation manual, Paper
pattern for installation, Drain
hose, Clamp metal, Washer
fixing plate, Sealing pads,
Clamps, Screws, Washer for
hanging bracket, Insulation
for fitting.
Operation manual,
Installation manual, Paper
pattern for installation, Drain
hose, Clamp metal, Washer
fixing plate, Sealing pads,
Clamps, Screws, Washer for
hanging bracket, Insulation
for fitting.
Operation manual,
Installation manual, Paper
pattern for installation, Drain
hose, Clamp metal, Washer
fixing plate, Sealing pads,
Clamps, Screws, Washer for
hanging bracket, Insulation
for fitting.
Operation manual,
Installation manual, Paper
pattern for installation, Drain
hose, Clamp metal, Washer
fixing plate, Sealing pads,
Clamps, Screws, Washer for
hanging bracket, Insulation
for fitting.
Drawing No. C: 3D038812
()()()()
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
RT=kW×0.284
cfm=m³/min×35.3
