Daikin RXYQ10MY1K [17/310] Capacity range
![Daikin RXYQ8MY1K [17/310] Capacity range](/views2/1714922/page17/bg11.png)
Capacity Range Si39-502A
6 General Information
4. Capacity Range
Outdoor Units
Capacity Index : Only for High Outdoor Temperature Use Type (RXYQ
~
MY1K(E), MYLK(E))
Indoor Units
Indoor Units (Connection Unit Series)
-50Hz Only-
Capacity Range 8HP 10HP 16HP 18HP 20HP 24HP 26HP 28HP 30HP
RXYQ 8M 10M 16M 18M 20M 24M 26M 28M 30M
Max. Number of
Connectable
Indoor Units.
10 12 20 30 32
Total Capacity
Index of Indoor
Units to be
Connected
150
~
200
150
~
250
300
~
400
300
~
450
300
~
500
450
~
600
450
~
650
450
~
700
450
~
750
Capacity Range 0.8HP 1HP 1.25HP 1.6HP 2HP 2.5HP 3.2HP 4HP 5HP 8HP 10HP
Capacity Index 20 25 31.25 40 50 62.5 80 100 125 200 250
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M 80M — 125M ——
Ceiling Mounted
Cassette Type
(Multi Flow)
FXFQ — 25M 32M 40M 50M 63M 80M 100M 125M ——
Ceiling Mounted
Cassette Corner Type
FXKQ — 25M 32M 40M — 63M —————
Slim Ceiling Mounted
Duct Type
FXDQ 20N 25N 32N 40N 50N 63N —————
Ceiling Mounted
Built-In Type
FXSQ 20M 25M 32M 40M 50M 63M 80M 100M 125M ——
Ceiling Mounted
Duct Type
FXMQ ———40M 50M 63M 80M 100M 125M 200M 250M
Ceiling Suspended
Type
FXHQ ——32M ——63M — 100M ———
Wall Mounted Type
FXAQ 20M 25M 32M 40M 50M 63M —————
Floor Standing Type
FXLQ 20M 25M 32M 40M 50M 63M —————
Concealed Floor
Standing Type
FXNQ 20M 25M 32M 40M 50M 63M —————
Capacity Range 0.8HP 1HP
1.25HP
1.6HP 2HP 2.5HP 3HP 4HP 5HP 8HP 10HP
Capacity Index 20 25 31.25 40 50 62.5 71 100 125 200 250
Ceiling Suspended
Cassette Type
FXUQ ——————71M 100M 125M ——
Wall Mounted
Type
FXAQ 20MH 25MH 32MH 40MH 50MH ——————
Floor Standing
Type
FXLQ 20MH 25MH 32MH 40MH 50MH ——————
