Si39-502A Specifications
Specifications 35
Concealed Floor Standing Type
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
5 Anechoic chamber conversion value, measured at a point 1.5 m in front of the unit at a height of 1.5 m.
During actual operation, these values are normally somewhat higher as a result of ambient conditions.
Model FXNQ20MVE FXNQ25MVE FXNQ32MVE
1 Cooling Capacity (19.5°CWB)
RT 0.7 0.8 1.1
kcal/h 2,000 2,500 3,200
Btu/h 7,800 9,900 12,600
kW 2.3 2.9 3.7
2 Cooling Capacity (19.0°CWB) kW 2.2 2.8 3.6
3 Heating Capacity
RT 0.7 0.9 1.1
kcal/h 2,200 2,800 3,400
Btu/h 8,500 10,900 13,600
kW 2.5 3.2 4.0
Casing Color Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 610×930×220 610×930×220 610×1,070×220
Coil (Cross
Fin Coil)
Rows×Stages×Fin
Pitch
mm 3×14×1.5 3×14×1.5 3×14×1.5
Face Area m² 0.159 0.159 0.200
Fan
Model D14B20 D14B20 2D14B13
Type Sirocco Fan Sirocco Fan Sirocco Fan
Motor Output ×
Number of Units
W15×115×125×1
Air Flow Rate (H/L)
m³/min 7/6 7/6 8/6
cfm 247/212 247/212 282/212
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material Glass Fiber/ Urethane Foam Glass Fiber/ Urethane Foam Glass Fiber/ Urethane Foam
Air Filter Resin Net (with Mold Resistant) Resin Net (with Mold Resistant) Resin Net (with Mold Resistant)
Piping
Connections
Liquid Pipes mm φ6.4 (Flare Connection) φ6.4 (Flare Connection) φ6.4 (Flare Connection)
Gas Pipes mm φ12.7 (Flare Connection) φ12.7 (Flare Connection) φ12.7 (Flare Connection)
Drain Pipe mm φ21 O.D (Vinyl Chloride) φ21 O.D (Vinyl Chloride) φ21 O.D (Vinyl Chloride)
Machine Weight (Mass) kg 19 19 23
5 Sound Level (H/L)
50/60Hz
220V
dBA
35/32 35/32 35/32
50Hz
240V
37/34 37/34 37/34
Safety Devices
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Fuse,
Thermal Protector for Fan Motor
Refrigerant Control Electronic Expansion Valve Electronic Expansion Valve Electronic Expansion Valve
Connectable Outdoor Unit R-410A M(A) Series R-410A M(A) Series R-410A M(A) Series
Standard Accessories
Operation Manual, Installation
Manual, Insulation for Fitting, Drain
Hose, Clamps, Screws, Washers,
Level Adjustment Screw.
Operation Manual, Installation
Manual, Insulation for Fitting, Drain
Hose, Clamps, Screws, Washers,
Level Adjustment Screw.
Operation Manual, Installation
Manual, Insulation for Fitting, Drain
Hose, Clamps, Screws, Washers,
Level Adjustment Screw.
Drawing No. C: 3D038817
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
RT=kW×0.284
cfm=m³/min×35.3
