Daikin RXYQ10MY1K [59/310] Cooling oil return operation
![Daikin RXYQ10MY1K [59/310] Cooling oil return operation](/views2/1714922/page59/bg3b.png)
Refrigerant Flow for Each Operation Mode Si39-502A
48 Refirgerant Circuit
Cooling Oil Return Operation
" OFF "
" ON "
" ON "
EV:200pls EV:200pls
FanFan
Indoor unit operation
Thermostat "OFF"
Indoor unit
FilterFilter
Heat exchanger
Fan OFF
Fan OFF
Indoor unit
FilterFilter
Heat exchanger
Fan ON
Thermostat "ON"
Indoor unit
"High temperature, high pressure gas"
"High temperature, high pressure liquid"
"Low temperature, low pressure"
Heat exchanger
Electronic expansion valve
EV:Nomal
control
FilterFilter
Fan
Heat exchanger
pipe
Receiver
Solenoid
valve
Solenoid
valve
Check
valve
Check
valve
Check
valve
Solenoid
valve
Check
valve
Filter
Filter
Filter
Filter
Filter
Filter
Filter
FilterFilter
Electronic
expansion
valve
Fusible plug
Electronic expansion valve Electronic expansion valve
Pressure regulating
valve
(check valve type)
High pressure
switch
High
pressure
switch
Compressor Compressor
Gauge port
Oil separator
Oil separator
Capillary tube
Capillary tube
4-way valve
High pressure
sensor
Low pressure
sensor
Stop valve(with service port on on-site piping side
φ
7.9 flare connection)
Check
valve
Electronic expansion valve
Capillary tube
