List of Electrical and Functional Parts Si39-502A
268 Appendix
Parts Name Symbol
Model
Remark
FXLQ
20MVE
FXLQ
25MVE
FXLQ
32MVE
FXLQ
40MVE
FXLQ
50MVE
FXLQ
63MVE
Remote
Controller
Wired Remote
Controller
BRC1A62
Option
Wireless Remote
Controller
BRC4C62
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ15W 1φ25W 1φ35W
Thermal protector 135°C : OFF 120°C : ON
Capacitor for Fan Motor
C1R 1.0µF-400V 0.5µF-400V 1.0µF-400V 1.5µF-400V 2.0µF-400V
Thermistors
Thermistor (Suction Air) R1T
ST8601-6 φ4 L1250
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-9 φ8 L2500
20kΩ (25°C)
Thermistor (for Heat
Exchanger)
R2T
ST8602A-9 φ6 L2500
20kΩ (25°C)
Others
Fuse F1U AC250V 5A
Transformer T1R TR22H21R8
Parts Name
Symbol
Model
Remark
FXNQ
20MVE
FXNQ
25MVE
FXNQ
32MVE
FXNQ
40MVE
FXNQ
50MVE
FXNQ
63MVE
Remote
Controller
Wired Remote
Controller
BRC1A62
Option
Wireless Remote
Controller
BRC4C62
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ15W 1φ25W 1φ35W
Thermal protector 135°C : OFF 120°C : ON
Capacitor for Fan Motor C1R 1.0µF-400V 0.5µF-400V 1.0µF-400V 1.5µF-400V 2.0µF-400V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-6 φ4 L1250
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-9 φ8 L2500
20kΩ (25°C)
Thermistor (for Heat
Exchanger)
R2T
ST8602A-9 φ6 L2500
20kΩ (25°C)
Others
Fuse F1U AC250V 5A
Transformer T1R TR22H21R8
Parts Name Symbol
Model
Remark
FXUQ71MV1 FXUQ100MV1 FXUQ125MV1
Remote
Controller
Wired Remote
Controller
BRC1A61 Option
Wireless Remote
Controller
BRC7C528W Option
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ45W 1φ90W
Thermal protector 130°C
Thermal protector 130°C : OFF 83°C : ON
Drain Pump M1P
AC220-240V (50Hz) AC220V (60Hz)
PJV-1426
Swing Motor M1S
MT8-L[3PA07572-1]
AC200~240V
Thermistors
Thermistor (Suction Air)
R1T
ST8601-1 φ4 L=250
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-4 φ6 L=800
20kΩ (25°C)
Others Float Switch S1L FS-0211B
