Daikin RXYQ10MY1K [230/310] Address duplication improper setting
![Daikin RXYQ8MY1K [230/310] Address duplication improper setting](/views2/1714922/page230/bge6.png)
Si39-502A Troubleshooting (OP: Central Remote Controller)
Troubleshooting 219
4.4
“
MC
”
Address Duplication, Improper Setting
Remote
Controller
Display
MC
Applicable
Models
Central remote controller
Method of
Malfunction
Detection
Detect the malfunction according to DIII-NET transmission data.
Malfunction
Decision
Conditions
Two units are both set to master controller mode or slave controller mode.
Supposed
Causes
Address duplication of centralized controller
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Are
two or more central
remote controllers
connected?
If the two central remote
controller are both set to
master controller mode or
slave controller mode, set
either of the units to master
controller mode and then
reset the power supply of the
central remote controller.
Reset power supply of the
central remote controller.
NO
YES
(V2835)
