List of Electrical and Functional Parts Si39-502A
266 Appendix
Parts Name
Symbol
Model
Remark
FXSQ
20MVE
FXSQ
25MVE
FXSQ
32MVE
FXSQ
40MVE
FXSQ
50MVE
FXSQ
63MVE
FXSQ
80MVE
FXSQ
100MVE
FXSQ
125MVE
Remote
Controller
Wired Remote
Controller
BRC1A62
Option
Wireless Remote
Controller
BRC4C62
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ50W 1φ65W 1φ85W
1φ125
W
1φ225W
Thermal Fuse 152°C
Thermal protector
135°C : OFF 87°C : ON
Drain Pump M1P
AC220-240V (50Hz)
PLD-12230DM
Thermal Fuse 145°C
Thermistors
Thermistor (Suction Air) R1T
ST8601-4 φ4 L800
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-7 φ8 L1600
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-6 φ6 L1250
20kΩ (25°C)
Others
Float Switch S1L FS-0211B
Fuse F1U 250V 5A φ5.2
Transformer T1R TR22H21R8
Parts Name
Symbol
Model
Remark
FXMQ
40MVE
FXMQ
50MVE
FXMQ
63MVE
FXMQ
80MVE
FXMQ
100MVE
FXMQ
125MVE
FXMQ
200MVE
FXMQ
250MVE
Remote
Controller
Wired Remote
Controller
BRC1A62
Option
Wireless Remote
Controller
BRC4C62
Motors
Fan Motor M1F
AC 220~240V 50Hz
1φ100W 1φ160W 1φ270W 1φ430W 1φ380W×2
Thermal protector 135°C : OFF 87°C : ON
Capacitor for Fan Motor
C1R 5µ F-400V
7µ F
400V
10µ F
400V
8µ F
400V
10µ F
400V
12µ F
400V
Thermistors
Thermistor (Suction Air)
R1T
ST8601A-5 φ4 L1000
20kΩ (25°C)
ST8601A-13
φ4 L630
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605A-4 φ8 L800
20kΩ (25°C)
ST8605A-5
φ8 L1000
Thermistor (Heat
Exchanger)
R2T
ST8602A-4 φ6 L800
20kΩ (25°C)
ST8602A-6
φ6 L1250
Others
Float switch S1L FS-0211
Fuse F1U 250V 5A φ5.2 250V 10A φ5.2 250V 10A
Transformer T1R TR22H21R8
