Model Names of Indoor/Outdoor Units Si39-502A
2 General Information
1. Model Names of Indoor/Outdoor Units
Indoor Units
Note: FXDQ has following 2 series as shown below.
FXDQ-NVE : with Drain Pump
FXDQ-NVET : without Drain Pump (For General Asia Area : except for EU, China and Australia)
Indoor Units (Connection Unit Series)
-50Hz Only-
Notes: BEV unit is required for each indoor unit.
Outdoor Units
Type Model Name Power Supply
Ceiling Mounted
Cassette Type
(Double Flow)
FXCQ 20M 25M 32M 40M 50M 63M 80M — 125M — —
VE
Ceiling Mounted
Cassette Type
(Multi Flow)
FXFQ — 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling Mounted
Cassette Corner
Type
FXKQ — 25M 32M 40M — 63M — — — — —
Slim Ceiling Mounted
Duct Type
FXDQ* 20N 25N 32N 40N 50N 63N — — — — —
Ceiling Mounted
Built-In Type
FXSQ 20M 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling Mounted
Duct Type
FXMQ — — — 40M 50M 63M 80M 100M 125M 200M 250M
Ceiling Suspended
Type
FXHQ — — 32M — — 63M — 100M — — —
Wall Mounted Type
FXAQ 20M 25M 32M 40M 50M 63M — — — — —
Floor Standing Type
FXLQ 20M 25M 32M 40M 50M 63M — — — — —
Concealed Floor
Standing Type
FXNQ 20M 25M 32M 40M 50M 63M — — — — —
Type Model Name Power Supply
Ceiling Suspended
Cassette Type
FXUQ ——————71M100M 125M — —
V1
Wall Mounted
Type
FXAQ
20MH 25MH 32MH 40MH 50MH
——————
Floor Standing
Type
FXLQ
20MH 25MH 32MH 40MH 50MH
——————
Connection Unit BEVQ-M 50M 50M 50M 50M 50M — 71M 100M 125M — — VE
Series Model Name Power Supply
Heat Pump
RXYQ 8M 10M 16M 18M 20M 24M 26M 28M 30M Y1K(E)
RXYQ 8M 10M 16M 18M 20M 24M 26M 28M 30M YLK(E)
VE: 1φ, 220~240V, 50Hz, 1φ, 220V, 60Hz
V1: 1φ, 220~240V, 50Hz
Y1: 3φ, 380~415V, 50Hz
YL: 3φ, 380, 60Hz
