Si39-502A Specifications
Specifications 15
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB.
2 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 46°CDB.
3 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB.
4 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 46°CDB.
5 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB.
6 Sound level : Anechoic chamber conversion value, measured at a point 1 m in front of the unit at a height
of 1.5m. The Sound level of “Combination Unit” is a supposed value. During actual operation, these
values are normally somewhat higher as a result of ambient conditions.
7 The units with anti-corrosion treatment will be available as standard. Please specify the suffix “E” as
RXYQ8MYLKE.
Model Name (Combination Unit) RXYQ28MYLK(E) RXYQ30MYLK(E)
Model Name (Independent Unit) RXYQ8MYLK(E)+RXYQ10MYLK(E)+RXYQ10MYLK(E) RXYQ10MYLK(E)+RXYQ10MYLK(E)+RXYQ10MYLK(E)
1 /
2 Cooling Capacity
RT 22.6 / 20.2 24.0 / 20.5
Btu / h 271,000 / 242,000 289,000 / 247,000
kcal / h 68,400 / 61,100 72,800 / 62,200
kW 79.5 / 71.0 84.6 / 72.3
3 /
4 Cooling Capacity
RT 22.3 / 20.1 23.9 / 20.5
Btu / h 268,000 / 241,000 287,000 / 247,000
kcal / h 67,400 / 60,700 72,200 / 62,200
kW 78.4 / 70.6 84.0 / 72.3
5 Heating Capacity
RT 25.0 26.8
Btu / h 300,000 322,000
kcal / h 75,700 81,300
kW 88.0 94.5
Casing Color
Without (E): Ivory White (5Y7.5 / 1)
With (E): Light Camel (2.5Y6.5 / 1.5)
Without (E): Ivory White (5Y7.5 / 1)
With (E): Light Camel (2.5Y6.5 / 1.5)
Dimensions: (H×W×D) mm (1600×1240×765)+(1600×1240×765)+(1600×1240×765) (1600×1240×765)+(1600×1240×765)+(1600×1240×765)
Heat Exchanger Cross Fin Coil Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type Hermetically Sealed Scroll Type
Piston Displacement m³/h (13.72+10.53)×3 (13.72+10.53)×3
Number of Revolutions r.p.m (6480, 2900)×3 (6480, 2900)×3
Motor Output×Number
of Units
kW (0.7+4.5)+(1.6+4.5)×2 (1.6+4.5)×3
Starting Method Direct on line (inverter drive) Direct on line (inverter drive)
Fan
Type Propeller Fan Propeller Fan
Motor Output kW 0.75×30.75×3
Air Flow Rate m³/min 210+210+210 210+210+210
Drive Direct Drive Direct Drive
Connecting
Pipes
Liquid Pipe mm φ19.1 (Flare Connection) φ19.1 (Flare Connection)
Gas Pipe mm φ34.9 (Brazing Connection) φ34.9 (Brazing Connection)
Product Mass (Machine Weight) kg 268+268+268 268+268+268
6 Sound Level dBA 65 65
Safety Devices
High Pressure Switch, Fan Driver Overload Protector,
Over Current Relay, Inverter Overload Protector,
Fusible Plugs
High Pressure Switch, Fan Driver Overload Protector,
Over Current Relay, Inverter Overload Protector,
Fusible Plugs
Defrost Method Deicer Deicer
Capacity Control % 5~100 5~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 28.6 28.8
Control Electronic Expansion Valve Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Installation Manual, Operation Manual, Connection Pipes,
Clamps
Drawing No. C: 4D050535, 4D050536 C: 4D050536
Conversion Formulae
RT=kW×0.284
Btu/h=kW×3412
kcal/h=kW×860
cfm=m³/min×35.3
