Si39-502A Specifications
Specifications 37
Ceiling Suspended Cassette Type
Notes:
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp.: 35°CDB / Equivalent piping length: 7.5m, level
difference: 0m.
3 Indoor temp. : 20°CDB / outdoor temp.: 7°CDB, 6°CWB / Equivalent piping length: 7.5m, level difference:
0m. (Heat pump only)
4 Capacities are net, including a deduction for cooling (an additional for heating) for indoor fan motor heat.
5 Anechoic chamber conversion value, measured at a point 1.5m downward from the unit center. These
values are normally somewhat higher during actual operation as a result of ambient conditions.
BEV Units
Model
Indoor Unit
FXUQ71MV1 FXUQ100MV1 FXUQ125MV1
Connection Unit
BEVQ71MVE BEVQ100MVE BEVQ125MVE
1 Cooling Capacity (19.5°CWB)
RT 2.4 3.3 4.1
kcal/h 7,100 10,000 12,500
Btu/h 28,300 39,600 49,500
kW 8.3 11.6 14.5
2 Cooling Capacity (19.0°CWB) kW 8.0 11.2 14.0
3 Heating Capacity (Max.)
RT 2.6 3.6 4.0
kcal/h 7,700 10,800 12,000
Btu/h 30,700 42,700 47,800
kW 9.0 12.5 14.0
Casing Color White (10Y9/0.5) White (10Y9/0.5) White (10Y9/0.5)
Dimensions: (H×W×D) mm 165×895×895 230×895×895 230×895×895
Coil (Cross
Fin Coil)
Rows×Stages×Fin Pitch mm 3×6×1.5 3×8×1.5 3×8×1.5
Face Area m² 0.265 0.353 0.353
Fan
Model QTS48A10M QTS50B15M QTS50B15M
Type Turbo Fan Turbo Fan Turbo Fan
Motor Output × Number
of Units
W45×190×190×1
Air Flow Rate (H/L)
m³/min 19/14 29/21 32/23
cfm 671/494 1,024/741 1,130/812
Drive Direct Drive Direct Drive Direct Drive
Temperature Control
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Microprocessor Thermostat for
Cooling and Heating
Sound Absorbing Thermal Insulation Material
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Heat Resistant Foamed Polyethylene,
Regular Foamed Polyethylene
Piping
Connections
Liquid Pipes mm φ9.5 (Flare Connection) φ9.5 (Flare Connection) φ9.5 (Flare Connection)
Gas Pipes mm φ15.9 (Flare Connection) φ15.9 (Flare Connection) φ15.9 (Flare Connection)
Drain Pipe mm
VP20
(External Dia. 26 Internal Dia. 20)
VP20
(External Dia. 26 Internal Dia. 20)
VP20
(External Dia. 26 Internal Dia. 20)
Machine Weight kg 25 31 31
5 Sound Level (H/L) (230V) dBA 40/35 43/38 44/39
Safety Devices Thermal Protector for Fan Motor Thermal Protector for Fan Motor Thermal Protector for Fan Motor
Standard Accessories
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Operation Manual, Installation
Manual, Drain Hose, Clamp Metal,
Insulation for Fitting, Sealing Pads,
Clamps, Screws, Washers, Holding
Plate.
Drawing No. C : 4D045395
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
RT=kW×0.284
cfm=m³/min×35.3
Model BEVQ71MVE BEVQ100MVE BEVQ125MVE
Power Supply 1 Phase 50Hz 220~240V 1 Phase 50Hz 220~240V 1 Phase 50Hz 220~240V
Casing Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
Dimensions: (H×W×D) mm 100×350×225 100×350×225 100×350×225
Sound Absorbing Thermal Insulation
Material
Flame and Heat Resistant Foamed
Polyethylene
Flame and Heat Resistant Foamed
Polyethylene
Flame and Heat Resistant Foamed
Polyethylene
Piping
Connection
Indoor
Unit
Liquid Pipes 9.5mm (Flare Connection) 9.5mm (Flare Connection) 9.5mm (Flare Connection)
Gas Pipes 15.9mm (Flare Connection) 15.9mm (Flare Connection) 15.9mm (Flare Connection)
Outdoor
Unit
Liquid Pipes
9.5mm (Flare Connection) 9.5mm (Flare Connection) 9.5mm (Flare Connection)
Suction Gas Pipes
15.9mm (Flare Connection) 15.9mm (Flare Connection) 15.9mm (Flare Connection)
Machine Weight (Mass) kg 3.0 3.0 3.5
Standard Accessories
Installation manual, Gas piping
connections, Insulation for fitting,
Sealing material, Clamps
Installation manual, Gas piping
connections, Insulation for fitting,
Sealing material, Clamps
Installation manual, Gas piping
connections, Insulation for fitting,
Sealing material, Clamps
Drawing No. 4D045387 4D045387 4D045388
