Si39-502A Troubleshooting by Remote Controller
Troubleshooting 147
8: ON 7: OFF 9: Blink
Malfunction
code
Operation
lamp
Inspection
display
Unit No. Malfunction contents Page
Referred
Indoor
Unit
A0 999Error of external protection device 151
A1 999PC board defect, E
2
PROM defect 152
A3 999Malfunction of drain level control system (S1L) 153
A6 999Fan motor (M1F) lock, overload 155
A7 879Malfunction of swing flap motor (MA) 156
A9 999Malfunction of moving part of electronic expansion
valve (20E)
158
AF 879Drain level about limit 160
AH 879Malfunction of air filter maintenance —
AJ 999Malfunction of capacity setting 161
C4 999Malfunction of thermistor (R2T) for heat exchange
(loose connection, disconnection, short circuit, failure)
162
C5 999Malfunction of thermistor (R3T) for gas pipes (loose
connection, disconnection, short circuit, failure)
163
C9 999Malfunction of thermistor (R1T) for air inlet (loose
connection, disconnection, short circuit, failure)
164
CJ 888Malfunction of thermostat sensor in remote controller 165
Outdoor
Unit
E1 999PC board defect 166
E3 999Actuation of high pressure switch 167
E4 999Actuation of low pressure sensor 168
E5 999Compressor motor lock 169
E6 999Standard compressor lock or over current 170
E7 999Malfunction of outdoor unit fan motor 172
E9 999Malfunction of moving part of electronic expansion
valve (Y1E, Y2E)
174
F3 999Abnormal discharge pipe temperature 176
F6 999Refrigerant overcharged 177
H3 879Malfunction of High pressure switch —
H4 999Malfunction of Low pressure switch —
H7 999Abnormal outdoor fan motor signal 178
H9 999Malfunction of thermistor (R1T) for outdoor air (loose
connection, disconnection, short circuit, failure)
179
J2 999Current sensor malfunction 180
J3 999Malfunction of discharge pipe thermistor (R31 or 32T)
(loose connection, disconnection, short circuit,
failure)
181
J5 999Malfunction of thermistor (R2T) for suction pipe
(loose connection, disconnection, short circuit,
failure)
182
J6 999Malfunction of thermistor (R4T) for heat exchanger
(loose connection, disconnection, short circuit,
failure)
183
J7 999Malfunction of receiver outlet liquid pipe thermistor (R6T) 184
J9 999Malfunction of subcooling heat exchanger gas pipe
thermistor (R5T)
185
JA 999Malfunction of discharge pipe pressure sensor 186
JC 999Malfunction of suction pipe pressure sensor 187
L0 999Inverter system error —
L4 999Malfunction of inverter radiating fin temperature rise 188
L5 999Inverter compressor motor grounding, short circuit 189
L6 999Compressor motor coil grounding on short circuit —
L8 999Inverter current abnormal 190
L9 999Inverter start up error 191
