Define the required fields of IPSec Function

 To display the VPN connection status via icon。

Chart --

Meaning Not be applied Disconnect Connecting

Name:

 The VPN name to identify the IPSec Autokey definition. The name must be the

only one and cannot be repeated.

WAN:

 The WAN interface of the local Gateway.

Gateway IP:

 The WAN interface IP address of the remote Gateway.

IPSec Algorithm:

 To display the Algorithm way.

Configure:

 Click Modify to change the argument of IPSec; click Remove to remote the setting.

IPSec Autokey Web UI
