Planet SG-1000 [29/262] Date time settings

3.2 Date/Time Settings

STEP 1﹒Select Enable synchronize with an Internet time Server

STEP 2﹒Click the down arrow to select the offset time from GMT.

STEP 3﹒Enter the Server IP / Name with which you want to synchronize.

STEP 4﹒Set the interval time to synchronize with outside servers.

System Time Setting

Click on the Sync button and then the SG-1000’s date and time will be synchronized to the

Administrator’s PC.

The value of Set Offset From GMT and Server IP / Name can be looking for from

Assist.

２８
