Planet SG-1000 [162/262] Define the required fields of trunk function

Define the required fields of Trunk Function

 To display the VPN connection status via icon。

Chart --

Meaning Not be applied Disconnect Connecting

Name:

 The VPN name to identify the VPN Trunk definition. The name must be the only

one and cannot be repeated.

Source Subnet:

 Displays the Source Subnet.

Destination Subnet:

 Displays the Destination Subnet.

Tunnel:

 Displays the Virtual Private Network’s(IPSec Autokey, PPTP Server, PPTP Client)

settings of Trunk function.

Configure:

 Click Modify to change the argument of VPN Trunk; click Remove to remote the

setting.

VPN Trunk Web UI

１６１
